OPERATOR'S MANUAL
INVERTER AC/DC PULSED TIG WELDER
TIG 200E AC/DC
2014．06
IMPORTANT: Read this Owner's Manual Completely before attempting to use this
equipment. Save this manual and keep it handy for quick reference. Pay particular
attention to the safety instructions we have provided for your protection. Contact your
.
distributor if you do not fully understand this manual.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TIG 200E AC/DC and is the answer not in the manual?

Questions and answers

Summary of Contents for Rimac TIG 200E AC/DC

  • Page 1 OPERATOR’S MANUAL INVERTER AC/DC PULSED TIG WELDER TIG 200E AC/DC 2014．06 IMPORTANT: Read this Owner’s Manual Completely before attempting to use this equipment. Save this manual and keep it handy for quick reference. Pay particular attention to the safety instructions we have provided for your protection. Contact your...

  • Page 2: Table Of Contents

    CONTENT §1 SAFETY ............................. 1 §1.1 S ........................1 IGNAL XPLANATION §1.2 A ....................... 1 ELDING AMAGE §1.3 T ............... 5 HE KNOWLEDGE OF LECTRIC AND AGNETIC IELDS §2 SUMMARY ............................6 § 2.1 B ........................6 RIEF NTRODUCTION §2.2 M ........................

  • Page 3: Safety

    SAFETY §1 SAFETY §1.1 Signal Explanation  The above signals mean warning! Notice! Running parts and getting an electric shock or thermal parts will take damage for your body or others. The corresponding notices are as follows. It is quite a safe operation after taking several necessary protection measures.
  • Page 4 SAFETY semiautomatic welding gun are also electrically “hot”.  Always be sure the work cable makes a good electrical connection with the metal being welded. The connection should be as close as possible to the area being welded. Maintain the electrode holder, work clamp, welding cable and welding machine in good, safe operating condition.
  • Page 5 SAFETY arc when welding or observing open arc welding.  Use suitable clothing made from durable flame-resistant material to protect your skin and that of your helpers from the arc rays.  Protect other nearby personnel with suitable, non-flammable screening and /or warn them not to watch the arc nor expose themselves to the arc rays or to hot spatter or metal.
  • Page 6 SAFETY an explosion even though they have been “cleaned”.  Vent hollow castings or containers before heating, cutting or welding. They may explode.  Sparks and spatter are thrown from the welding arc. Wear oil free protective garments such as leather gloves, heavy shirt, cuff less trousers, high shoes and a cap over your hair.

  • Page 7: The Knowledge Of Electric And Magnetic Fields

    SAFETY §1.3 The knowledge of Electric and Magnetic Fields Electric current flowing through any conductor causes localized Electric and Magnetic Fields (EMF). The discuss on the effect of EMF is ongoing all the world. Up to now, no material evidences show that EMF may have effects on health.

  • Page 8: Summary

    SUMMARY §2 SUMMARY § 2.1 Brief Introduction TIG200E AC/DC welding machine adopts the latest pulse width modulation (PWM) technology and insulated gate bipolar transistor (IGBT) power module, which can change work frequency to medium frequency so as to replace the traditional hulking work frequency transformer with the cabinet medium frequency transformer.
  • Page 9 SUMMARY  DC Pulse TIG  AC MMA  AC TIG  AC Pulse TIG 1.For DC MMA, polarity connection can be chosen according to different electrodes，please refer to §3.5； 2.For AC MMA, magnetic flow caused by invariable DC polarity can be avoided； 3.For DC TIG, DCEP is used normally (workpiece connected to positive polarity, while torch connected to negative polarity).

  • Page 10: Module Explanation

    SUMMARY IGBT——Insulation Gate Bipolar Transistor TIG——Tungsten Insert Gas welding §2.2 Module Explanation The module explanation of arc welding machine must accord with the correlative prescripts of National Standard GB10249. It is explained as the following (take WSME-200 as an example). E ---- 200 Max welding current: 200A DC/AC...

