Owner's Manual
Over The Range M crowave Oven
i
Household Use Only
Model No.
NN-SG1 8S
3
ATTACHED INSTALLATION INSTRUCTION
PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE USING THIS PRODUCT,
AND SAVE THIS MANUAL FOR FUTURE USE.
Inverser le manuel pour lire les instructions en français.
For assistance, please contact us via the web at:
http://www.panasonic.ca/english/support
(Canada only)
16170000A72269
Printed in China
Panasonic Canada Inc. 2019
Advertisement
Table of Contents
Related Manuals for Panasonic NN-SG138S
Summary of Contents for Panasonic NN-SG138S
- Page 1 PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE USING THIS PRODUCT, AND SAVE THIS MANUAL FOR FUTURE USE. Inverser le manuel pour lire les instructions en français. For assistance, please contact us via the web at: http://www.panasonic.ca/english/support (Canada only) 16170000A72269 Printed in China Panasonic Canada Inc. 2019...
-
Page 3: Table Of Contents
CONTENTS Safety Information IMPORTANT SAFETY INSTRUCTIONS ............................... 3-5 Installation Instructions ............................................5-6 ......................................Grounding Instructions Food Preparation ....................................7-8 Cook ware guide......................................9 Oven Components Diagram .................................10 Control Panel ......................................11 Operation Using the Microwave for the First Time ............................12 Setting the Clock .......................................12 Setting the Child Safety Lock ................................12 Setting Light .......................................13... -
Page 4: Important Safety Instructions
(c) DO NOT operate the oven if it is damaged. It is particularly Thank you for purchasing a Panasonic Microwave Oven Your microwave oven is a cooking appliance and you should use as much care as you use with a stove or any other cooking appliance. - Page 5 IMPORTANT SAFETY INSTRUCTIONS (continued) 10. DO NOT allow children to use this appliance, unless closely supervised by an adult. DO NOT assume that because a child has mastered one cooking skill he/she can cook everything. 11. DO NOT operate this appliance if it has a damaged cord or plug, if it is not working properly, or if it has been damaged or dropped. 12.
-
Page 6: Installation Instructions
3. DO NOT dry clothes, newspapers or other 2. DO NOT operate the oven without the Glass Tray fully engaged materials in the oven, or use newspaper or on the drive hub. Improper cooking or damage to the oven paper bags for cooking. could result. -
Page 7: Grounding Instructions
The plug must be plugged into an outlet that is properly installed result in a re or oven damage. Using a lower voltage will cause and grounded. slow cooking. Panasonic is NOT responsible for any damages • Plug into properly installed and grounded three-prong resulting from the use of the oven with any voltage other than outlet. -
Page 8: Food Preparation
Food Preparation Follow these Safety Precautions when cooking in your oven. 4) FOODS WITH NONPOROUS SKINS IMPORTANT • DO NOT COOK / REHEAT WHOLE EGGS, WITH OR WITHOUT THE SHELL. Proper cooking depends upon the power, the time setting and quantity of food. If you use a smaller portion than Steam buildup in whole recommended but cook at the time for the recommended eggs may cause them... - Page 9 Food Preparation (continued) 6) PAPER TOWELS / CLOTHS • DO NOT use paper towels or cloths that contain a synthetic fiber woven into them. The synthetic fiber may cause the towel to ignite. Use paper toweling under supervision. 7) BROWNING DISHES / OVEN COOKING BAGS •...
-
Page 10: Cookware Guide
Cookware Guide This section answers the question, “Can I use in the Microwave?” Aluminum Foil Glass Jars Check Microwave Safe manufacturers’ directions for recommended uses. Some microwave safe It is not recommended No. Most glass jars are not plastic containers are not suitable for cooking to use. -
Page 11: Oven Components Diagram
Oven Components Diagram See-through Oven Window Waveguide Cover (do not remove) Oven Light Glass Tray (Turntable) Oven Air vent (Vent Grille is removable and can be cleaned, see page 25) Glass Tray Panel Grease Filter (Grease lter is removable and can be cleaned, see page 25) Door Safety Lock System Warning Label... -
Page 12: Control Panel
Control Panel Defrost 9 10 11 1. 1. Display Window Number Pads Popcorn Pad Beverage Pad Potato Pad Veggies Pad Frozen Entrees Pad Sensor Reheat Pad Chicken Pad Fish Pad Pasta Pad Power Level Pad Quick 30 Pad Auto Defrost Pad Light On/Off Pad Vent Motor Pad Clock/Timer Pad... -
Page 13: Operation
Operation Using the Microwave Setting the Clock Setting the Child for the First Time Safety Lock Display Window When the time of day appears in the display, press Start three times; Current time will appear in the display. Press Clock/Timer once, then Plug into a properly grounded press number pad to input electrical outlet. -
Page 14: Setting Light
Operation (continued) Setting Fan Setting Light Setting Turntable On/Off For best cooking results, leave the turntable on. It can be turned off for large dishes. Press Turntable On/Off pad to This feature allows you to turn the turntable on or off. control the brightness of on or off. -
Page 15: Cooking
Operation (continued) Cooking Setting the Timer DO NOT OVERCOOK: This oven requires less time to cook than older units. Overcooking will cause food to dry out and may cause a fire. A microwave oven’s cooking power tells you the amount of microwave power available for cooking. -
Page 16: Potato
Operation (continued) Popcorn Beverage Potato This feature allows you to This feature allows you to This feature allows you to pop popcorn without setting reheat beverage without setting cook potato without setting weight and time. The oven weight and time. The oven weight and time. -
Page 17: Sensor Menu
Operation (continued) Sensor Menu-Veggies Sensor Menu-Chicken Sensor Menu-Sensor Reheat Press Sensor Reheat to choose reheat menu. Press Chicken once. Press Veggies once for fresh vegetables.Twice for frozen vegetables. Reheat Press Start . Chicken Press Start appears in the display appears in the display window. - Page 18 Operation (continued) Sensor Menu-Frozen Entree Sensor Menu-Fish Sensor Menu-Pasta Press Frozen Entree once. Press Fish once. Press Pasta once. Frozen entree Press Start appears in the display Fish window. Press Start Press Start Pasta appears in the display appears in the display window window NOTES:...
