Summary of Contents for CastleNet EBM522
- Page 1 Quick Installation Guide For EBM522 Mesh Wi-Fi Router...
-
Page 2: Package Contents
EBM522 Mesh Wi-Fi Router Quick Installation Package Contents RJ-45 Cable Quick Installation Guide For EBM 552 M esh Wi-Fi Router Power Adapter x 3 EBM522 x 3 (12V/1.5 A) A quick look at EBM522 Reset Button and hold Press 5 sec(s) Set device to default status. -
Page 3: Led Indicators
EBM522 Mesh Wi-Fi Router Quick Installation LED Indicators There are two LEDs located on the front panel, providing status information to the user. LED1 Status Description System ready, but Internet is not Slowly Flashing Green connected Internet is connected System working fine... - Page 4 EBM522 Mesh Wi-Fi Router Quick Installation Setting up your EBM522 This chapter describes the proper steps for connecting your Mesh Wi-Fi router. Please be sure to follow the steps below. Using RJ-45 cable to connect your modem’s LAN port to your device’s Step a: WAN port.
-
Page 5: Connecting To The Device
EBM522 Mesh Wi-Fi Router Quick Installation Connecting to the device There is a label pasted to the bottom of EBM522. In that label, you can obtain Wi-Fi access information. Please note, following label is just an example, each EBM522 has its own label and setting value. Please follow your label information to access your EBM522 Mesh Wi-Fi system. - Page 6 Download the router App to manage your Wi-Fi Mesh home network. To find the app, scan the QR code on the right side or search for CastleNet Mesh in the Google Play Store or the Apple App Store. Launch the CastleNet Mesh app on your cell phone and follow the instructions step by step.
- Page 7 EBM522 Mesh Wi-Fi Router Quick Installation Adding agent to your Mesh Wi-Fi system Power ON another device. Wait for a moment, press "Next" when the Status LED becomes solid red. Press “Sync” button on both controller and agent device. On boarding process may take up several minutes, please wait a moment.
- Page 8 EBM522 Mesh Wi-Fi Router Quick Installation Accessing the App Management Now you can see your Wi-Fi environment information on the app, also configure advanced functions, such as guest network, parental control, QoS, and monitor current traffic flow.
- Page 9 EBM522 Mesh Wi-Fi Router Quick Installation Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 10 EBM522 Mesh Wi-Fi Router Quick Installation FCC RF Radiation Exposure Statement: This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. FCC Statement This device complies with Class B Part 15 of the FCC Rules. The device generates, uses and can radiate radio frequency energy and, if not installed and used as instructed, may cause harmful interference to radio communication.
- Page 11 EBM522 Mesh Wi-Fi Router Quick Installation Seller may charge Buyer a fee (including travel expenses, if needed) to cover the cost of evaluation if the evaluation shows that the items are not defective or that they are defective for reasons beyond the scope of this warranty.The Seller makes no warranty concerning components or accessories not manufactured by it.
