Summary of Contents for SWIT NDI EFP
- Page 1 Multi-Camera Production System User Manual Thank you for purchasing SWIT products! Please read this manual carefully before using. Ver： C * NDI® is a registered trademark of Vizrt Group.
-
Page 2: Table Of Contents
Contents Statement Safety Precautions Introduction Features Index of Parts and Functions The Camera Adaptor The Intercom Control Panel Get Started 1. System Connection 2. IP setup Webpage Settings - Camera Adaptor 1. Channel - Camera Channel configuration 2. Channel - Return Video Source Select 3. -
Page 3: Statement
If users find problems during use or have suggestions and requirements for our products, please contact us by telephone, fax, email, etc. SWIT Electronics Co., Ltd. Address: 10 Hengtong Road, Nanjing Economic and Technological Development Zone, Nanjing 210038, P.R. China... -
Page 4: Safety Precautions
Please follow the safety precautions in this manual and operate in the correct way. Our company guarantees that this product can be used for a long time, but the following situations are not included: 1.Unauthorized disassembly, maintenance or replacement of parts and other operations. 2.Damage caused by accident, including but not limited to lightning, fire, exposure to rain or moisture. -
Page 5: Introduction
Introduction The SWIT NDI EFP system consists of camera adaptors EC-N200 (up to HD) or EC-N200-4K (up to 4K) and an intercom control panel ET-N80 with all the essential accessories for one-stop setup. The EC-N200 camera adaptor takes 3G-SDI input from cameras, encoded to an HD NDI stream over an IP network, and the EC-N200-4K camera adaptor takes 12G-SDI input, and encodes to 4K NDI. -
Page 6: Index Of Parts And Functions
Index of Parts and Functions The Camera Adaptor EC-N200 / EC-N200-4K （10） （1） （13） （2） （14） （3） SDI LOOP （4） （5） （15） （6） （7） SDI IN （12） （11） （8） （16） （17） （9） （18） (1) External TALLY output, 3.5mm jack (10) On-board TALLY light (2) Power ON/OFF switcher (11) V-mount battery plate (Gold mount option) (3) Volume Up *... -
Page 7: The Intercom Control Panel
Index of Parts and Functions The Intercom Control Panel ET-N80 （1） （2） （3） （4）（5）（6） （7）（8） （9） （10） （11）（12） （13） （14） （15） （16） （17） （18） (1) 3-pin XLR Microphone socket (12) Power ON/OFF switcher (2) Mic/Headset switching button (13) Press the pin to reset Press down to switch from Headset to Mic (14) AC 100-240V 50/60Hz input (3) 5-pin XLR Headset socket... -
Page 8: Get Started
Get Started 1. System Connection Connect all the camera adaptors and the intercom control panel to the NDI network. EC-N200/N200-4K HDMI output CAM 1 Local / Return video External TALLY light Camera SDI Headset Input 15mm Rod Rail Clamp 15mm Rod Rail Camera Base Install between camera and tripod More Camera Channels, NDI switcher, NDI monitor etc. -
Page 9: Ip Setup
Get Started 2. IP Setup Launch web browser on the computer, The camera adaptor and intercom control panel input 192.168.1.15X to enter configuration has factory default IP address: webpage of the camera adaptor, and input Device Default IP 192.168.1.101 to enter configuration EC-N200/N200-4K 192.168.1.15X webpage of the intercom control panel. -
Page 10: Webpage Settings - Camera Adaptor
Webpage Settings - Camera Adaptor 1. Channel - Camera Channel configuration No special characters accepted Click to enter IP address of assigned the webpage of Intercom Control Panel Intercom panel. No special characters accepted Status Info List Rename and Apply 2. -
Page 11: Channel - Ndi Group Setting
Webpage Settings - Camera Adaptor 3. Channel - NDI Group Setting Add, Delete, or Modify the name of NDI Group The current NDI Group will displayed below. Change and Apply 4. Channel - External Sources Add device IP address to find NDI sources from subnet. The current external device IP address will displayed below. -
Page 12: Channel - Advanced Settings
Webpage Settings - Camera Adaptor 5. Channel - Advanced Settings Select from: UDP (unicast) UDP (multicast) RUDP (unicast) TCP (single connection) TCP (multi-connection) Switch on NDI Discovery Server Add NDI Discovery Server IP address Change and Apply 6. Network - Change IP address Change address Mac address display Change and Apply... -
Page 13: User Admin - Log-In Id And Password Setting
Webpage Settings - Camera Adaptor 7. User Admin - Log-in ID and Password Setting Change Log-in User name 4 - 16 letters Re-type password Change and Apply 8. Firmware Update Check Serial Number, Model and NDI SDK Restart the device Reset the device Drag &... -
Page 14: Webpage Settings - Intercom Control Panel
Webpage Settings - Intercom Control Panel 1. Channel - Assign Camera Adaptors Assigned devices: Display color - The device is online Display grey - The device is offline Click to remove Search IP address or device name the device to add Camera adaptors Drag the devices to move positions (not available for the offline devices) Change and Apply 2. -
Page 15: Indicators
Indicators 1. The Camera Adaptor EC-N200/N200-4K Singal Indicator Status/Color Instruction Powered on OFF/ON Off Device not get powered No SDI input recognized SDI IN Green SDI input recognized No return NDI source recognized NDI RETURN Green Return NDI source recognized The camera channel is PGM On board Green... -
Page 16: Troubleshooting
Troubleshooting Phenomenon Possibility Reasons Solutions Camera adaptor not get powered Check power supply No NDI video Camera SDI not connected Check camera SDI cable from camera Camera SDI format not supported Check camera SDI format channels Network blocked Check IP address of the camera adaptor Didn’... -
Page 17: Specifications
Specification Camera Adaptor EC-N200 EC-N200-4K Input 3G-SDI ×1 12G-SDI ×1 3G-SDI loop ×1 12G-SDI loop ×1 Output HDMI 1.3 out ×1 HDMI 1.3 out ×1 High bandwidth NDI ×1 High bandwidth NDI ×1 2160P （60/50/30/23.98/29.97/25） 1080P （60/59.94/50/30/23.98/29.97/25） 1080P （60/59.94/50/30/23.98/29.97/25） 1080I （60/59.94/50） 1080I （60/59.94/50）... -
Page 18: Dimensions
Dimension EC-N200/N200-4K Unit:mm ET-N80 Unit:mm Packing List EC-N200/N200-4K ET-N80 Single ear headset (5-pin XLR) ×1 Single ear headset (5-pin XLR) ×1 15mm rail rods ×2 Swanneck Microphone (3-pin XLR) ×1 Camera 15mm rail base ×1 AC power cable ×1 Adaptor 15mm rail clamp ×1 External TALLY with cable and coldshoe ×1...
