Chapter 1. Getting

Started
Getting Started
Thank you for purchasing the MD-5000 M-ATX
mainboard. The MD-5000 mainboard is based on SiS
North Bridge & 963 South Bridge chipsets for optimal system
efficiency. Designed to fit the advanced Intel
processors in the 478 pin package, the MD-5000
mainboard delivers a high performance and professional desktop
platform solution.
Getting Started
648
®
Pentium 4/Celeron
®
1-1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MD-5000 and is the answer not in the manual?

Questions and answers

Related Manuals for Medion MD-5000

Summary of Contents for Medion MD-5000

  • Page 1: Chapter 1. Getting

    Chapter 1. Getting Started Getting Started Thank you for purchasing the MD-5000 M-ATX mainboard. The MD-5000 mainboard is based on SiS ® North Bridge & 963 South Bridge chipsets for optimal system efficiency. Designed to fit the advanced Intel Pentium 4/Celeron ®...

  • Page 2: Mainboard Specifications

    All manuals and user guides at all-guides.com MD5000 M-ATX Mainboard Mainboard Specifications Supports Socket 478 for P4/Celeron processors (Willimate and Northwood core) with 400/533 MHz Core Frequency from 1.3 GHz to 2.8 GHz and up Chipset 648 chipset ® - Supports Intel Pentium 4 processors with data transfer rate up to 533 MHz - Supports 64-bit high performance DDR333+/DDR333/DDR266 memory controller - Supports AGP 8X/4X interface...
  • Page 3 All manuals and user guides at all-guides.com Getting Started - 1 parallel port - Audio * 3 in vertical for 6 channels Line-out, 2 in vertical for MIC & Line- - 1 standard 1394 connector - 1 mini 1394 connector - 5 USB ports (3 front + 2 rear) - 1 RJ-45 Lan Jack (optional) - PS2 KB/Mouse...

  • Page 4: Mainboard Layout

    All manuals and user guides at all-guides.com MD-5000 M-ATX Mainboard Mainboard Layout Top : mouse Bottom: keyboard JPW1 CPUFAN1 Top : LPT Bottom: COM A SPDIF in SPDIF out T: RJ45 LAN jack B: USB ports IEEE1394 Port Mini IEEE...

  • Page 5: Chapter 2. Hardware

    All manuals and user guides at all-guides.com Hardware Setup Chapter 2. Hardware Setup Hardware Setup This chapter tells you how to install the CPU, memory modules, and expansion cards, as well as how to setup the jump- ers on the mainboard. Also, it provides the instructions on con- necting the peripheral devices, such as the mouse, keyboard, etc.

  • Page 6: Quick Components Guide

    All manuals and user guides at all-guides.com MD-5000 M-ATX Mainboard Quick Components Guide JPW1, p.2-9 CPU, p.2-3 CPUFAN1, p.2-17 DDR DIMMs, p.2-7 CONN1, p.2-9 Back Panel FDD1, p.2-15 I/O, p.2-10 J7, p.2-26 IDE1 & IDE2 p.2-16 J9, p.2-26 AGP Slot, p.2-28 JSPDIF1, p.2-23...

  • Page 7: Central Processing Unit (Cpu)

    All manuals and user guides at all-guides.com Hardware Setup Central Processing Unit: CPU ® ® The mainboard supports Intel Pentium 4 processor in the 478 pin package. The mainboard uses a CPU socket called PGA478 for easy CPU installation. When you are installing the CPU, make sure the CPU has a heat sink and a cooling fan attached on the top to prevent overheating.

  • Page 8: Cpu Installation Procedures For Socket 478

    All manuals and user guides at all-guides.com MD-5000 M-ATX Mainboard CPU Installation Procedures for Socket 478 Please turn off the power and unplug the power cord before Open Lever installing the CPU. Pull the lever sideways away Sliding 90 degree Plate from the socket.
  • Page 9 All manuals and user guides at all-guides.com Hardware Setup Memory The mainboard provides 2 slots for 184-pin DDR SDRAM DIMM (Double In-Line Memory Module) modules and supports the memory size up to 2GB. You can install DDR200/266/333 modules on the DDR DIMM slots (DIMM 1~2).

