OWNER'S
MANUAL
COLOR TV/VCR/DVD TRIPLE COMBO
SRCD420P
INSTRUCCIONES EN ESPAÑOL INCLUIDAS.
As an E
S
NERGY
TAR
Partner, our company has
determined that this product meets
the E
S
®
guidelines for
NERGY
TAR
energy efficiency. E
S
NERGY
TAR
is a U.S. registered mark.
All manuals and user guides at all-guides.com
®
If you need additional operating assistance after reading this owner's
manual, please call
®
TOLL FREE : 1-800-968-3429.
Please read before using this equipment
(20 inch)
SUPPLIED ACCESSORIES
ACCESSORIES
Remote Control Unit
Batteries
Owner's Manual
PART NO.
NE227UD
2 AA Batteries
1EMN20105

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Sylvania SRCD420P and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sears Sylvania SRCD420P

Summary of Contents for Sears Sylvania SRCD420P

  • Page 1 All manuals and user guides at all-guides.com OWNER’S MANUAL COLOR TV/VCR/DVD TRIPLE COMBO SRCD420P (20 inch) SUPPLIED ACCESSORIES ACCESSORIES PART NO. Remote Control Unit NE227UD Batteries 2 AA Batteries INSTRUCCIONES EN ESPAÑOL INCLUIDAS. Owner’s Manual 1EMN20105 As an E ® NERGY Partner, our company has If you need additional operating assistance after reading this owner’s...

  • Page 2: C Important Safeguards

    All manuals and user guides at all-guides.com WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. THIS SYMBOL INDICATES THAT DAN- CAUTION GEROUS VOLTAGE CONSTITUTING A RISK OF ELECTRIC SHOCK IS PRESENT RISK OF ELECTRIC SHOCK WITHIN THIS UNIT.
  • Page 3 All manuals and user guides at all-guides.com F IGURE A EXAMPLE OF ANTENNA GROUNDING AS PER NATIONAL ELECT RICAL CODE ANTE NNA L EAD I N W I R E GROUND C L A M P A NTENNA DI SCHARG E UN I T (NEC SECTION 8 10 -2 0) EL ECT RI C SE RV I CE...

  • Page 4: C Precautions

    All manuals and user guides at all-guides.com PRECAUTIONS LASER SAFETY IMPORTANT COPYRIGHT INFORMATION Unauthorized copying, broadcasting, public perfor- This unit employs a laser. Only a qualified service mance and lending of discs are prohibited. person should remove the cover or attempt to ser- This product incorporates copyright protection tech- vice this device, due to possible eye injury.

  • Page 5: Location

    All manuals and user guides at all-guides.com WARNING LOCATION Moisture condensation may occur inside the unit For safe operation and satisfactory performance of when it is moved from a cold place to a warm place your TV/VCR/DVD, keep the following in mind or after heating a cold room or under conditions of when selecting a place for its installation: high humidity.

  • Page 6: Table Of Contents

    All manuals and user guides at all-guides.com TABLE OF CONTENTS STILL PICTURE ....26 TIME SEARCH ....39 C IMPORTANT SAFEGUARDS .

  • Page 7: C Features

    All manuals and user guides at all-guides.com FEATURES TV/VCR Mode • • The Hi-Fi stereo recording/playback You can view a Hi-Fi system– 2 Step picture search operation– system offers you excellent sound quality with a video program at a high speed or super high speed dynamic range of 80dB, frequency response from in either a forward or reverse direction in LP and 20Hz to 20kHz and 0.005% wow and flutter.
  • Page 8 All manuals and user guides at all-guides.com DVD Mode ¡ ¡ Dolby Digital sound On-screen display This TV/VCR/DVD can output a Dolby Digital Information about the current operation can be dis- surround signal from the coaxial digital audio out- played on a TV screen, allowing you to confirm the put jack currently active functions (such as program play- ¡...

  • Page 9: Functions

    All manuals and user guides at all-guides.com OPERATING CONTROLS AND FUNCTIONS - TV/VCR/DVD FRONT PANEL - [Fig.1] DVD buttons TV/VCR buttons SKIP PLAY SKIP CHANNEL REC/OTR PLAY F.FWD STOP POWER VOLUME STOP OPEN/CLOSE SELECT HEADPHONE VIDEO AUDIO R SEARCH TV/VCR EJECT 11 12 13 STOP Button...
  • Page 10 All manuals and user guides at all-guides.com - TV/VCR/DVD REAR PANEL - [Fig.3] AUDIO OUT ANT. COAXIAL AUDIO L/R input Jacks MODE Button [DVD P.40] Connect to the audio output jacks of a video Activates program playback or random playback camera, VCR, video game system.

