BLZ-26-PZOVN PIZZA OVEN (NG/LP)

DANGER

- IF YOU SMELL GAS:

I) Shut off the gas supply to the appliance at its source.

2) Extinguish any open flames.

3) Open oven hood to release any accumulation of

gas vapor.

4) If a gas odor persists, keep away from your

appliance and contact your gas supplier or fire

department immediately.

INSTALLER: PLEASE LEAVE THESE INSTRUCTIONS WITH THE CONSUMER.

CONSUMER: PLEASE READ & RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE AND

USE & CARE GUIDE

ATTENTION:

BEFORE INSTALLING OR OPERATING.

- CONTACT INFORMATION -

Blaze Outdoor Products:

6620 Greenwell Springs Rd, Baton Rouge, LA 70805

Phone: 866-976-9510

CustomerService@BlazeGrills.com

BLAZEGRILLS.COM

Blaze Outdoor Products Instructional Book

Page | 1

WARNING

I) Do not store or use gasoline or other flammable

liquids or vapor in the vicinity of this or any other

appliance

2) A LP cylinder not connected for use shall not be

stored in the vicinity of this or any other appliances.

Table of Contents

Need help?

Do you have a question about the BLZ-26-PZOVN and is the answer not in the manual?

Questions and answers

Summary of Contents for Blaze BLZ-26-PZOVN

Page 1 USE & CARE GUIDE BLZ-26-PZOVN PIZZA OVEN (NG/LP) WARNING DANGER - IF YOU SMELL GAS: I) Do not store or use gasoline or other flammable I) Shut off the gas supply to the appliance at its source. 2) Extinguish any open flames.
Page 2: Table Of Contents
Lighting the Appliance iii. Manually Lighting the Main Burner 26 - 27 iv. Flame Adjustment 27 - 28 v. Pizza Stone Turnable and Rotisserie Instructions vi. Using the Rotisserie vii. Using the Rear Burner Blaze Outdoor Products Instructional Book Page | 2...
Page 3 IX. Cleaning your Appliance Fuel Conversion 31 - 33 i. Convertible Gas Regulator (if applicable) XI. Warranty Regestration 34 - 35 i. WARRANTY ON PARTS: Blaze Outdoor Products Instructional Book Page | 3...
Page 4: Oven Specifications
*Limited Lifetime on valves *1 Year – Ignition, electronics and Warranty lighting systems *Appliances must be registered within 30 days of purchase to validate this warranty. *See warranty section for details. Blaze Outdoor Products Instructional Book Page | 4...
Page 5: Unpacking Unit - Please Read Before Unpacking
Your Blaze Series Appliance comes pre-assembled and requires very little setup. We do however; recommend the use of professional help during the installation of your unit as improper installation may affect your warranty.
Page 6: General Safety And Installation Warnings
3. If odor continues, immediately call your gas supplier or your fire department. Safe operation of the BLAZE OVEN depends upon its proper installation. Only a qualified professional installer and service technician must perform adjustments and service of the oven. Proper location and proper use are essential to insure safe and continued trouble-free operation.
Page 7 Have an ABC Fire Extinguisher accessible at all times. Never attempt to extinguish a grease fire with water or other liquids. IMPORTANT: Consult the AHJ (Authority Having Jurisdiction) or local contractor of any uncertainty. Blaze Outdoor Products Instructional Book Page | 7...
Page 8 Ensure burners are properly seated on valve seat and burner mounting screws a securely mounted in place. For the rear burner ensure the burner is properly seat on the male post and the cotter pin is securely fastened Failure to do so could result in a fire and injury. Blaze Outdoor Products Instructional Book Page | 8...
Page 9 Never use charcoal or any other solid fuel in the oven . Never cook without the drip pan in place. Never operate this oven while under the influence of alcohol or drugs. Blaze Outdoor Products Instructional Book Page | 9...
Page 10 Do not leave the appliance unattended while in use.  Do not use water on grease fires! A violent steam explosion may result. Instead, smother the fire with a  multipurpose ABC extinguisher. Blaze Outdoor Products Instructional Book Page | 10...
Page 11: Location Of Appliance
Do not store combustible materials, gasoline or flammable liquids or vapors around the appliance. This Blaze oven must be located outdoors only. As with any gas appliance, harmful carbon monoxide is ...
