Full Spectrum Laser MUSE FIBER GALVO 2 User Manual

Hide thumbs Also See for MUSE FIBER GALVO 2:
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MUSE FIBER GALVO 2 and is the answer not in the manual?

Questions and answers

Related Manuals for Full Spectrum Laser MUSE FIBER GALVO 2

Summary of Contents for Full Spectrum Laser MUSE FIBER GALVO 2

  • Page 2: Safety Warning

    Safety Warning: Assembly: M5 hex Do not leave your machine unattended. Avoid using materials made of carbon or that contain carbon M4 hex 2- m5 components. screws Always keep a fire extinguisher and first aid kit nearby. 4- m6 screws Do not attempt to access any electrical areas while the machine is on.

  • Page 3: Connecting To Internet

    Diagrams: Connecting to Internet: Laser head Assembly Connect Via Router (Recommended): To establish a reliable link to RE3, it is recommended to connect the Fiber Galvo Lens to the router. The Fiber Galvo is equipped with an ethernet cable that should be plugged into the ethernet ports of both devices Note: Ethernet port looks the same on all devices Touchscreen...

  • Page 4: Touchscreen Interface

    Touchscreen Interface: Home Network ⇨ Wi-Fi The Home screen displays important information such as the device's Enables users to connect to a Wi-Fi network. IP address, the QR Code for RE3, and controls for the laser head. Job History Mobile Version A mobile version of the device is accessible by either scanning the The Job History icon provides easy access to previous projects.
  • Page 5 Focusing: Manual Focus Autofocus The focal length of the lens determines the distance between your laser head and the material. Refer to the chart below for the required distance for each of our lenses. To autofocus your machine, you need to retrieve your April tag card first. Ensure that the side of the card which says "Focus Card V1.2"...

  • Page 6: Lens Replacement

    Focusing: Lens Replacement: Dual Diode: Lens Collar Camera Lens 1. Remove any objects or work pieces from underneath the lens work area. Ensure laser head is in a reachable position to remove lens. 3. Place the lens cap onto your lens to protect the lens from potential damage. A diode is affixed to the rear of the machine and positioned according to the focal length of the lens.

  • Page 7: Lens Calibration

    Lens Calibration: Once the Laser Tools page is loaded, locate the Laser Focus and Lens Calibration section. Ensure that the correct lens size is saved in the lens section. If the wrong lens setting is saved, then all subsequent calibrations will need to be redone. 2.
  • Page 8 Mark Adjustment: Preview Adjustment: After confirming that the mark adjustment is accurate, proceed to mark a new square by selecting the "Mark Square" button. 1. Without moving the previously engraved material, press the "Preview Square" button. 2. Make use of the adjustment buttons to align the tracing made by the red dot precisely with the marked square.
  • Page 9 Focus Tag Calibration: Ensure that your machine is properly focused before starting the calibration process. Take note of the Z-stage coordinates displayed on the Main Unit screen to ensure accurate calibration. Navigate to the Laser Tools page and locate the Galvo Autofocus Calibration section. Select the Autofocus Mode.
  • Page 10 RetinaEngraveV3 (RE3): RE3 can be accessed by entering your machines IP address into your web browser. When loaded RE3 will appear like so. Main Toolbar Workspace Viewing Tools Drawing Tools Orientation Tools Grouping Tools Tools Project List Project Information Gantry Coordinates Cursor Coordinates Rotary Switch Status Indicators...
  • Page 11 Full Spectrum AI: Full Spectrum Lasers has just unveiled its newest innovation - an advanced AI system that is After taking the Screenshot, hold the Shift key and select a few spots on the present objects, then hold set to revolutionize the laser cutting industry. This cutting-edge technology is designed to the Shift and Alt keys to select background spots.
  • Page 12 Full Spectrum AI: 2. The Advance Settings:(Sidebar) Aligning objects: Vector and Raster objects can be selected and placed onto the center of each perimeter By selecting the down arrow, a side bar will appear using the align option. Keep in mind that the AI will not resize the selected objects, it will showing the settings for all the identified objects.

  • Page 13: Troubleshooting

    Project Procedure: Troubleshooting: Q: What should I do if my laser isn't marking? A: Check if the laser is properly focused. If the machine is not at the right height, it won't engrave. Refocus the laser head after changing to a new material. Still having difficulties, make sure that your Connect to Software material is compatible with your laser engraver.
