- Page 1 Installation Guide P/N 067363-002 TRAKKER Antares ® 2455 Keyboard...
- Page 2 Intermec Technologies Corporation 6001 36th Avenue West P.O. Box 4280 Everett, WA 98203-9280 U.S. service and technical support: 1-800-755-5505 U.S. media supplies ordering information: 1-800-227-9947 Canadian service and technical support: 1-800-688-7043 Canadian media supplies ordering information: 1-800-268-6936 Outside U.S. and Canada: Contact your local Intermec service supplier. The information contained herein is proprietary and is provided solely for the purpose of allowing customers to operate and/or service Intermec manufactured equipment and is not to be released, reproduced, or used for any other purpose without written permission of Intermec.
- Page 3 T2455 Keyboard Installation Guide TRAKKER Antares 2455 Keyboard Installation Guide This installation guide explains how to install your TRAKKER Antares ® 2455 (T2455) keyboard. 2455I.001 The T2455 keyboard assembly kit includes the following: • Keyboard • #8 straight-slot screws, ½-inch (12.7 mm) long (4) •...
-
Page 4: Mounting The Keyboard
T2455 Keyboard Installation Guide Installing the Keyboard Overlay Your terminal shipped with a keyboard overlay. You can install the overlay on your keyboard. To install the keyboard overlay 1. Clean the keyboard surface using a cotton swab moistened with isopropyl alcohol. Allow the surface to dry. - Page 5 T2455 Keyboard Installation Guide Attaching the Hinges to the Keyboard Tension screw 2455I.002 4. Repeat Steps 2 and 3 for the other hinge. 5. Position the T2455 so the four mounting holes in the bottom of the terminal are facing up. 6.
- Page 6 T2455 Keyboard Installation Guide 9. Position one keyboard mounting bracket against the terminal as shown in the following illustration. Loosely secure the bracket to the terminal using the #8 Phillips screws with cone washers and the Phillips screwdriver. Slide the bracket to the outermost position.
- Page 7 T2455 Keyboard Installation Guide Mounting the Keyboard to a Remote Location You can mount the keyboard to a remote location, rather than to the terminal. For instance, you can mount the keyboard to the dashboard of your vehicle. To create your own mounting surface, see “Specifications”...
- Page 8 T2455 Keyboard Installation Guide Mounting the Keyboard to a Remote Location Back plate Keyboard screw (6 places) Mounting screw (4 places) 2455I.005 Connecting the Keyboard Cable to the Terminal Now that you have installed your keyboard, you need to connect it to the terminal. 1.
-
Page 9: Specifications
T2455 Keyboard Installation Guide Connecting the Keyboard Cable to the Terminal Keyboard cable connector Keyboard 2455I.006 3. Use the straight-slot screwdriver to tighten the screws in the keyboard cable connector and secure the cable to the T2455. 4. Tuck any excess cable into the back of the keyboard. 5. - Page 10 T2455 Keyboard Installation Guide Keyboard Back Plate Specifications .562 in 1.43 cm 7.570 in 1.062 in 19.23 cm .21 in 2.7 cm .186 in 5.334 mm 3.78 in 4.72 mm 9.6 cm 1.69 in 4.29 cm 2X 3.379 in 8.58 cm 4X ∅...
- Page 11 T2455 Keyboard Installation Guide Keyboard Specifications (Front View) 11.24 in 28.55 cm 4.10 in 10.414 cm 2455I.009 Note: This keyboard illustration is not shown to scale. Keyboard Specifications (Side View) 1.72 in 4.369 cm 1.00 in 2.54 cm 2455I.010 Note: This keyboard illustration is not shown to scale.