Page 12: Electrical Safety And Installation Warnings
A minimum 6 foot of clearance is required between the countertop and the overhead construction. o When installed under a combustible overhead construction, the area above the Blaze appliance must be covered with a vent hood. The vent hood must provide protection for the combustible overhead construction.
Page 13: Gas Safety And Installation Warnings
Always check the Rating Plate to make sure the gas supply you are • hooking up to is the gas type the appliance is manufactured for. Check the rating label on the left hand outside of the unit. • RATING PLATE LOCATION Blaze Outdoor Products Instructional Book Page | 13...
Page 14 Ensure that the service supplying the appliance is fitted with a shut off valve conveniently positioned near the appliance and giving ease of access. The appliance and its individual shutoff valve must be disconnected from the gas supply piping system during any pressure testing of that system. Blaze Outdoor Products Instructional Book Page | 14...
Page 15: Gas Leak Warnings
 each use. Only the factory supplied hose and regulator must be used. Use only replacement regulator and hose assemblies specified by BLAZE OUTDOOR PRODUCTS. Checking for Gas Leaks Perform a leak test before each use. In addition, whenever the gas cylinder is connected to the regulator or whenever any part of the gas system is disconnected or replaced, perform a leak test.
Page 16 Open the valve (shut-off or ‘ON’ LP tank). Test for leaks by applying liquid soap solution to all joints. Bubbles forming indicate gas leak. NEVER USE AN OPEN FLAME TO CHECK FOR LEAKS Blaze Outdoor Products Instructional Book Page | 16...
Page 17: Gas Connections
An installer supplied gas shutoff valve must be installed in an accessible place.  ii. Liquid Propane (LP) Gas and Tank Requirements If your BLAZE Oven is for a Liquid Propane application, a L.P regulator set for 11” WC must be used • and is for use with LP gas only.
Page 18: Transporting And Storing Lp Gas
The LP Gas Cylinder must be in compliance with the specifications for LP‐Gas Cylinders of the US Department of Transportation or the National Standard of Canada, CAN/CSA‐ B339. The basic tank size is 12” in diameter and 18” High with a QCC‐1 cylinder valve. Blaze Outdoor Products Instructional Book Page | 18...
Page 19 To disconnect after you have used the appliance, turn the burner knobs to the OFF position. Close the Cylinder Valve by turning the Hand Wheel counter-clockwise until it stops. Disconnect the regulator from the LP cylinder after use. Blaze Outdoor Products Instructional Book Page | 19...
Page 20: Installing The Appliance In A Bbq Island
Check to make sure the appliance is level and is supported around the entire outside edge. If the appliance is not level or is unstable, use non-combustible shims under the outside lip to stabilize it. Blaze Outdoor Products Instructional Book Page | 20...
Page 21: Outdoor Kitchen Ventilation
(picture shown on page 23), and both the cabinets containing the gas appliances and the gas tank should be ventilated appropriately. If a plenum wall is undesirable, BLAZE offers a Propane tank drawer as an alternative. ****...
Page 22: Building Bbq Specifications And Instruction
*Ensure your outdoor kitchen is constructed out of non-combustible materials. *If your outdoor kitchen is constructed of combustible materials, an insulated jacket is REQUIRED. ALL BBQ ISLANDS MUST BE MANUFACTURED FROM “NON-COMBUSTIBLE” MATERIAL Blaze Outdoor Products Instructional Book Page | 22...
Page 23: Installation Diagrams
Installation Diagrams Installation Method for Low Pressure Gas Installation Diagram (5 Gallon LP tank shown) Source- (Natural Gas Regulator Shown) Blaze Outdoor Products Instructional Book Page | 23...
Page 24: First Time Operation
Button will turn "RED" when the main power is on. This will power the digital screen see below image. The screen is used for monitoring tempeture and controlling the turntable. Blaze Outdoor Products Instructional Book Page | 24...
Page 25: Lighting The Appliance
