Features
USB 2.0 MTT Hub
Fully compliant with Universal Serial Bus
Specification Revision 2.0
Supports USB HS (480Mbps), FS (12Mbps) and
LS (1.5Mbps) modes
Three downstream ports and one upstream port
with integrated USB 2.0 transceivers
Multiple Transaction Translator (MTT) provides
respective TT control logics for each downstream
port
Supports one suspend LED indicator and three
downstream port status LED indicator
On-chip 8-bit micro-processor (6 MIPS @12MHz)
with 64-byte RAM and 2K internal ROM
Built-in upstream port 1.5KΩ pull-up and
downstream port 15KΩ pull-down resistors
Supports both individual and gang modes of power
management and over-current detection for
downstream ports
Supports compound-device (non-removable in
downstream ports) by I/O pin configuration
Improves output drivers with slew-rate control for
EMI reduction
Internal power-fail detection for ESD recovery
10/100M Fast Ethernet Controller
Integrates 10/100Mbps Fast Ethernet MAC/PHY
IEEE 802.3 10Base-T/100Base-TX compatible
Supports twisted pair crossover detection and
auto-correction (HP Auto-MDIX)
Embedded 16KB SRAM for RX packet buffering
and 8KB SRAM for TX packet buffering
Supports both Full-duplex with flow control and
Half-duplex with backpressure operation
Product Description
The AX88760 is a high performance and highly integrated USB/Ethernet and USB/USB connectivity solution which
contains an USB 2.0 hub, three downstream USB 2.0 transceivers, an upstream USB 2.0 transceiver, a 10/100M Ethernet
PHY, a 10/100M Ethernet MAC, a EEPROM controller, and a 24KB SRAM. The AX88760 is targeted for many
applications such as desktops, notebook PC's, Ultra-Mobile PC's, docking stations, game consoles, multifunction
printers, digital-home appliances, and any embedded system using a standard USB port.
Always contact ASIX Electronics for possible updates before starting a design.
This data sheet contains new products information. ASIX Electronics reserves the rights to modify product specification without notice. No liability is
assumed as a result of the use of this product. No rights under any patent accompany the sale of the product.
ASIX ELECTRONICS CORPORATION
4F, NO.8, Hsin Ann Rd., Hsinchu Science Park, Hsin-Chu City, Taiwan, R.O.C. 300
TEL: 886-3-579-9500
USB2.0 to Ethernet Combo Controller
Document No: AX88760/V1.01/07/07/10
Supports 2 VLAN ID filtering, received VLAN
Tag (4 bytes) can be stripped off or preserved
MAC/PHY loop-back diagnostic capability
Support Wake-on-LAN Function
Supports Suspend mode and Remote Wakeup
via Link-up, Magic packet, MS wakeup frame
and external pin
Optional PHY power down during Suspend
mode
High performance packet transfer rate over USB
bus using proprietary burst transfer mechanism (US
Patent Approval)
Supports USB to Ethernet bridging or vice versa in
hardware
Supports 256/512 bytes (93c56/93c66) of serial
EEPROM (for storing USB Descriptors for USB to
LAN function)
Supports automatic loading of Ethernet ID, USB
Descriptors and Adapter Configuration from
EEPROM after power-on initialization
Integrates on-chip voltage regulator and only requires a
single 3.3V power supply
12MHz and 25MHz clock input from either crystal or
oscillator source
Integrates on-chip power-on reset circuit
Package type with 100-pin LQFP RoHS compliant
package
Operating temperature range: 0°C to 70°C
* IEEE is a registered trademark of the Institute of Electrical and
Electronic Engineers, Inc.
* All other trademarks and registered trademark are the property
of their respective holder
FAX: 886-3-579-9558
AX88760
USB 2.0 MTT HUB and
Released Date: 07/07/2010
http://www.asix.com.tw/
