Summary of Contents for Blickfeld Qb2
- Page 1 Q U I C K S TA R T M A N U A L A N D S A F E T Y I N F O R M AT I O N...
- Page 2 Publ. #49039-EN-Rev1.0-20230517 This manual contains information necessary to safely mount, install and start up the Qb2 LiDAR sensor manufactured by Blickfeld GmbH. It provides important information regarding the use of said product and is intended for qualif ied person- nel that is familiar with the local work safety regulations and general safety regulations for laser products.
-
Page 3: Table Of Contents
Technical data ................Installation ............11 Requirements ................11 Mounting ..................11 Electrical installation ............. 12 Accessing the Qb2 Web Interface ....13 Service and Maintenance ........ 15 Service and repair information ........15 Cleaning ..................15 Storage and disposal ........16 Storage ................... -
Page 4: Safety Information
LiDAR technologies, the Qb2 is a precise optical measuring device and must be handled with care. The Qb2 is a scanning LiDAR sensor with a built-in laser that emits pulses of laser beams with a wavelength of 905 nm, which is invisible to the human eye. - Page 5 • The Qb2 is not permitted to be used in potentially explosive or corrosive environments. • The Qb2 is not a safety component within the scope of the Machinery Directive (2006/42 EC) or comparable regulations. • Prevent strong shaking or vibrations, e.g. due to dropping of the Qb2 as this can permanently damage the optical components.
- Page 6 Safety information The Qb2 is a Class 1 laser product according to EN/IEC 60825-1 Ed. 3 2014. Invisible laser radiation CAUTION The Qb2 incorporates a Class 3B embedded laser. Any modifications to the Qb2 or incorrect use can increase the level of risk of exposure to hazardous quantities of invisible laser radiation, which may pose a danger to the eyes and skin.
-
Page 7: Use Restrictions
Safety information • Custom electrical installations must be carried out by qualified electricians. • Never try to operate the Qb2 if an obvious damage of the device or its protective enclosure is discernible. Hot surface! CAUTION During and shortly after operation the mounting surface of the Qb2 can be hot enough to poten- tially cause skin burn. -
Page 8: Product Description
Product description Product description Product overview QB2-AWP-ST1xxx QB2-AWP-ETRxxx Fig. 1 Figure 1 Qb2 overview. Qb2 front (left), back (center and right). Optical aperture (f ront) M12 Ethernet port Antenna port Venting membrane. -
Page 9: Technical Data
Product description 2.2 Technical data Model No. QB2-AWP-ST1xxx QB2-AWP-ETRxxx Class 1 (IEC 60825-1:2014, Ed. 3) Laser class Typ. 10 W (max. 13 W) Power consumption Power over Ethernet Operating voltage Type 1 PD (IEEE 802.3at) 8-pin M12 Industrial Ethernet connector,... - Page 10 Product description Model No. QB2-AWP-ST1xxx QB2-AWP-ETRxxx Ca. 400 g / 0.882 lb Ca. 535 g / 1.18 lb Weight Ca. 75 mm x 111 Ca. 75 mm x 111 Dimensions mm x 53 mm / mm x 83 mm / 2.95 in x 4.37 in x...
-
Page 11: Installation
• For the data connection, a shielded Ethernet cable of Cat. 5E or higher is required. • For operating the Qb2, Power over Ethernet must be available. The corresponding equipment must support Type 1 powered devices (IEEE 802.3at) and be certified according to the local safety standards and regulations. -
Page 12: Electrical Installation
Installation • Make sure that the device is only accessible for trained and authorized personnel. • Do not place the Qb2 in the immediate vicinity of sources of magnetic fields as this might hamper measurement accuracy or lead to malfunction. -
Page 13: Accessing The Qb2 Web Interface
The Qb2 is factory-conf igured to be reachable Note under the following address: 1. The preset static IP configuration of the Qb2 is: • IP address: 192.168.26.26 (fallback IP) • Subnet mask: 255.255.255.0 (/24) If the network or host computer does not support link local... - Page 14 Open an Internet browser such as „Mozilla Firefox“ or „Google Chrome“. Enter the address "http://192.168.26.26/". Æ You are now connected to the WebGUI of the Qb2. If the Qb2 is used in non-DHCP mode, it is Note strongly recommended to change the network- ing mode of the Qb2 to static and configuring a custom IP address different from the fallback IP.
-
Page 15: Service And Maintenance
Service and Maintenance Service and Maintenance Service and repair information • The Qb2 contains no parts serviceable by the user. • Any repair procedures may only be performed by Blickfeld-authorized technicians. • Do not open the sensor under any circumstance. -
Page 16: Storage And Disposal
• For disposal, customers located in Germany have the option to return decommissioned devices to Blickfeld. Please contact support@blickfeld.com for further information. Information on the WEEE Directive 2012/19/EU for... -
Page 17: Customer Service / Support
Customer service / support Customer service / support Please do not send devices to Blickfeld without having been requested to do so. Contact the Blickfeld Support via support@blickfeld.com for technical support or repair requests. -
Page 18: Compliance Information
Compliance Information Compliance Information EU Declaration of Conformity Hereby, Blickfeld declares that the radio equipment type Qb2 is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: https://www.blickfeld.com/resources/ 8.2 UK Declaration of Conformity...