To shut off the burners, rotate the knob and turn to OFF. It is normal to hear a popping sound when the burners are turned off. Close the valve at the gas supply. Blaze Outdoor Products Instructional Book Page | 25...
Page 26: Manually Lighting The Main Burner
Wait five minutes until the gas clears before attempting to light it again. If the burner does not light after several attempts, immediately close all gas valves and consult an authorized service technician. Blaze Outdoor Products Instructional Book Page | 26...
Page 27: Flame Adjustment
LOW flame setting simply light the appliance on the LOW setting and adjust the screw located under the knob on the front of the valve using a flat head screwdriver as seen in the diagram below.) Low FLAME setting Blaze Outdoor Products Instructional Book Page | 27...
Page 28: Pizza Stone Turnable And Rotisserie Instructions
20 lb. cut of meat or poultry. If the shaft doesn’t run smooth, or makes a struggling sound, the meat is not properly balanced. Use the counterweight to balance any unevenness of the food on the rotisserie. Blaze Outdoor Products Instructional Book Page | 28...
Page 29: Using The Rotisserie
It's mainly designed for cooking pizza's or broiling foods. When cooking pizza it's necessary to use all three burners and to allow time for the oven the reach temperature before placing pizza dough onto the stone. Blaze Outdoor Products Instructional Book Page | 29...
Page 30 After the first use, it is normal for your appliance to become discolored in certain areas from the heat produced by the burners. A video for cleaning your oven is located on the blaze website to assist with the below instructions, www.blazegrills.com .
Page 31 Fuel Conversion CAUTION: This should only by performed by a licensed gas professional. (A video converting your blaze oven is located on the blaze website to assist with the below instructions, www.blazegrills.com Convertible Gas Regulator (if applicable): Currently all natural gas ovens are supplied with a regulator which is appropriate for use with natural gas or low-pressure propane.
Page 32 Blaze Outdoor Products Instructional Book Page | 32...
Page 33 Fuel (Gas) Conversion Instructions for Blaze Gas ovens . CAUTION: This should only by performed by a licensed gas professional. Main Burners: You must remove pizza stone and mounting plate to expose the main burners in the appliance. (unless they were removed prior to installation On the top rear of each burner is a set of screws.
Page 34 This warranty replaces the lifetime warranty offered with residential use when appliance is used in multi-user settings. If you have purchased a Blaze Series Oven you must register your product within 30 days of purchase to validate the warranty and maintain your original receipt to get parts for the appliance. You may register your appliance at www.blazegrills.com by selecting Support, and then selecting Register your...
Page 35 $120.00. All warranty claims are subject to manufacturer review. Please make sure to have your sales receipt information and product serial number located on the outside left side panel of the appliance. All replacement parts can be purchased through your local stocking dealer. Blaze Outdoor Products Instructional Book Page |35...
Page 36 26. pizza oven power bu�on 8. pizza oven gear drive motor cover 17. pizza oven LED lights 18. pizza oven rear burner 27. pizza oven ruglator 9. pizza oven rear burner cover Blaze Outdoor Products Instructional Book Page | 36...
Page 37 Locating the Product Serial Number: The serial number for your BLAZE appliance is located on the left hand outside of the Firebox (see picture on page 14.) You will need this number to properly register your appliance and activate coverage. Write this information in the space provided below for your records...
Page 38 Please take a minute to let us know what you bought. This makes sure we keep you up to date and have your info ready if you ever need warranty help! You may register your product electronically on the blaze website vs mailing in the below paperwork, blazegrills.com. First____________________________________...
Page 39 Mail To: Blaze Outdoor Products, Warranty Registration, 6620 Greenwell Springs Rd Baton Rouge, LA 70805 Blaze Outdoor Products Instructional Book Page | 39...
