EVEREST REFRIGERATION ECF Series Owner's Manual

Nitro cold brew coffee dispensers

Hide thumbs

Table Of Contents

Quick Links

Download this manual

Nitro Cold Brew

Coffee Dispensers

Owner's Manual

ECF1

www.EVERESTref.com

Table of Contents

Need help?

Do you have a question about the ECF Series and is the answer not in the manual?

Questions and answers

Summary of Contents for EVEREST REFRIGERATION ECF Series

Page 1 Nitro Cold Brew Coffee Dispensers Owner’s Manual ECF1 www.EVERESTref.com...
Page 2 THIS PAGE INTENTIONALLY LEFT BLANK...
Page 3: Table Of Contents
Nitro Cold Brew Coffee Dispensers ECF1 Contents 1. Hydrocarbon Guidelines 2. Installation Instructions 3. General Safety 4. Electrical Safety 5. Operation 6. Care and Maintenance 7. Troubleshooting Guide 8. Warranty Information Everest Owner’s Manual...
Page 4: Hydrocarbon Guidelines
1. Hydrocarbon Guidelines This section applies to R290 Hydrocarbon units only. To identify the refrigerant type, see the data plate in the cabinet interior. WARNING - THIS UNIT USES R290, A HYDROCARBON, PROPANE REFRIGERANT THAT IS ENVIRONMENTALLY FRIENDLY BUT IS ALSO HIGHLY FLAMMABLE AND EXPLOSIVE. PLEASE READ THIS MANUAL CAREFULLY AND FOLLOW ALL SAFETY PRECAUTIONS CONTAINED HEREIN TO AVOID THE RISK OF FIRE OR EXPLOSION.
Page 5 • General service and repairs must be performed in well-ventilated areas. • General service and repairs must be performed only by professionals authorized by Everest Refrigeration. • Component shall be replaced with Everest-issued, like components to minimize the risk of possible ignition resulting from incompatible parts or improper repairs.
Page 6: Installation Instructions
2. Installation Instructions This section applies to all Everest products. Correct installation ensures proper performance and longevity of your appliance. Professional installation by a trained refrigeration technician and electrician is recommended. Warranty is void if the following guidelines are not met. 1.
Page 7 Product Load Level & Shelf Placement ECF Series Front View Air Vent Side View Airflow Front Rear Installation Instructions...
Page 8 Draft Assembly - Single Faucet Faucet Handle Nitrogen Regulator Tower Cover Faucet Tower Nitrogen Tower Tank Gasket Air Hose Coffee Line All par ts labeled come standard with the Nitro Cold Brew Dispenser Installation Instructions...
Page 9 Draft Assembly - Dual Faucet ( Optional Setup ) Faucet Handles Nitrogen Regulator Tower Cover Faucet Air Distributor Tower Tower Gasket Nitrogen Tank Coffee Line Air Hose All parts labeled on page 5; Draft Assembly - Single Faucet come standard with the Nitro Cold Brew Dispenser Installation Instructions...
Page 10 Draft Assembly Instructions 1) Position the base of the draft tower so that the tower shaft and screw holes align perfectly with the corresponding openings on the worktop. Feed the coffee line through the main opening. 2) Secure the base of draft tower to the work top using the provided screws. Installation Instructions...
Page 11 Draft Assembly Instructions ( Continued ) Insulation (Foam) 3) Take the cold air hose and insert the flat end into the air baffle located in the cabinet interior. Insulation (Foam) Insulation (Foam) Insulation (Foam) Insulation (Foam) Insulation (Foam) Hook Hook Hook 4) Remove the top cap and insulation pad from 5) Take the cold air hose and insert the hooked end...
Page 12 Draft Assembly Instructions ( Continued ) 6) Secure the top cap and insulation pad back on the draft tower. Ensure that they are tightly sealed in place. 3/4" O.D. T-Shaped PVC Drain Fittings w/ 7) Connect any exterior rubber or silicone drain hose that matches the ¾” diameter drain fitting located at the Moveable Plug front, bottom section of the unit.
Page 13 Safe Drilling Areas for Nitrogen Ports Everest recommends only a qualified technician or keg installation professional to perform this modification. Warranty is void if the following guidelines are not met. Safe Drilling Area Right Side Left Side Drill Safe Area Do Not Drill Drill holes for Nitrogen lines anywhere within the highlighted areas.
Page 14 Keg Installation The Nitrogen distributor can be used to share the single Nitrogen tank between multiple kegs. 1) Choosing the Nitrogen tank location A) Cabinet Exterior: For Nitrogen tanks placed outside of the unit, it is necessary to drill a hole for the Nitrogen port anywhere in the safe areas indicated in Chapter 2.
Page 15 Keg Installation ( continued ) 6) Connecting the Coffee Line to the Keg Coupler A) Before proceeding, remove any protective film or wrap from the keg coupler. B) Attach the rubber washer to the coffee line hex fitting. C) Connect the coffee line from the tower to the screw fitting on top of the keg coupler. 7) Tapping the Keg A) Pull on the top handle of the keg coupler and push down until it locks in place.
Page 16: General Safety
• If you suspect a refrigerant leak or a compromised refrigeration system, disconnect the unit, and contact Everest Refrigeration immediately. • When disposing the unit, remove all doors and shelves to avoid any risk of injury or entrapment. Ensure that the refrigerant in the condensing unit is properly disposed of by a qualiﬁed refrigeration technician according...
