ADIR ADIKI300-01 Series User Manual

Paper roll dispenser
Hide thumbs

Advertisement

Quick Links

PAPER ROLL DISPENSER
(5-ROLLS)
USER G UIDE
ADIKI300-01-SERIES

Advertisement

loading
Need help?

Need help?

Do you have a question about the ADIKI300-01 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for ADIR ADIKI300-01 Series

  • Page 1 PAPER ROLL DISPENSER (5-ROLLS) USER G UIDE ADIKI300-01-SERIES...
  • Page 2 Thank you for your purchase. AdirKids commits to delivering safe and quality children’s products. We pride ourselves on creating uniquely exquisite products for your children that they will enjoy for many years to come. Furnishing your child’s room or classroom can be expensive and stressful, but we’ll help make the process affordable and stress-free.

  • Page 3: Table Of Contents

    Table of Contents Parts Hardware Assembly Instructions Loading Paper Cutting Paper Warranty...

  • Page 4: Parts

    Parts Bottom Spring Arm Bottom Frame (x5) Top Frame Top Spring Arm (x5) Caster Wheel (x5) Roll Rest (x5) Vertical Pole (x5) Cutter Blade (x5) Paper Roll Rod (x5) Bottom Bracket (x5)

  • Page 5: Hardware

    Hardware Screw (M6*10) (x25) 8 mm Wrench M6 Capped Screw Nut (x10) 6 mm Wrench Screw (M6*35) (x10) Washer (x10) M8 Screw Nut (x5) M8 Capped Screw Nut (x5) Screw (M8*80) (x5)

  • Page 6: Assembly Instructions

    Assembly Instructions Step 1: A. Locate Bottom Frame (A) and place it on a flat, clean surface. B. Take one of the Bottom Spring Arms (B) and attach it to the Bottom Frame (A) with two Screws (M6*10) (1). a. Use the 6 mm Wrench (4) that was included to secure the screw in place C.
  • Page 7 Step 2: A. Locate the Top Frame (C) and a Top Spring Arm (D). B. Attach one of the Top Spring Arm’s (D) to the Top Frame (C) with two Screws (M6*10) (1) . a. Use the 6 mm Wrench (4) that was included to secure the screws in place.
  • Page 8 Step 3: A. Locate the Caster Wheels (E), and these will be affixed to the Bottom Frame (A). B. Take one of the wheels and insert it into the predrilled hole located on the outer ring of the Bottom Frame, as pictured. C. Affix it using M8 Screw Nut (7); secure it in place with the included 6 mm Wrench (4). D. Repeat these steps for the remaining Caster Wheels (E).
  • Page 9 Step 4: A. Locate a Roll Rest (F) and place it on the inner ring of the Bottom Frame, as pictured. a. Each Roll Rest (F) will go between where each Vertical Pole (G) will be installed. B. Affix it to the frame using a Screw (M8*80) (9), an M8 Screw Nut (7), an M8 Capped Screw Nut (8), and the included 8 mm Wrench (2). C. Repeat this step for the remaining four Roll Rests (F).
  • Page 10 Step 5: A. Locate a Vertical Pole (G): this will be installed in one of the predrilled holes on the inner ring, adjacent to the crossbar connecting the outer ring. B. Affix the Vertical Pole (G) with a Screw (M6*35) (5) using the included 6 mm Wrench (4). C. Repeat this step for the remaining four Vertical Poles (G).
  • Page 11 Step 6: A. Take a Bottom Bracket (J) and slide it down the Vertical Pole (G). B. The horizontal piece of the Bottom Bracket (J) should be facing out towards the outer ring. C. Push down firmly so that it is secure on the crossbar and tighten the screw on the bracket.
  • Page 12 Step 7: A. Take the Top Frame (C) and place it on top of the Vertical Poles (G). B. Affix the Vertical Poles (G) to the Top Frame, aligning them with the smaller predrilled holes. C. Using five Screws (M6*35) (5), secure them in place with a 6 mm Wrench (4).
  • Page 13 Step 8: A. Handling with care, take a Cutter Blade (H), and attach it to the Top Spring Arm (D) and Bottom Spring Arm (B), as pictured. B. Secure it in place with an M6 Capped Screw Nut (3), and utilize the 6 mm Wrench (4). C. Repeat this step for the remaining four Cutter Blades (H). D. Repeat this step at the bottom end to ensure both the top and bottom have the screws to affix the blade.
  • Page 14 Step 9: A. Insert the five Paper Roll Rods (I) into the Top Frame (C), as pictured. B. Your Paper Roll Dispenser is now ready to be used.

  • Page 15: Loading Paper

    Loading Paper Step 1: A. Remove one of the Paper Roll Rods (I) and position your paper roll on top of the Roll Rest (F) located on the Bottom Frame (A). B. The hole in the paper roll should be placed on top of the short, upright spindle located on the Roll Rest (F). a. This will anchor and position your roll for cutting.

  • Page 16: Cutting Paper

    Step 2: A. Insert the Paper Roll Rod (I) through the Top Frame (C) and into the top end of the paper roll. B. If needed, repeat the above steps for the remaining Paper Roll Rods (I). Cutting Paper Step 1: A. To cut your paper roll, ensure the Cutter Blade (H) is positioned so that both points of the V-shaped blade make contact with the roll. a. If needed, you can swivel the blade into position.

  • Page 17: Warranty

    Warranty Adir Corp (the “Company” or “Tiger Companies”) warrants to the purchaser that the product will be free from defects in workmanship and materials for a period of 1 year from the date of purchase. The warranty period is not extended if we repair, replace, exchange, or provide a refund for the product (as determined in our sole discretion).
  • Page 18 ADIKI300-01-SERIES © 2023 AdirCorp adircorp.com...
