- Page 1 DC 80V Lithium-Ion Battery Power Inverter FOR MODELS: IV80A00 INPUT: DC 80V, 6A OUTPUT: AC 120V/60HZ, 300W Owner’s Manual TOLL-FREE HELPLINE: 1-855-345-3934 www.GreenworksTools.com Read all safety rules and instructions carefully before operating this tool.
- Page 2 CONTENTS Contents ..........................2 Product Specifications ......................2 Important Safety Instructions ....................3 Protective Features of the Inverter..................5 Working Principles........................6 Operation ..........................7 Environmentally Safe Battery Disposal................... 8 Troubleshooting ........................9 Warranty ..........................10 PRODUCT SPECIFICATIONS DC 80V POWER INVERTER Output Voltage ................
- Page 3 IMPORTANT SAFETY INSTRUCTIONS W A R N I N G : THIS MANUAL CONTAINS IMPORTANT INFORMATION REGARDING SAFETY, OPERATION, MAINTENANCE AND STORAGE OF THIS PRODUCT. BEFORE USE, READ AND UNDERSTAND ALL CAUTIONS, WARNINGS, INSTRUCTIONS AND PRODUCT LABELS, PLUS YOUR GREENWORKS’S BATTERY MANUFACTURER GUIDELINES. FAILURE TO DO SO COULD RESULT IN INJURY AND/OR PROPERTY DAMAGE.
- Page 4 IMPORTANT SAFETY INSTRUCTIONS POWER SOURCE REQUIREMENTS The power source must be able to supply the necessary current to operate the load. The Greenworks™ 80-volt battery is the only DC source, this inverter cannot connect to other DC sources. W A R N I N G : Keep ventilation when using batteries.
- Page 5 PROTECTIVE FEATURES OF THE INVERTER Your inverter monitors the following potentially hazardous conditions: OVER TEMPERATURE PROTECTION – If the temperature inside the inverter is too high, the unit will automatically shut down. Allow the unit to cool for at least minutes before restarting after a heat-related shutdown.
- Page 6 MOSFET transistors in a full bridge configuration. THE OUTPUT WAVEFORM The AC output waveform of the IV80A00-series inverter is known as “modified sine wave”. It is a waveform that has characteristics similar to the sine wave shape of utility power. This type of waveform is suitable for most AC loads, including linear and switching power supplies used in electronic equipment, transformers, and motors.
- Page 7 OPERATION INSTRUCTIONS NOTE: This product requires no assembly. 1. Insert the battery pack (A) into the power inverter. 2. Press the switch (B) to ON position. 3. Connect the USB (C) or plug (D) to the receptacle. Note: To remove the battery pack, press the battery release button (E) on the power inverter. W A R N I N G : Shut off the power source, or disconnect the battery when the power interter is not in use.
- Page 8 ENVIRONMENTALLY SAFE BATTERY DISPOSAL The following toxic and corrosive materials are in the batteries used in this tool battery pack: Li-ion, a toxic material. W A R N I N G : All toxic materials must be disposed of in a specified manner to prevent contamination of the environment.
- Page 9 TROUBLESHOOTING PROBLEM POSSIBLE CAUSE SOLUTION The power needed to start AC appliances Read the information panel on each AC ap- may be as much as 2 Inverter will not turn on pliance carefully to accurately determine the to 8 times its continu- tool’s input wattage.
- Page 10 WARRANTY Greenworks™ hereby warranties this product, to the original purchaser with proof of purchase, for a period of four (4) years against defects in materials, parts or workmanship. Greenworks™, at its own discretion will repair or replace any and all parts found to be defective, through normal use, free of charge to the customer.
