- Page 1 Page 1 of 17 User manual Ferlin One Revision: 1.2 Release date: 14-6-2023 Rudolf Dieselstraat 15A, Nijverdal, Nederland. +31 523 0613439. Mail: Info@ferlin.nl...
-
Page 2: Table Of Contents
Dosing signal ............................9 External alarm signal ......................... 10 Start and stop ............................11 This turns the start button into a stop button. The Ferlin One can be stopped by pressing this button................................11 Recipe change............................12 Cleaning ..............................13 Alarms .............................. -
Page 3: General Information
Ferlin reserves the right to update this manual at any time without prior notice. Ferlin has made every effort to ensure that these operating instructions are accurate. Ferlin disclaims liability for any inaccuracies or omissions. - Page 4 General: • The company, which owns the FERLIN ONE, needs to guarantee that its co-workers working with the FERLIN ONE are aware of the safety instructions and have read and understood the safety instructions and manual. • With the execution of maintenance near or with the FERLIN ONE the safety instructions and the manual should be available for the co-worker.
- Page 5 FERLIN ONE for performing maintenance. • It must be ensured that the Ferlin ONE is not subject to collision hazard. If this cannot be guaranteed, installation on input zone is prohibited. •...
- Page 6 • Make sure that the FERLIN ONE is prevented from falling or tilting. • Make sure the door of the FERLIN ONE is closed and the dosing part and main hopper are removed before transport. Rudolf Dieselstraat 15A, Nijverdal, Nederland.
-
Page 7: Ferlin One
Page 7 of 17 Ferlin One Parts overview 1- Neck piece 2- Housing 3- Door 4- Main hopper 5- Clamping levers 6- Dosing part 7- Filter pressure regulator (optional) Alarm lamp (optional) Rudolf Dieselstraat 15A, Nijverdal, Nederland. +31 523 0613439. Mail: Info@ferlin.nl... -
Page 8: Controller
Controller The controller is displayed below: Help function The Ferlin One features a help function. Press the question mark in the top right corner to get explanations about the content on the screen. Setting up the One The Ferlin One controller should be connected to the dosing section via 3 cables. Connect the 9, 15 and 25-pole d-sub connectors to the controller and the housing (2). -
Page 9: Dosing Signal
Page 9 of 17 Dosing signal De The controller of the Ferlin One has an M12 connector on the back that has 8 poles. The potential-free dosing contact of the injection moulding machine must be connected to this. A screw connector is supplied with the Ferlin One. -
Page 10: External Alarm Signal
Page 10 of 17 External alarm signal The Ferlin One controller also includes a potential-free alarm contact. This contains a NO and NC connection. These can be connected via the 5-pin M12 connector. A screw connector is supplied with the Ferlin One. Connecting is as follows:... -
Page 11: Start And Stop
When starting up the injection moulding machine (and flushing), the Ferlin One should be set to stop. This means that the start button should be visible. (If the stop button is visible, the Ferlin One is still in run mode). -
Page 12: Recipe Change
After this, the recipe screen opens, which looks as follows: Shot weight and percentage can be entered here. Press the pencil to adjust the values. Press previous to return to the main screen. Rudolf Dieselstraat 15A, Nijverdal, Nederland. +31 523 0613439. Mail: Info@ferlin.nl... -
Page 13: Cleaning
(6) backwards. The dosing part (6) can now be cleaned. CAUTION: use safety goggles when cleaning the hopper with compressed air. Place the dosing part(3) back into the housing (2). Reconnect the motor cable to the connector. Close the door(3). Rudolf Dieselstraat 15A, Nijverdal, Nederland. +31 523 0613439. Mail: Info@ferlin.nl... -
Page 14: Alarms
Here is a list of the possible alarms with causes and solutions: Please keep the safety instruction on page 5 in mind when performing any action on the Ferlin One. 1. Door open. a. The door(3) of the Ferlin One is open. It must be closed to start the Ferlin One. - Page 15 Enter the desired dosing time here. 7. Unstable dosing weight a. This alarm appears when the Ferlin One has not been able to perform a stable weighing for 2 consecutive cycles. This alarm disappears automatically when another stable weighing has taken place.
-
Page 16: Problem Solving
Taring and calibration Go to settings (gears on main screen) -> loadcell. Then open the tare or calibrate screen. Follow the on-screen instructions to tare or calibrate. Rudolf Dieselstraat 15A, Nijverdal, Nederland. +31 523 0613439. Mail: Info@ferlin.nl... -
Page 17: Login
To log in, click on the lock at the top left of the main screen: Then choose the desired login level and enter the password. Passwords are by default: 1111 for supervisor 2222 for technician Rudolf Dieselstraat 15A, Nijverdal, Nederland. +31 523 0613439. Mail: Info@ferlin.nl...
