Flavel Dalton No1a Installation And Operating Instructions

INSTALLATION AND OPERATING INSTRUCTIONS
LEAVE THIS DOCUMENT WITH THE HOUSEHOLDER!
All Flavel Stoves exceed the safety and performance requirements of European Standards
Intermittent burning solid fuel roomheaters for installation with a single dedicated chimney.
Independent thermal and emissions testing by SGS Environmental BV, Arnhem, Notified Body No 0608 - July 2009
Fuel
Test Standard
Test Cycle
Settings
Flue Draught Pa (ins WG)
Efficiency %
Recommended Rating kW
Mean Flue Gas Temp Rise ºC
Minimum air entry requirement
Minimum Clearance to combustibles (allow min 50mm
clearance to non-combustibles)
NOx mg/m³
CO %
CxHy mg/m³
Gas flow g/sec
Smoke Emission mg/m³
I declare that this information is true, these products meet the requirements of Harmonised Standards and are fit for sale.
Signed on behalf of the manufacturer by Glyn Hughes, Design Engineer, at Winster, Derbyshire, England 28. Nov. 2017
Read these instructions! Use the right fuels!
This document, when completed by the installer, constitutes part of a 'Hearth Notice' for purposes of
Building Law. It must be left with the householder and placed where it can easily be found.
INSTALLED AT LOCATION:
BY:
EMERGENCY CONTACT:
I definitively assert that this installation is safe, has been lit and demonstrated to the
householder, conforms with current building regulations and with these instructions
SIGNED:
TO FIND A QUALIFIED INSTALLER, FUEL SUPPLIER or CHIMNEY SWEEP, CONTACT:
UK: The Solid Fuel Association, 7 Swanwick Court, Alfreton, Derbyshire DE55 7AS Tel:0845-601-4406 www.solidfuel.co.uk
RoI: Irish Nationwide Fireplace Organisation, 162 Capel Street, Dublin 1 Tel:01-801-5959 www.fireplace.ie
These Flavel stoves by BFM use the Portway No1 firebox, and may be used in smoke control areas when operated
strictly in accordance with these instructions and with Soliftec Smoke Advice Sheet No1
UK: Untreated wood logs or authorised smokeless fuels (Exempted from s20 of the Clean Air Act 1993)
RoI: Wood logs, smokeless fuels or peat briquettes, but not petroleum coke (Control of Atmospheric Pollution Regulations, 1970)
Trentham Lakes, Stoke on Trent, Staffordshire, England ST4 4TJ
www.bfm-europe.com Tel 01782 339000 Fax 01782 339009
(www.soliftec.com/smokeadvice.htm), when burning:
Solid Fuel Stoves Manual v4. Issued - 28/11/2017 (385)
Flavel Dalton No1a
SOLID FUEL HEATING STOVE
MULTI-FUEL MODEL
BFM Model No FN1MFDa
BFM / Portway / Flavel Dalton No1 Stove
Wood (Beech)
EN 13240:2001+A2 2004
1.15kg over 0.75hrs
Primary 0,
2nd 25mm
12 (0.05)
78.8
4.9
226
2700 mm ²
350mm
44
0.19
169
4.6
38
DATE:
1
Mineral Fuel (Anthracite)
0.76kg over 1.1hrs
Primary 30, 2nd 25mm
12 (0.05)
78.2
4.9
216
-
0.10
-
5.4
21
Flue Draught
measured on
commissioning:
Pa
WG
Fuel used on
commissioning