  • Page 11: C Preparation For Use

    All manuals and user guides at all-guides.com ANT. in Jack COAXIAL digital audio out Jack Connect to an antenna, cable system or satellite Connect to the digital input of an external Audio system. receiver. Only DVD, CD and MP3 audio will be NOTE: Power cord output from this jack.

  • Page 12: Connecting To External Input Jacks

    All manuals and user guides at all-guides.com TO RECORD A SCRAMBLED/UNSCRAM- INSTALLING THE BATTERIES BLED CHANNEL 1. Set the TV/VCR/DVD channel selector to the out- 1)Open the battery compartment cover by pressing put channel of the Cable Converter Box or Satellite the cover on the remote unit in the direction of the Box.

  • Page 13: Connecting To A Stereo Receiver Equipped With Digital Input Jacks

    All manuals and user guides at all-guides.com CONNECTING TO A STEREO RECEIVER EQUIPPED WITH DIGITAL INPUT JACKS Use an audio coaxial digital cable available at retail stores for the audio connection. AUDIO OUT ANT. COAXIAL Receiver equipped with digital DIGITAL AUDIO OUT COAXIAL input jacks NOTE: DVD, CD, MP3 audio only To COAXIAL DIGITAL...

  • Page 14: With A Dolby Digital Decoder (For Dvd)

    All manuals and user guides at all-guides.com CONNECTING TO RECEIVER WITH A DOLBY DIGITAL DECODER (for DVD) If using this TV/VCR/DVD to play a DVD disc in a 5.1 channel Dolby Digital surround format, the TV/VCR/DVD outputs a DOLBY DIGITAL Data stream from its COAXIAL digital audio out jack. By hook- ing the TV/VCR/DVD up to a Dolby Digital decoder, you can enjoy a more convincing, realistic surround sound as enjoyed in movie theaters.

  • Page 15: C Set Up For Use

    TV/VCR SECTION All manuals and user guides at all-guides.com SET UP FOR USE SELECTING THE LANGUAGE CLOCK SET UP (AUTO / MANUAL) TV/VCR TV/VCR Plug in the TV/VCR/DVD power cord The TV/VCR/DVD clock must be set correctly before Plug the TV/VCR/DVD power cord into a VCR timer recording is possible.
  • Page 16 All manuals and user guides at all-guides.com AUTOMATIC CLOCK SETTING Select the year – MANUAL CLOCK SET – Make sure ... • Press the Arrow button K or L MONTH DAY YEAR The TV/VCR/DVD is turned on. 0 5 / 0 6 THU 2 0 0 4 until your desired year appears.

  • Page 17: Daylight-Saving Time

    All manuals and user guides at all-guides.com NOTE: During Auto Clock CH Search, the picture DAYLIGHT-SAVING TIME may be distorted, this is normal. TV/VCR Enter the channel number that contains the Select this feature and the TV/VCR/DVD’s clock Automatic Clock Setting Signal automatically will advance one hour in April, then Press the SETUP button on the reverse one hour in October.

  • Page 18: Channel Set Up

    All manuals and user guides at all-guides.com DELETING (OR ADDING) CHANNEL SET UP CHANNEL(S) TV/VCR TV/VCR You can program the tuner to preset all the channels you receive in your area. The channels you no longer receive or seldom watch can be deleted from the memory.

  • Page 19: C Tv Operation

    All manuals and user guides at all-guides.com TV OPERATION WATCHING A TV PROGRAM PICTURE CONTROL TV/VCR TV/VCR The TV/VCR/DVD’s picture controls – BRIGHT, CONTRAST, COLOR, TINT and SHARPNESS – Turn on the TV/VCR/DVD are preset to factory specifications. Although they are Press the POWER button to turn on the TV/VCR/DVD.

  • Page 20: Closed Caption System

    All manuals and user guides at all-guides.com CLOSED CAPTION SYSTEM Select “CAPTION” - TV/VCR SETUP - TIMER PROGRAMMING Press the SETUP button on the SETTING CLOCK CHANNEL SET UP TV/VCR USER’S SET UP remote control. V-CHIP SET UP LANGUAGE [ENGLISH] B CAPTION [OFF] You can view specially labeled (cc) TV programs, Press the Arrow button K or L to...