  • Page 10: Dimm Module Combination

    All manuals and user guides at all-guides.com MD-5000 M-ATX Mainboard DIMM Module Combination Install at least one DIMM module on the slots. You can install either single- or double-sided modules in any order to meet your own needs. Memory modules can be installed in any combination as follows:...

  • Page 11: Power Supply

    All manuals and user guides at all-guides.com Hardware Setup Power Supply The mainboard supports ATX power supply for the power system. Be- fore inserting the power supply connector, always make sure that all compo- nents are installed properly to ensure that no damage will be caused. ATX 20-Pin Power Connector: CONN1 This connector allows you to connect to an ATX power supply.

  • Page 12: Back Panel

    All manuals and user guides at all-guides.com MD-5000 M-ATX Mainboard Back Panel The back panel provides the following connectors: 6 Channel L-out Parallel (Optional) Mouse L-in IEEE1394 Keyboard SPDIF- SPDIF- COM A Ports Mouse Connector ® The mainboard provides a standard PS/2 mouse mini DIN connector ®...

  • Page 13: Keyboard Connector

    All manuals and user guides at all-guides.com Hardware Setup Keyboard Connector ® The mainboard provides a standard PS/2 keyboard mini DIN connec- ® ® tor for attaching a PS/2 keyboard. You can plug a PS/2 keyboard directly into this connector. Pin Definition SIGNAL DESCRIPTION...

  • Page 14: Parallel Port Connector: Lpt1

    All manuals and user guides at all-guides.com MD-5000 M-ATX Mainboard Parallel Port Connector: LPT1 The mainboard provides a 25-pin female centronic connector as LPT. A parallel port is a standard printer port that supports Enhanced Parallel Port (EPP) and Extended Capabilities Parallel Port (ECP) mode.

  • Page 15: Lan Jack (Optional)

    All manuals and user guides at all-guides.com Hardware Setup RJ-45 LAN Jack (Optional) The mainboard provides a RJ-45 connector that allows your computer to be connected to a network environment. Signal Description Transmit differential pair Transmit differential pair Receive differential pair Not used Not used Receive differential pair...
  • Page 16 All manuals and user guides at all-guides.com MD-5000 M-ATX Mainboard IEEE1394 Ports The mainboard provides two IEEE 1394 ports. The mini IEEE1394 port is designed for you to connect the IEEE1394 device with external power. The standard IEEE1394 port connects to IEEE1394 devices without external power.
  • Page 17 All manuals and user guides at all-guides.com Hardware Setup Serial Port Connector: COM A The mainboard offers one 9-pin male DIN connector as serial port COM A. The port is a 16550A high speed communication port that sends/receives 16 bytes FIFOs. You can attach a serial mouse or other serial devices directly to the connector.

  • Page 18: Floppy Disk Drive Connector: Fdd1

    All manuals and user guides at all-guides.com MD-5000 M-ATX Mainboard Connectors The mainboard provides connectors to connect to FDD, IDE HDD, case, modem, LAN, USB Ports, IR module and CPU/System FAN. Floppy Disk Drive Connector: FDD1 The mainboard provides a standard floppy disk drive connector that supports 360K, 720K, 1.2M, 1.44M and 2.88M floppy disk types.

  • Page 19: Hard Disk Connectors: Ide1 & Ide2

    All manuals and user guides at all-guides.com Hardware Setup Hard Disk Connectors: IDE1 & IDE2 The mainboard has a 32-bit Enhanced PCI IDE and Ultra DMA 33/66/ 100/133 controller that provides PIO mode 0~4, Bus Master, and Ultra DMA 33/66/100/133 function. You can connect up to four hard disk drives, CD- ROM, 120MB Floppy (reserved for future BIOS) and other devices.

