Advance acoustic ATS 180 Operating Manual

Shoulder bag, frame and combination unit models

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

ATS 180

ATS180 - Operator Manual

Operating Controls

Operating Controls ........................................................................................................................

Safety Notes .....................................................................................................................................

Product Specification ...................................................................................................................

Intended Use ....................................................................................................................................

Introduction ......................................................................................................................................

Delivered Items ................................................................................................................................

Electrical Safety ................................................................................................................................

Using the Equipment .....................................................................................................................

Data Log Memory ............................................................................................................................

Manual Welding .............................................................................................................................

Fusamatic Welding .......................................................................................................................

Bar Code Welding .........................................................................................................................

Fusion Operator Badge ..............................................................................................................

GPS Location .................................................................................................................................

Shoulder Bag, Frame and

Extreme Low Temperature Operation .................................................................................

Downloading the Weld Memory .............................................................................................

Upgrading the Operating Software .......................................................................................

Combination Unit Models

Set Up Options ..............................................................................................................................

Information .....................................................................................................................................

Fault Finding ...................................................................................................................................

Maintenance ..................................................................................................................................

Disposal ............................................................................................................................................

Calibration and Warranty ...........................................................................................................

Operating manual

Declaration of Conformity ........................................................................................................

Service and Repair.........................................................................................................................

Quick Start Guide ..........................................................................................................................

ATS 180

Table of Contents

Need help?

Do you have a question about the ATS 180 and is the answer not in the manual?