  • Page 21: V-Chip Set Up

    All manuals and user guides at all-guides.com V-CHIP SET UP SUB RATINGS V-CHIP SET UP When you select the ratings of TV-Y7,TV-PG,TV-14 or TV-MA you will have the option of selecting sub TV/VCR rating categories. V-CHIP SET UP Select “V-CHIP SET UP” Make sure ...
  • Page 22 All manuals and user guides at all-guides.com CHANGING V-CHIP BLOCKED PRO- Exit the V-Chip setting mode GRAMMING Press the SETUP button on the remote control to Note: To change the rating, the TV must be turned to exit the screen. a station that is not protected.

  • Page 23: C Mts(Multi-Channel Television Sound)System

    All manuals and user guides at all-guides.com MTS(Multi-Channel Television sound)SYSTEM You can record or listen to a program in MTS stereo. CHECKING THE SELECTED MTS MODE TV/VCR When you play a VHS tape, or receive a broadcast 1) When a program is broadcast in stereo, STEREO on the tuner channel you are watching, appears on the TV screen.

  • Page 24: Selecting The Mts System

    All manuals and user guides at all-guides.com SELECTING THE MTS SYSTEM TV/VCR Make sure ... TO SELECT MONO MODE • TV/VCR/DVD power must be turned on. You can change the selection to “MONO” if you want to listen to HIFI tapes in normal audio play- TO SELECT HIFI MODE back.

  • Page 25: C Video Cassette

    All manuals and user guides at all-guides.com VIDEO CASSETTE This TV/VCR/DVD will operate with any cassette that has the mark. For best results, we recommend the use of high-quality tapes. Do not use poor quality or damaged tapes. PRECAUTIONS INSERTING A CASSETTE •...

  • Page 26: C Playback

    All manuals and user guides at all-guides.com PLAYBACK NORMAL PLAYBACK SLOW MOTION TV/VCR TV/VCR Press the PAUSE button, then press the F.FWD g Make sure ... button to start the playback in slow motion. The • TV/VCR/DVD power must be turned on. TV/VCR/DVD mutes the sound during slow motion.

  • Page 27: C Special Playback

    All manuals and user guides at all-guides.com SPECIAL PLAYBACK Make sure ... AUTO REPEAT PLAYBACK • TV/VCR/DVD’s power must be turned on. • Insert a prerecorded tape. TV/VCR The TV/VCR/DVD has the auto repeat function that RENTAL PLAYBACK allows you to repeat a tape indefinitely without touching the PLAY button.

  • Page 28: C Search

    All manuals and user guides at all-guides.com SEARCH Make sure ... TIME SEARCH • TV/VCR/DVD power must be turned on. • Insert a tape. TV/VCR The Time Search function makes it possible to quick- ZERO RETURN ly advance the tape to your desired location simply by entering the exact amount of playback time you TV/VCR want to skip.

  • Page 29: Index Search

    All manuals and user guides at all-guides.com INDEX SEARCH Select “INDEX SEARCH” - TV/VCR SETUP - Press the SETUP button on the TIMER PROGRAMMING TV/VCR SETTING CLOCK CHANNEL SET UP remote control. USER’S SET UP V-CHIP SET UP This feature provides a method of indexing the start- Press the Arrow button K or L to LANGUAGE [ENGLISH] CAPTION [OFF]...

  • Page 30: C Recording

    All manuals and user guides at all-guides.com RECORDING Make sure ... • TV/VCR/DVD power must be turned on. • Insert a cassette tape with its erase prevention tab in place. (If necessary, rewind or fast forward the tape to the point at which you want to begin recording.) NOTES: •...

  • Page 31: Otr (One Touch Recording)

    All manuals and user guides at all-guides.com Push(es) Display Recording length OTR (One Touch Recording) 1 push (normal recording) 2 pushes 0:30 30 minutes TV/VCR 3 pushes 1:00 60 minutes This function enables you to set a recording length simply by pressing the REC/OTR button on the 17 pushes 8:00 480 minutes...

