・Please read this entire manual prior to using the S327 Precision Cleaver.
・This manual must be kept with the S327 Precision Cleaver.
Safety Instructions
This manual contains the complete operating and basic maintenance
instructions for the S327 Precision Cleaver.
Please review this manual carefully before using the S327 Precision Cleaver.
The following safety instructions must be followed whenever this product is
operated, serviced, or repaired. Failure to comply with any of these instructions
or with any precaution or warnings contained in this manual is in direct
violation of the standards of the design, the manufacturer, and the intended use
of the instrument. FURUKAWA ELECTRIC CO., LTD. assumes no liability
for the customer's failure to comply with these requirements.
CAUTION
!
ATTENTION
Please contact FURUKAWA ELECTRIC CO., LTD. with any questions
relating to the description of this manual.
In no case will FURUKAWA ELECTRIC CO., LTD. be liable to the buyer, for
any consequential or indirect damage which is caused by product failure,
malfunction, or any other problem.
S327 Precision Cleaver
Operating Instructions
Safety Instructions
Failure to comply with any of the instructions,
which are indicated by this symbol, may cause
serious injury or damage to the machine.
Failure to comply with any of the instructions,
which are indicated by this symbol, may cause the
device to function improperly and degrade the
performance.
FTS-B616
Issue 1; Feb. 2023
Advertisement
Related Manuals for Fitel S327
Summary of Contents for Fitel S327
- Page 1 Issue 1; Feb. 2023 S327 Precision Cleaver Operating Instructions ・Please read this entire manual prior to using the S327 Precision Cleaver. ・This manual must be kept with the S327 Precision Cleaver. Safety Instructions This manual contains the complete operating and basic maintenance instructions for the S327 Precision Cleaver.
- Page 2 ・ Please be cautious when disposing of fibers from the fiber waste bin. Scattered fibers may cause injury. The fiber waste bin for loose fiber must be installed into the S327 Precision ・ Cleaver during operation, otherwise there is a risk of loose fibers scattering.
-
Page 3: Standard Components
1. Standard Components Parts Name Parts No. S327 Main Body S327A-01 Single Fiber Adapter S327X-18 Waste Bin S327X-12 Carrying Case S327X-17 Hexagonal Wrench S327X-16 Operating Instructions FTS-B616 2. Optional Components Parts Name Parts No. Blade Exchange Set S327X-24 Single Fiber Adapter... -
Page 4: Specifications
4. Specifications Applicable Fiber Silica Fiber Count Single Fiber Ribbon Fiber (250mm) ; 2~12 fiber ribbon Ribbon Fiber (200mm) ; 2~16 fiber ribbon 125 m Clad Diameter Coating Diameter Single Fiber ; 0.20~3.0 mm Ribbon Fiber ; 0.20~0.40mm×0.25mm pitch Ribbon Fiber ; 0.20~0.40mm×0.20mm pitch Cleave Length Single Fiber ;... - Page 5 5. Operating instructions 5.1. Unlock cover of Clamp Arm The Cover of Clamp Arm should be locked during transportation. Unlock the Cover prior to use and select appropriate opening angle. Semi-Open or Fully Open. Press the Cover down. ① Turn the knob to appropriate position. ②...
- Page 6 5.2. Cleaving fiber Push the Blade Unit to the back until it latches. ① Set a prepared fiber (stripped and cleaned) across cleaving area with ② fiber end inserted into the Waste Bin. Ensure that the stripped fiber is long enough to reach the Pinch Roller. Put fiber to the appropriate v-groove on the single fiber adapter, depending on the coating diameter of optical fiber.
-
Page 7: Blade Rotation
ATTENTION Don’t touch the FR arm while working on ②③. Please take care not to tilt S327 Precision Cleaver too much, as fiber will spill out of the Waste bin. Take care not to cut your fingers with the Blade. - Page 8 1. Turn ① in the “–“ direction of the 1 tick. 2. Tighten ② screws 7. Disposal S327 contains no hazardous substances or recyclable materials. If disposed of, follow your local disposal regulations. 8. Contacts For sales and service information, Contact FURUKAWA ELECTRIC CO., LTD.
