TecTecTec BPROWILD Quick Start Manual

BPROWILD
10 X 42 MM BINOCULARS
H
A
B
D
E

INSTRUCTIONS FOR OPTIMAL USE

1. Remove all rubber protection from the optics as pictured.
2. The ocular lenses (1) have two levels. Use the first level
if you are wearing eyeglasses.
3. Always aim your objectives in the direction of
magnification before bringing them to your field of view.
4. Adjust the orientation of the center hinge manually to
make it fit with your interocular morphology.
5. With your naked eye, aim for an observation point,
then bring the binoculars up to view that same point.
6. Adjust the ocular lenses (1) to level one or two as necessary.
7. Close your right eye and open the left. Adjust the center
adjustment dial (2) to focus the lenses on your target
until you get a clear view.
8. Close your left eye and open the right. Continue the adjustment
by rotating the diopter wheel (3) until you have a crystal clear view.
9. Adjust the magnification with the center dial depending on the distance to the target.
10. For prolonged use, consider connecting the neck strap to your binoculars to free your hands.
11. By unscrewing the cover (4) at the center you will have access to 1/4" thread where a tripod can be affixed.
12. Dry your binoculars quickly and completely after contact with a liquid without using compressed air.
NEVER OBSERVE THE SUN OR ANY OTHER LIGHT SOURCE DIRECTLY USING YOUR OPTICS.
G
C
F
REGISTER TO ACTIVATE
YOUR WARRANTY
Scan the QR Code or visit:
https://tectectec.com/warranty
THANK YOU
for choosing TecTecTec !®
Any questions, suggestions, or concerns with
this product, can be directed to: cs@tectectec.com
WHAT'S INCLUDED
A) x 1 TecTecTec ! BPROWILD 10 x 42 MM Binoculars
B) x 1 Ocular Lens Caps
C) x 1 Neck Strap
D) x 1 Smartphone and Tripod Adapter
E) x 2 42mm Objective Lens Caps
F) x 1 Microfiber Cleaning Cloth/Pouch
G) x 1 Carrying Case with Shoulder Strap and Belt Loop
H) x 1 Box and Instruction Booklet
3
4
1
2
1
