Specifications
Model
VLEDB2HG/W
Pick-up Device
1/3" 960H CCD
Effective Pixels (H×V)
NTSC:976×494
Sensing Area
4.9mm×3.7mm
Horizontal Resolution
700 TV Lines
Minimum Illumination
0.01 Lux, 0 Lux at IR on
S/N Ratio
More than 52dB
Scanning System
2:1 Interlace
Synchronous System
Internal
Electronic Shutter
1/50s(1/60s)～1/100,000s
IR Distance
IR Leds
24 pcs Φ5 infrared LED
IR status
IR on: under 10Lux, by CDS auto control
Water Resistance
IP66
Gama Characteristic
Auto Gain Control
Auto
White Balance
Auto
Video Output
1.0Vp-p composite video, 75Ω
Lens
3.6mm
Power/Current
12VDC/ IR on: 300mA, IR off: 80mA
Operating Temperature
14F～122F
Storage Temperature
-4F～140F
65'
0.45
VLEDB2HG/W Series Color
Camera
IR Bullet Camera
Note:
Before applying power to the cam-
era, please read this UserGuide in detail.
