Quick Start Guide: FlexRadio Cabinet
1
Assemble
A FlexRadio Cabinet assembly requires a single FlexRadio Cabinet, omni directional
antenna, 6 foot coaxial cable, and the bracket/DIN mount kit.
2
Install FlexRadio Cabinet
1608 4th Street Suite 200 Berkeley CA 94710
FlexRadio Cabinet Installation Parts
DIN Mount
Use the Sensys Networks provided DIN or bracket mounts to install the FlexRadio Cabinet inside the traffic cabinet.
Refer to Assembly Instructions Bracket and DIN Mounts for more information.
M3x4 mm screw x 4
Rail x 2
Bracket Mount
Install FlexRadio Cabinet
|
info@sensysnetworks.com
Tools Required
FlexRadio Cabinet requires the following tools for installation:
• #2 Phillips bit screwdriver
• ⅞ in ( 2.22 cm) hole saw or step drill bit with power drill
• Hand wrench
|