Page 40 GUIDE D 'UTILISATION E T D 'ENTRETIEN FOUR À P IZZA B LZ26PZOVN ( NG/LP) AVERTISSEMENT DANGER S I V OUS S ENTEZ D U G AZ : I) N e s tockez p as e t n 'utilisez p as d 'essence o u d 'autres p roduits i nflammables. I) ...
Page 41 Lighting the Appliance iii. Manually Lighting the Main Burner 26 - 27 iv. Flame Adjustment 27 - 28 v. Pizza Stone Turnable and Rotisserie Instructions vi. Using the Rotisserie vii. Using the Rear Burner Blaze Outdoor Products Instructional Book Page | 2...
Page 42 IX. Cleaning your Appliance Fuel Conversion 31 - 33 i. Convertible Gas Regulator (if applicable) XI. Warranty Regestration 34 - 35 i. WARRANTY ON PARTS: Blaze Outdoor Products Instructional Book Page | 3...
Page 43 3 0 j ours s uivant l 'achat p our valider c ette g arantie. *Voir l a s ection g arantie p our p lus de d étails. Blaze O utdoor P roducts I nstruction Page d e l ivre | 4...
Page 44 âle s ur l e b rûleur r epose d ans l a f ente c orrespondante à l 'arrière d u c hâssis d u g ril. Blaze O utdoor P roducts I nstruction...
Page 45 Lorsque v ous u tilisez v otre a ppareil B laze, v euillez l ire e t s uivre c es p récautions d e b ase : Blaze O utdoor P roducts I nstruction Page d e l ivre | 6...
Page 46 N'essayez j amais d 'éteindre u n f eu d e g raisse a vec d e l 'eau o u d 'autres l iquides. IMPORTANT : C onsultez l 'AHJ ( autorité a yant j uridiction) o u l 'entrepreneur l ocal e n c as d 'incertitude. Blaze O utdoor P roducts I nstruction Page d e l ivre | 7...
Page 47 à c e q ue l a t ige m âle à l 'arrière d u b rûleur r epose d ans l a f ente c orrespondante d u c hâssis d u f our. Le n onrespect d e c ette c onsigne p ourrait e ntraîner u n i ncendie e t d es b lessures. Blaze O utdoor P roducts I nstruction Page d e l ivre | 8...
Page 48 Ne c uisinez j amais s ans l a l èchefrite e n p lace. N'utilisez j amais c e g ril s ous l 'influence d e l 'alcool o u d e d rogues. Blaze O utdoor P roducts I nstruction Page d e l ivre | 9...
Page 49 N'utilisez p as d 'eau s ur l es f eux d e g raisse ! U ne v iolente e xplosion d e v apeur p eut e n r ésulter. A u l ieu d e c ela, é touffez l e f eu a vec u n extincteur A BC p olyvalent. Blaze O utdoor P roducts I nstruction Page d e l ivre | d ix...
Page 50 égulateur d e g az, l a b outeille d e g az e t t outes l es v annes d 'arrêt. L aisser u n a ccès d égagé à l'ensemble d u t uyau d 'alimentation e n g az e t d u r égulateur. Blaze O utdoor P roducts I nstruction Page d e l ivre | 1 1...
Page 51 "déclencher" l e d isjoncteur o u d ébrancher l 'appareil. R EMARQUE : U tilisez u n d isjoncteur d e 1 5 A a vec p rotection G FI. Blaze O utdoor P roducts I nstruction Page d e l ivre | 1 2...
Page 52 • V érifiez l 'étiquette s ignalétique s ur l a g auche à l 'extérieur d e l 'appareil. EMPLACEMENT D E L A P LAQUE S IGNALÉTIQUE Blaze O utdoor P roducts I nstruction Page d e l ivre | 1 3...
Page 53 L'appareil e t s a v anne d 'arrêt i ndividuelle d oivent ê tre d éconnectés d u s ystème d e t uyauterie d 'alimentation e n g az l ors d e t out t est d e p ression de c e s ystème. Blaze O utdoor P roducts I nstruction Page d e l ivre | 1 4...
Page 54 S ur l es s ystèmes L P, r etirez l a b outeille d e l 'appareil. A ppelez u n technicien d 'entretien d 'appareils à g az a gréé o u u n r evendeur d e G PL. Blaze O utdoor P roducts I nstruction Page d e l ivre | 1 5...
Page 55 NE J AMAIS U TILISER U NE F LAMME N UE P OUR V ÉRIFIER L ES F UITES Blaze O utdoor P roducts I nstruction Page d e l ivre | 1 6...
Page 56 FOUR o u t oute a utre f lamme n ue, a ppareil(s) p roduisant d e l a c haleur o u s ource d e c haleur Blaze O utdoor P roducts I nstruction Page d e l ivre | 1 7...
Page 57 ÉtatsUnis o u à l a n orme n ationale d u C anada, C AN/CSAB339. L a t aille d e b ase d u r éservoir e st d e 1 2" d e d iamètre e t 1 8" d e h aut avec u ne s oupape d e c ylindre Q CC1. Blaze O utdoor P roducts I nstruction Page d e l ivre | 1 8...
Page 58 7. F ermez l e r obinet d e l a b outeille e n t ournant l e v olant d ans l e s ens i nverse d es a iguilles d 'une m ontre j usqu'à c e q u'il s 'arrête. 8. D ébranchez l e r égulateur d e l a b outeille d e p ropane a près u tilisation. Blaze O utdoor P roducts I nstruction Page d e l ivre | 1 9...
