Summary of Contents for Vicpas Houston Street H30
- Page 1 Model H30 Operation Manual Model H30 Version 1.0 Houston Street Technologies August 1, 2007...
- Page 2 H30 Operation Manual Houston Street Technologies...
- Page 3 H30 Operation Manual Houston Street Technologies Houston Street Technologies 135 West Davenport Street Rhinelander WI 54501 Phone: 866.441.7997 Fax: 866.278.0036 info@houstonst.com www.houstonst.com...
-
Page 4: Table Of Contents
H30 Operation Manual Houston Street Technologies Table of Contents INTRODUCTION ........................5 SPECIFICATIONS ........................5 USER INTERFACE ........................6 INSTALLATION ........................7 QUICK START GUIDE......................9 MANUAL OPERATION MODES ..................10 AUTO OPERATION MODE....................11 ENGINE STALL PROTECTION (ESP) ................12 DIGITAL INPUTS .........................14 DIGITAL OUTPUTS ......................15 SECURITY ..........................15 CONTRAST ADJUSTMENT ....................16 TROUBLESHOOTING ......................16 CONTACT ..........................16... -
Page 5: Introduction
H30 Operation Manual Houston Street Technologies 1. Introduction Houston Street Technologies’ Model H30 diesel engine controller was designed to provide simple, accurate and consistent engine control for a variety of diesel power applications. When used with an ECU controlled engine the H30 utilizes SAE J1939 CAN bus protocol to communicate desired engine control characteristics as well as display all relevant engine operating parameters and fault codes, both stored and active. -
Page 6: User Interface
H30 Operation Manual Houston Street Technologies 3. User Interface The H30’s monochrome graphical LCD display is used as a visual interface for the operator. The H30’s primary screen is the Operation Screen (shown below), which displays user-defined operating parameters on three analog gauge faces as well as scrolling text for a total of six parameters in addition to any active fault codes being broadcast by the engine ECU. -
Page 7: Installation
H30 Operation Manual Houston Street Technologies 4. Installation The cutout pattern required for surface mounting the H30 is shown below:... - Page 8 H30 Operation Manual Houston Street Technologies CAUTION: Power supply at pin 2 of Connector A (ECU Power) should be protected with a 10 Amp fuse or circuit breaker. Connector A is required for electronic engines. Connectors A and B are required for mechanical engines. Connector C is required for extended features only.
-
Page 9: Quick Start Guide
H30 Operation Manual Houston Street Technologies 5. Quick Start Guidelines POWER UP When the power button is pressed the H30 will display a splash screen that will show a company logo and controller information. After the splash screen has timed out and if START UP SECURITY is not enabled, the Operation Screen will be displayed. -
Page 10: Manual Operation Modes
H30 Operation Manual Houston Street Technologies 6. Manual Operation Modes MANUAL RAMP When in MANUAL RAMP mode the engine will operate within a range of configurable low and high RPM values, increasing and decreasing speed in one of two manners: 5 second linearly or exponentially. When using 5 second linear ramp rate the engine speed will increase from the low RPM setting to the high RPM setting in a 5 second interval when the UP button is held. -
Page 11: Auto Operation Mode
H30 Operation Manual Houston Street Technologies 7. Auto Operation Modes When in AUTO RAMP mode the engine will start and stop based off of digital inputs or pressing the U/D buttons. Startup and shutdown profiles of TIME vs. RPM are configurable, allowing for warm up and cool down cycles to minimize stress on both the engine and engine-driven equipment. -
Page 12: Engine Stall Protection (Esp)
H30 Operation Manual Houston Street Technologies 8. Engine Stall Protection (ESP) When ENGINE STALL PROTECTION (ESP) is enabled, the H30 can be used to engage and disengage feed rollers that may be overloading the engine, causing it to stall. One of the H30’s digital outputs can be configured to engage the feed forward solenoid at a set RPM limit, while a second digital output can be used to reverse the feed direction for a set amount of time (0.0 to 1.0 seconds) when a low RPM limit is reached. - Page 13 H30 Operation Manual Houston Street Technologies ESP - DUAL VALVE A dual-valve feed system is comprised of dual 2-position valves that use one solenoid each to control hydraulic oil flow, and ultimately the feed direction. The first valve is an ON/OFF valve that controls hydraulic oil flow to the feed system, while the second valve determines the direction of the feed rollers.
-
Page 14: Digital Inputs
H30 Operation Manual Houston Street Technologies 9. Digital Inputs Below is a list of settings for the (8) digital inputs currently available. Contact HST for additional input settings. DIGITAL INPUT SETTING CONTROLLER/ENGINE RESPONSE DISPLAYED MESSAGE FLOAT SWITCH HIGH BEGINS AUTO STARTUP SEQUENCE "HIGH FLOAT SWITCH"... -
Page 15: Digital Outputs
H30 Operation Manual Houston Street Technologies 10. Digital Outputs Below is a list of settings for the (4) digital outputs currently available. Contact HST for additional output settings. DIGITAL OUTPUT SETTING DESCRIPTION/USE SWITCHED POWER POWER SUPPLIED WHEN CONTROLLER IS TURNED ON AUDIBLE ALARM USE TO DRIVE AN EXTERNAL WARNING/ SHUTDOWN ALARM... -
Page 16: Contrast Adjustment
H30 Operation Manual Houston Street Technologies 12. Contrast Adjustment The H30 has an automatic contrast feature that will adjust the LCD screen contrast based off of temperature. If the contrast is too light or too dark the contrast can be manually adjusted by going to the MAIN MENU, then UTILITIES, then ADJUST DISPLAY. - Page 17 H30 Operation Manual Houston Street Technologies...
