Main Board Remove
The PBA can only be replaced at an authorized repair shop. If the PBA is faulty,
contact Samsung for further instruction.
1
Check the screws at the 4 different points and remove them using a cross-head
screwdriver.
When removing the screws, be careful not to damage the camera lens and cover.
Check the number of screws that have been removed, and store them carefully to
make sure that no unassembled screws are left inside the device during assembly.
2
Using the tweezers, disconnect the laser AF module's connector.
Disassembly and Assembly
64
