Sedna VA4220WF-K5 Installation Manual

VA4220WF-K5
VA4221WF-K5
Installation Guide
Smart Water Damage Protection System
STEP 1
CONNECTING THE VALVE TO YOUR WI-FI NETWORK
1
Download the free Sinope Water Leak
Protection app on your device from the
AppStore or Google Play*.
*It is also possible to operate the valve without an Internet connection.
However, you will not be notified when a water leak is detected.
Refer to the "Support" section of our Website at www.sinopetech.com.
4
Open the app and log into your
Sinope Water Leak Protection
account or create an account.
If you already have a Neviweb®
account, use the same login
information to configure and
control your valve.
Follow the steps to add a
device.
STEP 2
CONNECTING THE WATER LEAK DETECTORS TO THE SMART WATER VALVE
1
The mode switch of the
valve must be in
position "1".
The valve must be
plugged into a
power outlet.
4 Press the detector's connection button.
Light
Green light blinks
Green light lit for 10 s
Red light blinks
*Refer to the "Support" section of our Website at www.sinopetech.com.
*
SMART WATER DAMAGE PROTECTION SYSTEM
Protect your belongings. It's easy as 1,2,3.
The Sedna water damage protection system protects your property
at all times. In addition to detecting leaks, it will close the main water
supply to your home to avoid costly damage. You are notified by
email or SMS as soon as a leak is detected, and the main water
supply is closed. The valve keeps you in control of your main water
supply at all times.
Your smart water damage protection system includes:
5 Smart water leak detectors
• 3 detectors
• 2 detectors with probe
1 Smart water valve with AC adapter
Wi-Fi
2
Remove the valve
cover by unscrewing
the 4 screws with a flat
screwdriver.
5
Connect your Sinopé
smart water leak
detectors (Step 2).
2
Press the "B" button to
open the network
connectivity session for
the detectors.
The indicator lights will
light up in sequence to
indicate that the session
is active.
Status
Device is connecting
Successful connection
Connection has failed*
Valve
Detectors
5
Once all the detectors
are connected, press
the "B" button on the
valve to close the
connectivity session.
WARNINGS
The installation of this valve should be performed by a certified
professional in conformity with local and national construction codes.
The valve closes with sufficient force to cut a finger. ALWAYS keep
your fingers away from the ball valve.
Although each unit is pre-tested at the factory, it is strongly
recommended that you test the valve before installation to
ensure proper operation in your home.
3
Connect the valve to an
electrical outlet, using
the supplied adapter,
near where it will be
installed. By doing so,
you will validate the
range of the Wi-Fi
communication
between the valve
and your network.
3
Connect the detector
to the network from its
installation location.
This will ensure it is
within range of the RF
signal of the valve.
Remove the cover and
insert the batteries.
The connection can be verified at
any time by pressing the water leak
detector's button. The indicator light
will light up in green for 10 seconds
if the unit is connected.