  • Page 11: Volt-Ampere Characteristic

    SUMMARY §2.4 Volt-Ampere Characteristic TIG200E AC/DC welding machine has an excellent volt-ampere characteristic, whose graph is shown as the following figure. The relation between the conventional rated loading voltage U and the conventional welding current I is as follows: ≤600A，U ＞600A,U When I =10+0.04I...

  • Page 12: Installation And Adjustment

    INSTALLATION AND ADJUSTMENT §3 Installation and Adjustment §3.1 Parameters Models TIG 200E AC/DC TIG 200E AC/DC PULSE Parameters Input power 1~220±10%，50Hz 1~220±10%，50Hz Rated input current（A） 35.4（TIG） 39.5（MMA） 35.4（TIG） 39.5（MMA） Rated input power （KW） 5.2（TIG） 6.4（MMA） 5.2（TIG） 6.4（MMA） Power factor 0.68 0.68...

  • Page 13: Duty Cycle & Over Heat

    The movement may result in the potential danger or substantive hazard, so please make sure that the machine is on the safe position before using it. §3.4 Power supply input connection TIG 200E AC/DC welding machines’ power supply connects to 220V.

  • Page 14: Polarity Connection（Mma

    INSTALLATION AND ADJUSTMENT When the power supply voltage is over the safe work voltage, there are over voltage and under voltage protection inside the welder, the alarm light will on, at the same time, the current output will be cut off. If the power supply voltage continually goes beyond the safe work voltage range, it will shorten the welder life-span.

  • Page 15: Assembling The Equipment (Tig)

    INSTALLATION AND ADJUSTMENT §3.6 Assembling the equipment (TIG)  Workpiece is connected to the positive electrode of welding machine, and welding torch is connected to the negative electrode, which is called DC POSITIVE CONNECTION; otherwise, that is called DC NEGATIVE CONNECTION. Generally, it is usually operated in DC POSITIVE CONNECTION in TIG welding mode.

  • Page 16: Operation

    INSTALLATION AND ADJUSTMENT §4 Operation §4.1 Layout for the panel Positive output The welder’s positive polarity output. Negative output The welder’s negative polarity output. Aero socket Is connected to torch switch control wire.（It has 14 leads and lead 8 - lead 9 are connected to torch switch control wire）.
  • Page 17 MAINTENANCE AND TROUBLESHOOTING Shield gas input joint To connect one head of the gas hose while the other head of which is connected to argon gas cylinder.

  • Page 18: Control Panel

    INSTALLATION AND ADJUSTMENT §4.2 Control panel TIG 200E AC/DC...
  • Page 19 INSTALLATION AND ADJUSTMENT TIG 200E AC/DC PULSE...
  • Page 20 INSTALLATION AND ADJUSTMENT Available parameters where 2T and 4T mode have been selected: Gas pre-flow time Unit Setting r a nge 0.0—2.0 Starting current (only with 4T) Unit Setting r a nge 10—170 (DC)；10—200(AC) Upslope t i me Unit Setting r a nge 0.0—10 Welding current Unit...
  • Page 21 MAINTENANCE AND TROUBLESHOOTING Unit Setting r a nge 0—10 Crater ar c c urrent ( o nly with 4T) Unit Setting r a nge 10-170 (DC)；110-200 (AC) Gas p ost-flow time Unit Setting r a nge 0.1—10 Balance (only with TIG-AC) Balance adjustment is mainly used to set the adjustment of eliminating metal-oxide (such as Aluminium, Magnesium and its alloy) while AC output.

  • Page 22: Pedal Switch Control

    MAINTENANCE AND TROUBLESHOOTING §4.3.1 Pedal switch control ● When plug the fourteen-lead aero-socket of pedal switch in it. Welder will identify the pedal switch, the welding current knob on the front panel will can’t use，and only 2T can be selected. ●...

  • Page 23: Argon Arc Welding Operation

    MAINTENANCE AND TROUBLESHOOTING §4.4 Argon Arc Welding Operation §4.4.1 TIG welding （4T operation） The start current and crater current can be pre-set. This function can compensate the possible crater that appears at the beginning and end of the welding. Thus, 4T is suitable for the welding of medium thickness plates.

