Introduction:

Micro digital video recorder (DVR) with built-in 2GB memory and extra Micro SD slot. Ideal for

portable use or setting of cameras on location. Also suitable as video player and MP3 player.

Description:

1. Power ON/OFF button

2. MIC (NOT IN USE)

3. Volume - button

4. Volume + button

5. ESC (escape) button

6. MODE button

7. LED indicator

8. Forward button

9. Play/Pause button

10. Rewind button

11. LED indicator

12. Micro SD card slot

13. USB port

14. Camera input

15. Loudspeaker

16. Reset button

17. Audio/Video output

Table of Contents

Need help?

Do you have a question about the PDR25M and is the answer not in the manual?

Questions and answers

Summary of Contents for Security PDR25M

Page 1 Introduction: Micro digital video recorder (DVR) with built-in 2GB memory and extra Micro SD slot. Ideal for portable use or setting of cameras on location. Also suitable as video player and MP3 player. Description: 1. Power ON/OFF button 10. Rewind button 2.
Page 2 Operation: 1) Before first operation connect the DVR to a power source (via USB of PC or with supplied AC/DC adapter) to fully charge the battery. The LED indicators are flashing blue. Charging will take about 5 hours. We recommend charging the battery while the DVR is switched off. The LED indicators will turn off when charging is completed.
Page 3 Power mode 1) Push the volume - or + button to change to never, 30, 60 or 180 seconds. 2) Push the play/pause to confirm. For power saving mode select the option 30, 60 or 180 seconds. If no button is pushed during the selected period, then the DVR will go into standby mode.
Page 4 Specifications: Video compression: MPEG4 Video play support: ASF (MPEG4), AVI (DIVX, XVID), 3GP, MP4 Audio play: MP3 Built-in flash memory: 2GB Power supply: Li-ion battery Camera input: 3.5mm (video, audio, power 3-5VDC) AV output: 3.5mm (video, audio) LCD: 2.4" TFT USB port: 2.0 Dimensions: 83.5x50.2x12.5mm PC system requirements:...
Page 5 To reduce the risk of electric shock, this product should ONLY be opened by an authorized technician when service is required. Disconnect the product from mains and other equipment if a problem should occur. Do not expose the product to water or moisture. Maintenance: Clean only with a dry cloth.