Page 17: Electrical Safety
4. Electrical Safety This section applies to all Everest products. Basic safety precautions must be observed when using electrical appliances in addition to the following. Warranty is void if these guidelines are not met. Do not use extension cords, adapter plugs or Everest units come as 115 volts, 60 hertz, single other third party electrical connections.
Page 18: Operation
5. Operation Use your Everest product according to its intended functions. Warranty is void if the following guidelines are not met. Starting your Everest Product The default temperature setting is 35.0°F (2.0°C) for refrigerators and -4.0°F (-20.0°C) for freezers. The After plugging in the unit, the current temperature factory recommended temperature range is between 33.0°F (1.0°C) to 40.0°F (4.0°C) for refrigerators and...
Page 19 Carel ‘Easy’ Digital Temperature Control Everest units are equipped with a Carel Digital Temperature Control. The type of controller is dependent on the model and production date. Evaporator Fan Running Compressor Running Alarm in Progress Power / Up Button Temperature Set Button Cabinet Temperature Manual Defrost / Down Button...
Page 20 Setting the Temperature ( continued ) 2. Toggle through the desired temperature by pressing UP or DOWN The number increases or decreases by a decimal point. 3. The recommended setting is 35.0°F (2.0°C) for refrigerators and -4.0°F (-20.0°C) for freezers. The available temperature setting range is 33.0°F to 54.0°F (1.0°C to 12.0°C) for Refrigerators and -10.0°F to 54.0°F (-23.0°C to 12.0°C) for Freezers.
Page 21 Carel ‘ir33’ Digital Temperature Control Everest units are equipped with a Carel Digital Temperature Control. The type of controller is dependent on the model and production date Evaporator Fan Running Program Button Compressor Running Up Button / Alarm in Progress Auxillary Cabinet in Defrost Down Button /...
Page 22 Initiating Manual Defrost The controller has an automatic defrost cycle in place so initiating manual defrost is not necessary unless there is an abnormal accumulation of ice around the evaporator coil. 1. Press and hold down the Manual Defrost Button until the Defrost Symbol appears on the LED display.
Page 23: Care And Maintenance
6. Care and Maintenance This section applies to all Everest products. Regular care and maintenance of your appliance will significantly extend service life and dependability. In severe cases, lack of upkeep will contribute to the rapid decline in performance and component health. Care and maintenance is the product owner’s personal responsibility.
Page 24 Condenser Coil Locations It is necessary to clean the condenser coil of to ensure that it is free of lint, dust and grease build-up. Warranty is void if the following guidelines are not met. ECF1 The condenser coil is located at the back of the unit. Unscrew the front grill and detach completely to expose the Condenser Coils for cleaning.
Page 25 Condenser Coil Cleaning Instructions It is necessary to clean the condenser coil of to ensure that it is free of lint, dust and grease build-up. Warranty is void if the following guidelines are not met. 1. Ensure that the unit is disconnected from the outlet before performing maintenance.
Page 26: Troubleshooting Guide
7. Troubleshooting Guide In most cases, your Everest product may be exhibiting behavior that is typical of standard operation. Observe the following when troubleshooting symptoms. ‘cht’ or ‘CHt’ appears on the LED alternating The door, drawer or gasket may not be sealing with the current temperature and accompanied properly.
Page 27 Condensation on the unit’s exterior surfaces. The temperature may be set too high. Adjust the setting to 35.0°F (2.0°C) for refrigerators or -4.0°F Highly humid environments will contribute to the (-20.0°C) for freezers. condensation build up on exterior panels. Providing ample ventilation and air movement to a space will Hot food items may have been placed in the cabinet.
Page 28: Warranty Information
Warranty Registration Registering your new appliance is important. In the unlikely event a safety notification or warranty service is required, we will have the means to contact you. Your completed appliance registration also verifies your ownership in the event of an insurance loss or theft. You may register online at www.EVERESTref.com or use your smart phone to scan the QR code below: 8.
Page 29 Warranty Certiﬁcate EVEREST warrants to the first purchaser of every new EVEREST unit, the cabinet and all parts thereof, to be free from defects in material or workmanship, under normal and proper use and maintenance service as specified by EVEREST and upon proper installation and start-up in accordance with the instruction packet supplied with each unit.
Page 30 A Step Above The Standard 201 W. Artesia Blvd., Compton, CA 90220 Tel: 800-444-6285 / 310-323-6586 Fax: 310-323-7524 / 310-761-1127 www.EVERESTref.com...