Questions and answers

Summary of Contents for Advance acoustic ATS 180

Page 1 ATS 180 ATS180 - Operator Manual Operating Controls Operating Controls ........................Safety Notes ............................. Product Specification ........................Intended Use ............................ Introduction ............................Delivered Items ..........................Electrical Safety ..........................Using the Equipment ........................Data Log Memory ..........................Manual Welding ..........................ATS 180 Fusamatic Welding ........................
Page 2: Table Of Contents
ATS 180 ATS180 - Operator Manual Index Index ..............................Operating Controls ........................Safety Notes ..........................Product Specification ....................... Intended Use ..........................Introduction ........................... Delivered Items ..........................Electrical Safety..........................Duty Cycle ............................Using the Equipment ......................... Data Entry ............................Welding ............................
Page 3: Operating Controls
ATS 180 ATS180 - Operator Manual Operating Controls Supply Cable Temperature Sensor Protective Bag On/Off Switch Cooling Fan Display Buttons Welding Cable Bar code scanner reader 4. On/Off Switch (On side of case) 5. Cooling Fan (On side of case) 2.
Page 4: Safety Notes
ATS 180 ATS180 - Operator Manual Safety Notes • RISK OF EXPLOSION! This welding unit must not be used in a gaseous atmosphere. • RISK OF ELECTRIC SHOCK! Do not open. No user serviceable parts inside. • Before using, always visually inspect the unit to see that the cables and connectors are not worn or damaged.
Page 5: Product Specification
Bespoke OEM As a bespoke OEM Original Manufacturer we can produce this product as an OEM to suit your business Contact us to discuss your requirements Specification details - ATS 180 Manual, Barcode Operating Modes 39.5V (8 to 48V) Welding Voltage...
Page 6: Intended Use
ATS 180 ATS180 - Operator Manual Intended Use This equipment is intended to weld constant voltage electrofusion fittings suitable for low, medium and high pressure pipe work systems. This welding unit has been designed to comply with the International Organization for Standardization standard ISO12176-2:2000 “Plastic pipes and fittings, equipment for fusion...
Page 7: Electrical Safety
ATS 180 ATS180 - Operator Manual Electrical Safety WARNING! Switch off and remove the plug from the mains before adjusting, cleaning or if the cable is cut, damaged or entangled. This welding unit is Class 1 and requires an earthed (grounded) connection. An earth spike must be used with generators.
Page 8: Duty Cycle
ATS 180 ATS180 - Operator Manual Duty Cycle The equipment is designed for everyday use on connection size fittings up to 110mm diameter. It can also weld fittings up to 200mm diameter (8”) but with a reduced duty cycle. Larger diameter fittings generate a lot of heat within the equipment and it must be allowed to cool down between fusion cycles.
Page 9: Using The Equipment
ATS 180 ATS180 - Operator Manual Using the equipment Prepare and clamp the pipe and fittings inline with the manufacturers recommendations. Connect the supply cable to the correct supply voltage and switch the unit on. The screen will show the model number and software version. It will also show the current date and the calibration due date.
Page 10: Data Entry
ATS 180 ATS180 - Operator Manual Data Entry Letters and numbers are entered using the arrow buttons. Using the up and down arrows will scroll through the list of A to Z and 1 to 9. When the correct letter has been chosen, pressing the right arrow button will move to the next position.
Page 11 ATS 180 ATS180 - Operator Manual Welding Welding modes: Bar Code Manual Data Logging Connect the welding cable to the fitting and the screen will show Read the bar code on the fitting. If the code is read correctly then a message will be displayed saying “Read OK”.
Page 12: Welding
ATS 180 ATS180 - Operator Manual The welding voltage and current will be displayed to allow the operator to confirm the welding process is correct. When the weld is complete, the following screen will be displayed: The cooling time will now count up. This is to help the operator know when the weld ended and will continue to count up until the lead is disconnected from the fitting.
Page 13 ATS 180 ATS180 - Operator Manual MANUAL ENTRY If the bar code pen does not work or the bar code label on the fitting has been damaged and there are no numbers shown on the label, then the time and voltage can be entered manually.
Page 14 ATS 180 ATS180 - Operator Manual DATA LOGGING If data logging information is required, on the “Connect Fitting Screen” press the STOP button. The screen will show: Enter the Operator Name press the OK button. The screen will now show: Enter the Location and press the OK button.
Page 15: Options Menu
ATS 180 ATS180 - Operator Manual Options Menu When the display shows the “Connect Fitting” message, pressing the OK button will enter the options menu. Press OK and the display will show: Use the up and down arrows to scroll through the options. When the required option is shown press the left or right arrow to select it.
Page 16 ATS 180 ATS180 - Operator Manual Data Download Operator This will allow the stored data log memory to be downloaded to a USB memory drive. To view the details of the last weld on the screen, press the up arrow. All stored information will be shown.
Page 17 ATS 180 ATS180 - Operator Manual UK Data & Celsius Operator This will change the format of the date and temperature into UK Metric format. The date will be set to dd/mm/yy and the temperature to Celsius. US Date & Fahrenheit Operator This will change the format of the date and temperature into US Imperial format.
Page 18 ATS 180 ATS180 - Operator Manual Warranty Information Operator This will display the warranty information for the unit, when it was sold and what the weld counter was. First Use Date Operator This will show the date the unit was first used from new:...
Page 19 ATS 180 ATS180 - Operator Manual Display Ohm Meter Operator This will display the resistance of the fitting connected to the welding cable. This option can be used for fault finding, to make sure the welding unit is measuring the fitting resistance correctly.
Page 20 ATS 180 ATS180 - Operator Manual Barcode Ohms Required Supervisor In bar code welding, the actual resistance of the fitting is matched against the information in the bar code label. This option will force the checking of the fitting resistance. If there is a difference, the weld will not be allowed to continue.
Page 21 ATS 180 ATS180 - Operator Manual Change Unit Information Workshop This option allows an authorised service agent to change the part number and serial number of the unit. Set Calibration Period Workshop This option allows an authorised service agent to set the calibration period of the welder.
Page 22: Maintenance
ATS 180 ATS180 - Operator Manual Maintenance Regularly check for obvious defects such as loose or damaged cables and connectors. Look for warn components and broken covers or housings. There are no user serviceable parts inside the unit. It should be returned to an approved service agent for repair and calibration.
Page 23: Fault Finding
ATS 180 ATS180 - Operator Manual Fault Finding During operation, the welding unit monitors all aspects of its operation. If a fault occurs then an error message will be shown. 0: Weld OK No Fault, weld completed OK. 1: Stuck button on start up This fault shows when the power is first switched on.
Page 24 ATS 180 ATS180 - Operator Manual 8: Ambient temperature more than +50ºC. The unit has detected that the ambient temperature sensor has broken or a wire has gone open circuit. The unit must be returned to a service agent for repair.
Page 25 ATS 180 ATS180 - Operator Manual 21: High output volts (+1.25%) This fault will happen if the output voltage is 1.25% higher than the set point for more than 3 seconds. It will normally be caused by a poor quality generator with the supply voltage fluctuating.
Page 26 ATS 180 ATS180 - Operator Manual 40: Bar Code Invalid: Temperature Compensation Digits 22 and 23 of the bar code have been decoded incorrectly. 41: Bar Code Invalid: Resistance Coefficient Digit 18 of the bar code has been decoded incorrectly.
Page 27: Disposal
ATS 180 ATS180 - Operator Manual Disposal The equipment and packaging should be sorted for environmentally friendly recycling. DO NOT DISPOSE OF THIS EQUIPMENT INTO HOUSEHOLD WASTE ! According to the European Directive 2002/96/EC Waste Electrical and Electronic Equipment (WEEE), when no longer suitable for use, this equipment must be separately collected and sent for recycling.
Page 28: Calibration And Warranty
ATS 180 ATS180 - Operator Manual Calibration and Warranty This welding unit has been manufactured, inspected and tested in accordance with the quality control systems in place at Advance Welding. This welding unit has been calibrated using equipment that is traceable to national and international standards, through a NAMAS accredited laboratory.
Page 29 ATS 180 ATS180 - Operator Manual Customers will prepay all shipping charges for products returned under warranty, and Advance Welding will charge for return of the products back to the customer. This warranty statement gives the customer specific legal rights. The customer may also have other rights which vary from country to country in the world.
Page 30: Declaration Of Conformity
ATS 180 ATS180 - Operator Manual Declaration of Conformity This welding unit has been designed to comply with the harmonised standards under the “New Approach” directives, and has been CE marked accordingly. The applicable standards are: 2004/108/EC Electromagnetic compatibility (EMC)
Page 31: Service And Repair
ATS 180 ATS180 - Operator Manual Service and Repair Manufactured in the UK by: ADVANCE WELDING Units 1 & 2 Taylor Street Cleckheaton West Yorkshire BD19 5DZ United Kingdom Tel: UK 0844 880 7748 +44 1274 870112 Fax :UK 0870 752 6139 +44 870 752 6139 Email: sales@advancewelding.co.uk...