Page 59 èvre e xtérieure p our l a s tabiliser. Blaze O utdoor P roducts I nstruction...
Page 60 Les é vents i nférieurs s ont p our l e G PL e t l es é vents s upérieurs sont p our l e g az n aturel ( exemples u niquement). Blaze O utdoor P roducts I nstruction Page d e l ivre | 2 1...
Page 61 TOUS L ES Î LOTS B ARBECUE D OIVENT Ê TRE F ABRIQUÉS À P ARTIR D E M ATÉRIAUX « NON C OMBUSTIBLES » Blaze O utdoor P roducts I nstruction Page d e l ivre | 2 2...
Page 62 Schéma d 'installation (Réservoir L P d e 5 g allons i llustré) Source ( régulateur d e g az n aturel i llustré) Blaze O utdoor P roducts I nstruction Page d e l ivre | 2 3...
Page 63 C ela a limentera l 'écran n umérique v oir l 'image c idessous. L 'écran e st u tilisé p our surveiller l a t empérature e t c ontrôler l e p lateau t ournant. Blaze O utdoor P roducts I nstruction Page d e l ivre | 2 4...
Page 64 8. P our é teindre l es b rûleurs, t ournez l e b outon e t m ettezle s ur O FF. I l e st n ormal d 'entendre u n c laquement l orsque les b rûleurs s ont é teints. 9. F ermez l a v anne d 'alimentation e n g az. Blaze O utdoor P roducts I nstruction Page d e l ivre | 2 5...
Page 65 Si l e b rûleur n e s 'allume p as a près p lusieurs t entatives, f ermez i mmédiatement t outes l es v annes d e g az et c onsultez u n t echnicien d e s ervice a gréé. Blaze O utdoor P roducts I nstruction Page d e l ivre | 2 6...
Page 66 à l 'aide d 'un t ournevis à t ête p late c omme i ndiqué s ur l e s chéma c idessous.) Réglage F LAMME b asse Blaze O utdoor P roducts I nstruction Page d e l ivre | 2 7...
Page 67 é quilibrée. U tilisez l e contrepoids p our é quilibrer t oute i rrégularité d es a liments sur l a r ôtissoire. Blaze O utdoor P roducts I nstruction Page d e l ivre | 2 8...
Page 68 'atteindre l a t empérature a vant d e p lacer l a p âte à p izza s ur l a p ierre. Blaze O utdoor P roducts I nstruction Page d e l ivre | 2 9...
Page 69 3) L e b rûleur c hauffe d e m anière i négale. 4) L e b rûleur f ait d es b ruits d e c laquement. Blaze O utdoor P roducts I nstruction Page d e l ivre | 3 0...
Page 70 Quelle q ue s oit l a c onfiguration, n 'oubliez p as d e t oujours v érifier l es f uites d e g az u ne f ois l e t ravail t erminé ( voir 3 . V érification des f uites d e g az). Blaze O utdoor P roducts I nstruction Page d e l ivre | 3 1...
Page 71 Machine Translated by Google Blaze O utdoor P roducts I nstruction Page d e l ivre | 3 2...
Page 72 à t ête e t r éinstallez l e b rûleur p our r evérifier l 'apparence d e l a f lamme. R épétez s i n écessaire. Blaze O utdoor P roducts I nstruction Page d e l ivre | 3 3...
Page 73 V euillez a ppeler B laze O utdoor P roducts p our p lus d 'informations s ur l 'installation c orrecte d e l 'appareil à g az. Blaze O utdoor P roducts n e s era p as r esponsable e n v ertu d e c ette g arantie o u d e t oute g arantie i mplicite p our l es d ommages ...
Page 74 érie d u p roduit s e t rouvent s ur l e p anneau l atéral e xtérieur g auche d e l 'appareil. T outes l es p ièces d e r echange peuvent ê tre a chetées a uprès d e v otre r evendeur l ocal. Blaze O utdoor P roducts I nstruction Page d e l ivre | 35...
Page 75 Machine Translated by Google dix. 1. G rille d e f our à p izza * 2 P C 2 . 19. p lateau d e f our à p izza 10. B rûleur p rincipal d u f our à p izza * 2 P C 1 1. Boîtier ...
Page 76 Nom d u r evendeur B laze : Adresse d u r evendeur B laze : Numéro d e t éléphone d u r evendeur B laze : Blaze O utdoor P roducts I nstruction Page d e l ivre | 3 7...
Page 77 Quel e st l e n uméro d e s érie d u p roduit B laze ? _______________________________________________________________________ ____ Où a vezvous a cheté v otre p roduit B laze ? _________________________________________________________________________________________________________________________ _ _ _______________ Blaze O utdoor P roducts I nstruction Page d e l ivre | 3 8...
Page 78 Machine Translated by Google Courrier à : Blaze O utdoor P roducts, e nregistrement d e l a g arantie, 6 620 G reenwell S prings R d Bâton R ouge, L A 7 0805 Blaze O utdoor P roducts I nstruction...