  • Page 32: C Timer

    All manuals and user guides at all-guides.com TIMER AUTOMATIC TIMER Select “TIMER PROGRAMMING” RECORDING Press the SETUP button on the - TV/VCR SETUP - B TIMER PROGRAMMING SETTING CLOCK remote control. CHANNEL SET UP TV/VCR USER’S SET UP V-CHIP SET UP Confirm “TIMER PROGRAM- LANGUAGE [ENGLISH] CAPTION [OFF]...
  • Page 33 All manuals and user guides at all-guides.com TIMER PROGRAM EXTENSION Set beginning hour – TIMER PROGRAMMING – Press the Arrow button K or L until CH DATE BEGIN END -/- - - - - -:- - -:- - - - TV/VCR the desired hour appears.

  • Page 34: Hints For Automatic Timer Recording

    All manuals and user guides at all-guides.com TO CHECK THE BEGIN/END TIME Auto Return will begin 1)Press the POWER button so that the Recording When all the timer recordings are completed, the indicator goes off. TV/VCR/DVD will rewind to the beginning of the 2)Press the SETUP button on the remote control.

  • Page 35: C On Screen Display

    All manuals and user guides at all-guides.com ON SCREEN DISPLAY To check the Counter, Clock and Channel number on the TV screen, press the DISPLAY button on the remote control. Each time you press the DISPLAY button on the remote control, the TV screen will change as follows: When the Closed Caption mode is OFF: When the Closed Caption mode is ON: •...

  • Page 36: C About The Discs

    DVD SECTION All manuals and user guides at all-guides.com ABOUT THE DISCS PLAYABLE DISCS DISC TYPES The following discs can be played back on this [ DVD ] TV/VCR/DVD. Data on a DVD is divided into sections called "titles" and then into subsections called "chapters", each of which is ¡...

  • Page 37: C Playing A Disc

    All manuals and user guides at all-guides.com PLAYING A DISC BASIC PLAYBACK GENERAL FEATURES DVD-V DVD-V Getting started DVD may contain menus to navigate the disc and access special features. Press the appropriate number ¡ Turn on the power of any other components, if nec- buttons or use the Arrow button (K/L/ ) to high- essary.

  • Page 38: Resume

    All manuals and user guides at all-guides.com FAST FORWARD/REVERSE RESUME SEARCH DVD-V DVD-V During playback, press the STOP button. During playback, press and hold the SKIP ¡ Resume message will appear on the TV screen. (h/g) button for a few seconds. ¡...

  • Page 39: C Search Function

    All manuals and user guides at all-guides.com SEARCH FUNCTION TRACK SEARCH TIME SEARCH DVD-V There are three ways to begin playback on an Audio During playback, press the SEARCH MODE CD and MP3 at a specific track. button three times (CD: twice) to display the Time Search on the TV screen.

  • Page 40: C Special Playback Function

    All manuals and user guides at all-guides.com SPECIAL PLAYBACK FUNCTION REPEAT PROGRAM REPEAT is available only during playback. REPEAT TITLE / CHAPTER You may determine the order in which tracks will play. DVD-V In stop mode, press the MODE button. To activate the repeat function, press the ¡...

  • Page 41: C Playing An Mp3 Disc

    All manuals and user guides at all-guides.com PLAYING AN MP3 DISC MP3 PLAYBACK PROGRAM This feature allows you to program an MP3 disc to When a CD with MP3 files is in the TV/VCR/DVD, play in a desired sequence. press the DISC MENU button to call up the MP3 menu on the TV screen.

  • Page 42: C Changing The Settings

    All manuals and user guides at all-guides.com CHANGING THE SETTINGS SUBTITLE LANGUAGE CAMERA ANGLE DVD-V DVD-V The TV/VCR/DVD allows you to select a language for Some DVD discs contain scenes which have been shot subtitles during DVD (if available) playback. simultaneously from various angles.

  • Page 43: C The On-Screen Information

    All manuals and user guides at all-guides.com THE ON-SCREEN INFORMATION DVD-V You can check the information about the current disc by pressing the DISPLAY button on the remote control. For DVD-Vs For audio CDs Press the DISPLAY button during playback Press the DISPLAY button during playback to show current Chapter.

  • Page 44: Items

    All manuals and user guides at all-guides.com CHANGING THE DVD SETUP ITEMS LANGUAGE SETTING Language Code Language Code DVD-V Abkhazian 4748 Laothian 5861 Afar 4747 Latin 5847 Language options are not available with some discs. Afrikaans 4752 Latvian;Lettish 5868 Albanian 6563 Lingala 5860...

