Toolshop 208-2198 Operator's Manual

1-3/4" coil roofing nailer
Hide thumbs

Advertisement

Table of Contents

208-2198
1-3/4" COIL ROOFING NAILER
Operator's Manual
SAVE THIS MANUAL
You will need this manual for safety instructions, operating procedures and warranty.
Put it and the original sales receipt in a safe dry place for future reference.
For questions about this product, Please call 1-866-915-8626

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 208-2198 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Toolshop 208-2198

Summary of Contents for Toolshop 208-2198

  • Page 1 208-2198 1-3/4" COIL ROOFING NAILER Operator’s Manual SAVE THIS MANUAL You will need this manual for safety instructions, operating procedures and warranty. Put it and the original sales receipt in a safe dry place for future reference. For questions about this product, Please call 1-866-915-8626...

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS INSTRUCTIONS PERTAINING TO A RISK OF FIRE, OR INJURY TO PERSONS. WARNING! When using tools, basic precautions should always be followed, including the following. WORK AREA Keep the work area clean and well lit. Cluttered benches and dark areas increase the risk of electric shock, fire, and injury to persons.
  • Page 3 IMPORTANT SAFETY INSTRUCTIONS WARNING! Remove finger from the trigger when not driving fasteners. Never carry the tool with finger on trigger, the tool may fire a fastener. TOOL USE AND CARE Know this tool. Read manual carefully, learn its application and limitations, as well as the specific potential hazards related to this tool.

  • Page 4: Tool Service

    IMPORTANT SAFETY INSTRUCTIONS Always assume the tool contains fasteners. Respect the tool as a working implement; no horseplay. Always keep others at a safe distance from the work area in case of accidental discharge of fasteners. Do not point the tool toward yourself or anyone whether it contains fasteners or not.

  • Page 5: Specifications

    IMPORTANT SAFETY INSTRUCTIONS Use only a pressure-regulated compressed air source to limit the air pressure supplied to the tool. The regulated pressure must not exceed 110 PSI. If the regulator fails, the pressure delivered to the tool must not exceed 120 PSI. The tool could explode which will cause death or serious personal injury.

  • Page 6: Operating Procedures

    OPERATING PROCEDURES SETUP AIR SOURCE The TOOL SHOP 1-3/4” coil roofing nailer is designed to operate on clean, dry, compressed air, regulated at 70-110 PSI. The preferred system would include a filter, a pressure regulator, and an automatic oiler located as close to the tool as possible. Within 15 feet (5 m) is ideal.

  • Page 7: Loading Nails

    OPERATING PROCEDURES LOADING NAILS CAUTION: Do not load with contact safety mechanism or trigger depressed. Fig.4 Push down on the latch 1 (Fig.4), swing the latch 1 (Fig.5), then open the movable cover 2 (Fig.4). Fig.5 2. Open the magazine cover. ( Fig.6 ) Fig.6 3.

  • Page 8: Regular Maintenance

    OPERATING PROCEDURES Complete all the steps in PREPARING THE TOOL before using. Please Note: This tool is fired in only one way: BUMP FIRE: The tool should only fire if the Safety Nosepiece is pressed against the workpiece and the trigger is pulled. It should fire again if the trigger is Fig.8 released and pulled OR if the safety is lifted and pressed against the workpiece again.

  • Page 9: Troubleshooting

    TROUBLESHOOTING PROBLEM CAUSE SOLUTION Air leak at trigger area O-ring in trigger valve Check and replace O-ring damaged or cracked Trigger valve head damaged Check and replace trigger valve head Trigger valve stem, seal, or Check and replace trigger valve stem O-ring damaged Air leak between body and Piston O-ring or bumper...

  • Page 10: Parts List

    PARTS LIST DESCRIPTION DESCRIPTION DESCRIPTION ITEM NO. ITEM NO. ITEM NO. Screw 5*16 Catch Guide Plate Washer Spring Pin 3*12 Release Catch C O-Ring 16*1.7 Prevent fall frame(B) Catch Guide Plate Exhaust Cover Prevent fall frame(B) Screw 4*12 Magazine Washer Release Catch B Pin 3*28 Screw 6x30...

  • Page 11: Schematic Drawing

    SCHEMATIC DRAWING WARNING Repairs should be made by an authorized repair center.Do not open or disassemble this power tool.
  • Page 12 TOOL SHOP 1-3/4" COI L ROOFING NAILER WARRANTY...