-
Page 19: Auto Defrost
Operation (continued) The auto defrost feature provides you Quick 30 Auto Defrost with the best defrosting method for (Set or add cooking time in 1. MEAT frozen foods. The cooking guide 30 seconds increments) 2. POULTRY will show you which defrost sequence 3. -
Page 20: Placement Of The Roller Ring
Operation (continued) Placement of the Roller Ring For best cooking Results 1-Level cooking Before using the microwave oven, be sure the Roller Ring is Food microwaves best when placed onto the turntable, with properly installed. Incorrect installation can result in improper turntable on (rotating). -
Page 21: Food Characteristics
Food Characteristics Food Characteristics Cooking Techniques Bone and Fat Piercing Both bone and fat affect cooking. Bones may cause Foods with skins or membranes must be pierced, scored or have a strip of irregular cooking. Meat next to the tips of bones may skin peeled before cooking to allow steam to escape. - Page 22 Food Characteristics (continued) Stirring Cook all food to these minimum internal temperatures as measured Stirring is usually necessary during microwave cooking. Always bring with a food thermometer before removing food from oven. For the cooked outside edges toward the center and the less cooked center reasons of personal preference, you may choose to cook food at higher portions toward the outside of the dish.
-
Page 23: Care And Cleaning Of Your Microwave Oven
Care and Cleaning of Your Microwave Oven Operation (Continued) Helpful Hints An occasional thorough wiping with a solution of baking soda and water keeps the inside fresh. Be sure the power is off before cleaning any part of this microwave oven. How to Clean the Inside Walls, Floor, Inside Window, Metal and Plastic Parts on the Door... - Page 24 Care and Cleaning of Your Microwave Oven (continued) How to Clean the Outside We recommend against the use of spray cleaners and using cleaners with ammonia or alcohol, as they can damage the appearance of the microwave oven. If you choose to use a common household cleaner, first apply the cleaner directly to a clean cloth, then wipe the soiled area.
- Page 25 Care and Cleaning of Your Microwave Oven (continued) About the exhaust feature Vent FAN The vent fan has two metal reusable vent filters. Models that recirculate air back into the room also use a charcoal filter. Grease Filters The metal filters trap grease released by foods on the cooktop.
- Page 26 Care and Cleaning of Your Microwave Oven (continued) Removing and Cleaning the Filters To remove, slide them to the rear using the tabs. Pull down and out. To clean the vent filters, soak them and then swish around in hot water and detergent. Don’t use ammonia or ammonia products because they will darken the metal.
-
Page 27: Shop Accessories
Bottom Tab Ensure bottom tabs are seated as shown. Shop Accessories Purchase Parts, Accessories and Instruction Books online for all Panasonic Products by visiting our Web Site at: shop.panasonic.ca Parts Available to Order Instructions/Owner’s Manual (this book) ............. 16170000A72269 16170000A72267 Installation Instructions .................. -
Page 28: Before Requesting Service
Before Requesting Service See below before calling for service, as most problems can easily be remedied by following these simple solutions: Problem Solution Some radio, TV, Wi-Fi, cordless telephone, baby monitor, blue tooth or other wireless equipment interference might occur when you cook with the The oven causes TV microwave oven. -
Page 29: Warranty
In-home Service will be carried out only to locations accessible by roads and within 50 km of an authorized Panasonic service facility. This warranty is given only to the original purchaser, or the person for whom it was purchased as a gift, of a Panasonic brand product men- tioned above sold by an authorized Panasonic dealer in Canada and purchased and used in Canada, which product was not sold “as is”, and... -
Page 30: Speci Cations
Specifications Power Source 120 V , 60 Hz Power Consumption 1,550 W 1,000 W Cooking Power* ⁄ ” x 17 / ” x 16 / ” Outside Dimensions (W x H x D) (606 mm x 442 mm x 426 mm) ⁄...
