Remove all adhesive tapes and these tapes are located around the edges of the back
cover ( ).
Be careful not to put your fingertips or any foreign objects on the rear camera or
•
back cover lens ( ).
Make sure to remove any residual tape ( ) attached to the inside of the back
•
cover before reassembling the device.
Apply additional heat if you are having trouble separating the adhesive.
After you finish disassembling, refer to
reassemble.
Disassembly and Assembly
Back Cover Assembly
for how to
