USER'S MANUAL
Start Guide
Installation the battery
1. Make sure your radio is turned OFF.
2. Remove the battery compartment door.
3. Install the 4 NiMH rechargeable battery or 4 AAA Alkaline batteries into the
battery compartment.
4.Replace the battery compartment door.
Basic radio operations
1. Press
to turn on.
2. Press
to enter the channel settings, the channel display pattern starts flashing,
to select. Press PTT to confirm and exit.
with
3. Press
twice to enter the setting. OFF for no code, 01~38 for CTCSS code,
39-99 for DCS code.
4. Press
for 3 times to enter the Vox function selection. there are OFF,
1,2.3 these 3 gear sensitivity optional.
5. Press
for 4 times to enter the CALL tone selection function. They are 01 to 10
sounds available.
6. Press
for 5 times to enter the key tone selection function, select the button
when the ON button will beep a tone, select the OFF button when there is no tone.
7. Press
for 6 times to enter the launch end of the tone selection function, with
to select. select ON to release the PTT will have a tone, the opposite choice
of OFF there is no tone.
8. Press
for 7 times and exit can also press PTT to confirm the exit menu.
Note:
It doesn't has charging function , it can't be charged directly through charger
base and so on , it only can be charged by a NiMH vrechargeable battery.
When installing the battery, please pay attention to the corresponding positive and
negative placement!
Model: H - 388
Channel/Menu Indicator
Tx/RX Icon
Scan Indicator
Vox indcator
Antenna
1. Transmit call tone
2. Lock and unlock
the keypad(when
held down and not
in a menu)
Speaker
2
Product
Battery Level meter
CTCSS /DCS
Volume
Key Lock Indicator
LCD
1. Power button
Open or close
walkie-talkie
2. Menu button
Select menu options
1. Press it momentarily
to turnon the LED
2. Press and hold it to
enable the scanner
Up/Down Button
Flashing LED
1. PTT Button
(Push to talk)
2. .Save a setting
1
3