  • Page 24: Tig Welding (2T Operation)

    MAINTENANCE AND TROUBLESHOOTING  t6～t7： Post-gas time can be set by the post-gas time adjustment knob on the front panel （0.1～ 10S）;  t7： Electromagnetic valve is closed and stop argon flowing. Welding is finished. §4.4.2 TIG welding (2T operation) This function without the adjustment of start current and crater current is suitable for the Re-tack welding、transient welding、thin plate welding and so on.
  • Page 25 MAINTENANCE AND TROUBLESHOOTING the knob on the front panel.  electromagnetic gas valve turned off, the shield gas stops to flow, and welding is finished. Short circuit protect function： ○ 1 TIG /DC/LIFT：If the tungesten electrode touches the workpiece when welding, the current will drop to 20A, which can reduce the tungsten spoilage farthestly，prolong the using life of the tungsten electrode，and prevent tungsten clipping.

  • Page 26: Welding Parameters

    MAINTENANCE AND TROUBLESHOOTING output polarity changes alternately. §4.5 Welding Parameters §4.5.1 Joint forms in TIG/MMA butt joint lap joint coner joint T joint §4.5.2 The explanation of welding quality The relation of welding area color & protect effect of stainless steel Welding area argent , golden blue...
  • Page 27 MAINTENANCE AND TROUBLESHOOTING DC positive connection Welding current Gas nozzle Gas flow Gas nozzle Gas flow range/A diameter/mm rate/L·min diameter/mm rate/L·min 10～100 4～9.5 4～5 8～9.5 6～8 101～150 4～9.5 4～7 9.5～11 7～10 151～200 6～13 6～8 11～13 7～10 201～300 8～13 8～9 13～16 8～15 Notice: the above parameters originate from《Welding Dictionary》P149, Volume 1 of Edition 2.
  • Page 28 MAINTENANCE AND TROUBLESHOOTING Corner 175～250 joint Notice: the above parameters originate from《Welding Dictionary》P150, Volume 1 of Edition 2. Parameters of piping back sealing welding for mild steel （DCEP） Argon Welding Piping Tungsten Welding Gas nozzle Welding flow rate rate diameter electrode wire diameter/mm...

  • Page 29: Operation Environment

    MAINTENANCE AND TROUBLESHOOTING 180～ － 3～4 10～15 10～12 240～ － 16～20 14～16 260～ 4～5 16～20 14～16 100～ 280～ 4～5 16～20 14～16 150～ 300～ 4～5 5～6 18～22 16～20 180～ 340～ 5～6 5～6 20～24 16～20 200～ 340～ 5～6 20～24 16～20 200～ 360～ 5～6 25～30 16～20...

  • Page 30: Maintenance & Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING ● Connect the ground wire with the machine directly, and refer to §3.5. ● In case closing the power switch, no-load voltage may be exported. Do not touch the output electrode with any part of your body. ●...

  • Page 31: Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING any difference and it has affected the normal welding craft, please adjust it. Check up that Whether fan is damaged and is normal to rotate or control. If the fan is damaged, please change immediately. If the fan does not rotate after the arc welding machine is overheated , observe that whether there is something blocked in the blade, if it is blocked, please get rid of ;...
  • Page 32 MAINTENANCE AND TROUBLESHOOTING If there are some simple troubles of WSME-series welding machine, you can consult the following overhauling chart: Troubles Reasons Solution The power light damaged or connection is Check and repair Pr7 Turn on the power source, and not good fan works, but the power pilot lamp is not on.
  • Page 33 MAINTENANCE AND TROUBLESHOOTING Troubles Reasons Solution Something in the valve Remove it Electromagnetic valve is damaged Change it The gas-test on the front panel is on The gas-test on the front panel is off Something in the valve Remove it Gas always flows Electromagnetic valve is damaged Change it...

  • Page 34: Electrical Principle Drawing

    MAINTENANCE AND TROUBLESHOOTING §5.3 Electrical principle drawing...
  • Page 35 MAINTENANCE AND TROUBLESHOOTING...
