Summary of Contents for Flash Media M FUH Series
Page 1
User Manual Digital Signage Menu Board M**FUH...
Page 2
Safety instructions : In order to ensure the reliable use of the equipment and the safety of personnel, please comply with the following during installation, use and maintenance: System grounding: The system must have perfect grounding. Otherwise, not only signal interference, instability or mechanical damage, but also personal accidents may be caused by leakage.
Overview 1.1 Product Introduction Digital signage adopts LG original IPS commercial panel, 450 cd/㎡ , the wider color range and high restoration showing professional image quality in any lighting environment. Anti- spot tech ensures a long- term well performance without black spot. Built- in GTV publishing system makes multi- terminals remote control comes true.
Page 5
05 VGA 06 AUDIO IN 07 USB 08 USB 09 WIFI 10 3G/4G...
Installation 2.1 Product unboxing Due to the large size and heavy weight, we suggest at least two people in handling. Since the display panel is fragile and easily scratched, please handle it gently. Do not place the product face down without a protective pad. After unpacking, check that the carton contains the following items: Panel * Warranty...
2.1.1 wall mounting The installation instructions are for reference only (the picture below is a schematic diagram of the 43-inch product wall hanging): Choose a suitable location on the wall, determine the installation hole position, install the hanging board on the wall, pay attention to the level of equipment(when using the wall hanging board on the wooden wall, it should be noted that the thickness of the wooden wall is at least 3 cm, and the load-bearing capacity is 100 kg).
Section 3 User Guide 3.1 Turn on the power Power connector Power switch key When the machine is connected with power supply, turn on the power switch key to light up the machine for use. (The above is a schematic diagram of the power interface of the 43-inch product for reference) 3.2 Remote control introduction For the convenience of use, most of the operations on the device can be completed through the...
Page 9
Section 4 OSD menu function introduction By default, the main interface of the digital signage is entered as follows: Current playback status information are displayed on the top left, time and date are displayed on the top right. These information is displayed from left to right at the bottom of the page(Including apk version information, firmware version information, IP information, local storage information, etc.) The working mode defaults to wired mode.
Page 10
4.1.1 screen rotation On this page, move the cursor to the [Screen Rotation] menu, press the left and right keys to select the screen mode, and press the OK key to adjust the screen display direction, which must be consistent with the actual display mode. 4.1.2 Working mode Move the cursor to the 【Working Mode】menu, the terminal platform can work in stand-alone or networked conditions.
Page 11
Note: In different working modes, the content that can be set in the OSD menu will be different Stand-alone: The terminal is not connected to the Internet and runs on a stand-alone, and does not support network-related functions and settings. Wired network: The terminal is connected to a wired LAN, supports wired ...
Page 12
4.1.3 Server Settings Here you can choose the connection mode between the terminal system and the server platform, and set related parameters. When the server platform management software is different, the "Server Settings" interface has different settings. The server platform management software can be selected in [Advanced Settings >...
Page 13
Set date:: Select the [Time Setting] module and press the OK key to enter the time setting interface. Move the cursor to the date display box and press the enter key to open the date adjustment panel. Press the "+/-" button to adjust the date, after the adjustment is completed, press 【OK】 to save ...
Page 14
adjustment panel. Press the "+/-" button to adjust the time, after the adjustment is completed, press 【OK】to save. set time zone Move the cursor to the time zone option and press the enter key to open the time zone selection panel.
When this function is enabled, the system of server execute the time synchronization function after starting up, and automatically synchronize the server’s time to the terminal; otherwise, the network time will not be synchronized after starting up. Synchronize network time immediately: Move the cursor to "Synchronize Network Time Now", press the OK button, and the system will start to synchronize network time.
Page 16
Real-time clock display: The terminal interface can choose whether to display the current time, here you can set the display position of the real-time clock. Upper Left/Bottom Left/Upper Right/Bottom Right: Display the real-time clock on the upper left, lower left, upper right or lower right of the screen. Off: The terminal screen does not display the real-time clock.
Page 17
Machine ID: The system supports modifying the ID of the host. Play log: Set whether to enable the play log function. After enabling, the terminal system will record the broadcasting status of the program and upload it to the server platform.
Page 18
Off: Scrolling subtitles are not supported, and scrolling subtitles will never be displayed on the screen. Always On: Support scrolling subtitles, the system will automatically play the scrolling subtitles according to the actual situation of the playlist. If the playlist contains scrolling words subtitles are displayed;...
Page 20
4.2.2 Timed switch machine The system supports setting timer switch. Two modes are supported: daily mode and weekly mode. Daily Mode: After setting, the system will start or shut down at the set time every day. For example: it can be set to turn on at 8:00 every morning and turn off at 22:00 in the evening.
Page 21
Timing: Turn on or off at a specified time. After selection, 5 groups of on/off time will be displayed at the bottom, and each group of time can be independently set to start time, shutdown time and whether it is "on" or "off". Normally open: When connected to the power supply, the terminal is always on and never automatically shuts down Always Off: The terminal is always off and never automatically turns on.
Page 22
Take setting the power on and off time on Monday as an example, select the [Monday] option, and then select the power on and off mode. The descriptions of each mode are as follows: Timing: Turn on or off at a specified time. After selection, 5 groups of on/off time will be displayed below, and each group of time can be set independently.
Page 23
After the volume policy is enabled, the volume can be set for up to 5 time periods. Turn on the time zone first, then set the volume, and the tone The start time and end time of the volume application.
4.2.3 Network Settings Obtain IP method: When the terminal working mode is wired network, you can set the wired network IP acquisition method. This menu cannot be entered in other modes. There are two ways to obtain the IP of the terminal: automatic and manual。 TCP port: TCP port information, for viewing only, not editable.
Page 25
4.2.4 Server Settings If there is a separate file server, the address of the file server can be set here. The default is off. 4.2.4 Management software The working mode is wired network or wireless network, and the server platform management software can be selected.
4.2.4 File Management In the file management menu, you can view the usage information of the built-in memory and format the disk. Select [Format] and press the confirm key to format the built-in memory. 4.3 Stand-alone play programs 1. Press the menu button on the remote control to enter the OSD menu -> select system management ->...
Page 27
3. When the copying is over, confirm whether the number of copied materials displayed is consistent with the number copied to the U disk. 4.According to the prompt, the machine will automatically play the program after removing the U disk. (Remarks: If you want to play programs in a specified order, you need to name the material to be played as 1, 2, 3...
Page 28
2、Select Publish quickly. 3、Select a suitable template in the system template. (You can also choose to create a suitable template in the user template) Click Next. 4、Add the corresponding materials, select to save, and click to select the next step.
Page 29
5、First select the corresponding terminal, then adjust the release strategy, and finally click Confirm Release.
Section 5 Safety and Maintenance The voltage, frequency and current requirements indicated on the manufacturer's label must be met. Failure to observe these limits and connection to an unspecified power source could result in abnormal operation, equipment damage, or fire. Repairs should only be performed by a qualified service technician.
Page 31
This monitor is manufactured using very high precision Some pixels on the screen Some screen elements are not lit technology, however, sometimes may not be active. some pixels on the monitor may not display. This is not a malfunction. leave still images Image retention remains on...
Section 6 Service Policy Description of warranty service content: The incoming power supply must meet the voltage, frequency and current requirements indicated on the manufacturer's label. Failure to comply with these requirements and connection to an unspecified power source may result in abnormal operation of the equipment, damage, or fire. Repairs should only be performed by qualified technicians.