  • Page 45: Display Setting

    All manuals and user guides at all-guides.com DISPLAY SETTING AUDIO SETTINGS DVD-V DVD-V You can change certain aspects of the DVD display Choose the appropriate Audio settings for your equip- screens and on-screen messages on the TV screen. ment as it only affects during the playback of DVD discs.

  • Page 46: Parental Control

    All manuals and user guides at all-guides.com CONTROL LEVELS PARENTAL CONTROL ¡ALL All parental lock is cancelled. DVD-V ¡Level 8 DVD software of any grade (adult/general/children) Parental Control limits the disc viewing that exceed can be played back. your settings (with a password or playback will stop). ¡Levels 7 to 2 This feature allows you to prevent discs with objec- tionable material from being played by your children.

  • Page 47: C Troubleshooting Guide

    All manuals and user guides at all-guides.com TROUBLESHOOTING GUIDE If the TV/VCR/DVD does not perform properly when operated as instructed in this Owner’s Manual, check the TV/VCR/DVD, consulting the following checklist. PROBLEM CORRECTIVE ACTION • No power Make sure the power plug is connected to an AC outlet. •...
  • Page 48 All manuals and user guides at all-guides.com PROBLEM CORRECTIVE ACTION • Picture OK, Sound Poor Try a new channel, if OK, then possible station trouble. • Check for local interference. • Timer recording is not possible Make sure the timer recording is set correctly. •...
  • Page 49 All manuals and user guides at all-guides.com DVD Mode PROBLEM CORRECTIVE ACTION No picture • Insert a correct video disc that plays on this TV/VCR/DVD. • Press the SELECT button on the remote control to select DVD mode. Then, try other DVD feature. •...

  • Page 50: C Maintenance

    All manuals and user guides at all-guides.com MAINTENANCE CABINET CLEANING 1.Please visit your local Audio/Video store and pur- chase a good quality VHS Video Head Cleaner. • Wipe the front panel and other exterior surfaces of 2.If a Video Head Cleaner does not solve the prob- the TV/VCR/DVD with a soft cloth immersed in lem, please call our help line at 1-800-488-1222, to lukewarm water and wrung dry.

  • Page 51: C Specifications

    All manuals and user guides at all-guides.com SPECIFICATIONS GENERAL SPECIFICATIONS ELECTRICAL SPECIFICATIONS Sound output: 2 speakers, 1W, 8 ohm TV/VCR 20 inch in-line gun, OTHER SPECIFICATIONS 90˚ deflection tube Terminals Television system : NTSC-M Antenna input: VHF/UHF/CATV Closed caption system :§15.119/FCC 75 ohm unbalanced (F-type) Video Heads : Rotary four-head...

  • Page 52: C Español

    All manuals and user guides at all-guides.com INDICE 12. Indicador de grabación Parpadea durante la grabación. Se ilumina durante el modo de espera de grabación controlada por temporizador. ■ CONTROLES DE OPERACIÓN Y FUNCIONES ..52 13.
  • Page 53 All manuals and user guides at all-guides.com ANTENAS SEPARADAS DE VHF/UHF 30. Botón CLEAR Para cancelar ajustes. En algunas zonas será necesario utilizar una antena 31. Botón MODE exterior. Activa el modo de reproducción programada o el modo de TELEVISIÓN POR CABLE SIN CAJA DE reproducción aleatoria.
  • Page 54 All manuals and user guides at all-guides.com Consulte la figura 7 de la página 14 PARA INSERTAR LAS PILAS NOTAS: 1) Abra la cubierta del compartimiento de las pilas • Asegúrese de desconectar la alimentación de todos empujando la cubierta del mando a los componentes del sistema antes de conectar otro distancia en el sentido de la flecha.
  • Page 55 All manuals and user guides at all-guides.com NOTA: Si, por alguna razón, el menú está en inglés o 1) Pulse el botón SETUP en el mando a distancia. francés, pulse el botón SETUP en el mando a distancia, Pulse el botón K o L para indicar “AJUSTE pulse el botón K o L para señalar el “LANGUAGE RELOJ”.
  • Page 56 After 90 days and until one (1) year from the date of purchase, Sears will replace defective parts free of charge. You pay for labor. After 90 days and until two (2) years from the date of purchase, Sears will replace the Picture Tube if it is defec- tive. You pay for labor.
