- Page 1 TST-100 Touchscreen Terminal Installation Guide August 2022 Document Number: 8200-1370-01 Revision: E www.swhouse.com...
- Page 2 • Smart mode can only be used on one reader per port. UL compliance information The TST-100 Touchscreen Terminal has been evaluated to ULC60839-11-1 (Grade 2). Outdoor use has not been evaluated to ULC60839-11-1. Optional ULC 60839-11-1 requirements have not been evaluated by UL.
-
Page 3: Ordering Codes
Software House TST-100 Touchscreen Terminal voice and audio enabled (future firmware release). SWH-TST-OUTK Software House TST-100 Touchscreen Terminal outdoor kit. The TST-100 Touchscreen Terminal with speakers is rated to IP54 for water resistance. This IP54 rating is not UL evaluated. NOTE TST-100 Touchscreen Terminal Installation Guide... -
Page 4: Specifications And Requirements
■ For a UL-compliant installation the power must be approved to UL-294 and/or UL-603, and ULC-60839-11-1. CAUTION: Changes to the TST-100 Touchscreen Terminal that are not expressly approved by the party responsible for compliance could void your authority to operate the equipment. - Page 5 NOTE secure area in case of electromechanical failure. FOR BURGLAR ALARM INSTALLATIONS: The TST-100 Touchscreen Terminal is not provided with backup power. An external power supply must be provided with the following characteristics: • UL 603 Listed. • Minimum four hours of standby power.
-
Page 6: Enclosure Specifications
Enclosure specifications Table 3 Figure 1provide information on the measurements and weight of the TST-100 Touchscreen Terminal enclosure. Table 3: TST-100 Touchscreen Terminal enclosure dimensions Item Dimension Weight ~1 lb (~ 0.44kg) Height 6.85 in (174mm) Width 6.11 in (155.25mm) Depth 1.59 in (40.32mm) at the narrowest point... - Page 7 Environmental requirements ■ The TST-100 Touchscreen Terminal board has a -4°F (-20°C) to 140°F (60°C) ambient temperature rating. ■ This TST-100 Touchscreen Terminal board has a 93% (+/-2%) humidity spec rating. ■ This product is for indoor and outdoor use.
- Page 8 In Smart protocol mode, the data state resistances can be configured from the host, using the same resistance wiring configurations that are available for the I/8-CSI and the IP-ACM v1 or IP-ACM v2. For more information regarding other inputs available and details of configuration, refer to the I/8-CSI User Guide . TST-100 Touchscreen Terminal Installation Guide...
- Page 9 TST-100 Touchscreen Terminal board Figure 3 Page 9 shows the TST-100 Touchscreen Terminal board switches, connectors, jumpers, ports, and LEDs. Figure 3: TST-100 Touchscreen Terminal board Switches Table Table 6, and Table 7 describe switches on the TST-100 Touchscreen Terminal board.
- Page 10 Default operation for reader in Smart mode 1, 2, 3, 4, 5, 6, 7, 8 Reader address in RM mode 9, A, B, E, F Reserved for internal Software House use Configuration Mode Factory default reset TST-100 Touchscreen Terminal Installation Guide...
- Page 11 Half Duplex Data - GND/Power Return Full Duplex Data + Full Duplex Data - Wiring for the RS-485 is straight-through. Ensure that pin 1 of the TST-100 Touchscreen Terminal connects to pin 1 of the (IP-)ACM. NOTE TST-100 Touchscreen Terminal Installation Guide...
-
Page 12: Visual Indicators
Visual indicators Table 10 describes the LED visual indicators on the TST-100 Touchscreen Terminal board. Table 10: LED visual indicators Designation Power is going to the board Indicates Output 1 is enabled Indicates Output 2 is enabled RS-485 Tx RS-485 Rx NOTE: Outputs are for connection to external relay only. - Page 13 RM mode. Not all features are supported while using the reader in RM mode. If you change any of the switch settings after system start-up, you need to reset the TST-100 Touchscreen Terminal. You can do this by NOTE power cycling the reader or pressing SW1, the RESET button, on the board.
- Page 14 The card reader interface displays online status. Smart Mode configuration Configuring the TST-100 Touchscreen Terminal in Smart mode: 1. Connect and power the reader to an IP-ACM, iSTAR Ultra G2, Ultra G2 SE, or Edge G2 using RS-485 full-duplex wiring.
- Page 15 The reader is not ready. READY This occurs when the reader has been configured but has not been assigned to a door. PRESENT CARD Present your card. Configure a smart reader and assign it to a door. TST-100 Touchscreen Terminal Installation Guide...
- Page 16 DOOR IN ALERT The door state is in alert. DOOR FORCED The door state is forced open. OPEN DOOR HELD OPEN The door state is being held open. UNLOCKED The door state is unlocked and closed. TST-100 Touchscreen Terminal Installation Guide...
- Page 17 Prompt 1 field is populated. ENTER TARGET This displays after entering the numeric access code. Escorted Visitor RM Mode Graphic Description Message ACKNOWLEDGED Card read acknowledged in a situation requiring multiple cards for access. TST-100 Touchscreen Terminal Installation Guide...
- Page 18 AREA ARMED The intrusion zone is armed and not violated. SECURE VIOLATED The armed intrusion zone was violated. EXIT NOW The intrusion zone is in the process of being armed and the exit delay is active. TST-100 Touchscreen Terminal Installation Guide...
- Page 19 REJECT Occupancy levels not sufficient to allow access. OCCUPANCY REJECT The user cannot exit because they have left their UNATTENDED visitor unattended. LOCKOUT & TIME The reader is locked out and displays the time remaining. TST-100 Touchscreen Terminal Installation Guide...
- Page 20 Keypad scramble Keypad scramble is a feature available in the TST-100. It offers a high security option for covert code entry. The LED displays randomly allocated set of numbers from 0 to 9. The position of the numbers change every time you activate the keypad so that only the user standing directly in front of the keypad can see the scrambled digits.
- Page 21 Updating TST-100 Touchscreen Terminal firmware You can update the TST-100 Touchscreen Terminal firmware through C•CURE 9000 or by using a laptop directly connected to the reader. Read the TST-100 Touchscreen Terminal firmware release notes before updating the firmware. Firmware updates have not been evaluated by UL.
- Page 22 Updating the firmware using a connected laptop You can update Smart mode and RM mode readers using a laptop directly connected to the reader. Refer to the TST-100 Touchscreen Terminal Firmware Update Guide for update instructions when using a laptop connected to the reader.
- Page 23 Removing the front trim The TST-100 Touchscreen Terminal ships with a cardboard insert between the front trim and the unit. This stops the front trim from engaging with the unit during shipping. Remove this cardboard insert to completely engage the front trim to the TST-100 unit.
- Page 24 Copyright and Trademarks © 2022 Johnson Controls. All rights reserved. JOHNSON CONTROLS, TYCO and C•CURE 9000 are trademarks and/or registered trademarks. Unauthorized use is strictly prohibited. Product offerings and specifications are subject to change without notice. Actual products may vary from photos. Not all products include all features.