  • Page 20: Fan Power Connector: Cpufan1

    All manuals and user guides at all-guides.com MD-5000 M-ATX Mainboard Fan Power Connector: CPUFAN1 The CPUFAN1 (processor fan) supports system cooling fan with +12V. It supports a three-pin head connector. When connecting the wire to the connector, always take note that the red wire is the positive and should be connected to the +12V, the black wire is Ground and should be connected to GND.
  • Page 21 All manuals and user guides at all-guides.com Hardware Setup Front Panel Connector: F_P1 The mainboard provides one front panel connector for electrical con- nection to the front panel switches and LEDs. PS-ON PWR_LED HDD_LED Reset F_P1 2-19...

  • Page 22: Front Panel Audio Connector: Jaudio1

    All manuals and user guides at all-guides.com MD-5000 M-ATX Mainboard Front Panel Audio Connector: JAUDIO1 The JAUDIO1 front panel audio connector allows you to connect to the ® front panel audio and is compliant with Intel Front Panel I/O Connectivity Design Guide.

  • Page 23: Front Usb Connector: Jusb1

    All manuals and user guides at all-guides.com Hardware Setup Front USB Connector: JUSB1 The mainboard provides one front Universal Serial Bus connector for users to connect USB devices. JUSB1 JUSB1 Pin Definition Description Description Power Power SGND SGND Power Power 2-21...

  • Page 24: Cd-In Connector: Jcd1

    All manuals and user guides at all-guides.com MD-5000 M-ATX Mainboard CD-In Connector: JCD1 The connector is for CD-ROM audio connector. Audio Connector: JVEDIO1 This connector allows you to connect to a TV Tuner Card. JCD1 JVEDIO1 VIDEO-L VIDEO-R 2-22...
  • Page 25 All manuals and user guides at all-guides.com Hardware Setup SPDIF Connector: JSPDIF1 The connector is used to connect an optional bracket for SPDIF (Sony & Philips Digital Interconnect Format) digital audio transmission. JSPDIF1 JSPDIF1 Pin Definition Description Description VCC5 VCC3 SPDIF-O SPDIF-I 2-23...
  • Page 26 All manuals and user guides at all-guides.com MD-5000 M-ATX Mainboard IEEE 1394 Connector: J7 (Optional) The mainboard provides one IEEE1394 connector with housing that allows you to connect optional IEEE 1394 ports. Pin Definition SIGNAL SIGNAL IEGND TPA0- TPA0+ Power...
  • Page 27 All manuals and user guides at all-guides.com Hardware Setup Joystick/Game Connector: J9 (Optional) You can connect a joystick or game pad to this connector. J9 Pin Definition Description Description FVCC5 (power) Key pin 2-25...

  • Page 28: Clear Cmos Jumper: Jbat1

    All manuals and user guides at all-guides.com MD-5000 M-ATX Mainboard Jumpers The motherboard provides the following jumpers for you to set the computer’s function. This section will explain how to change your motherboard’s function through the use of jumpers. Clear CMOS Jumper: JBAT1 There is a CMOS RAM on board that has a power supply from external battery to keep the data of system configuration.

  • Page 29: Agp (Accelerated Graphics Port) Slot

    All manuals and user guides at all-guides.com Hardware Setup Slots The motherboard provides one AGP slot and three 32-bit PCI bus slots. AGP Slot PCI Slots AGP (Accelerated Graphics Port) Slot The AGP slot allows you to insert the AGP graphics card. AGP is an interface specification designed for the throughput demands of 3D graphics.

  • Page 30: Pci Interrupt Request Routing

    All manuals and user guides at all-guides.com MD-5000 M-ATX Mainboard PCI Interrupt Request Routing The IRQ, acronym of interrupt request line and pronounced I-R-Q, are hardware lines over which devices can send interrupt signals to the microprocessor. The PCI IRQ pins are typically connected to the PCI bus INT...
