KL1100 Keypad - Programming and Operating Instructions
Table of contents
Overview
Penalty Time
Batteries
Access Methods
Code Clients
The KL1100 Keypad has four Code Client levels
Master Code Client (8 digits)
Sub-Master Code Client (8 digits)
Technician Code Client (6 digits)
User Code Clients (4 digits)
Functions
Operating Instructions
Change the Master Code (Private & Public Function)
Set or Change the User Code (Private Function)
Delete a User Code (Private Function)
Set or Change the Sub-Master Code (Private & Public Function)
Delete the Sub-Master Code (Private & Public Function)
Auto-Unlock (Public Function)
Auto-Unlock At a Set Time (Public Function)
Disable Auto-Unlock At a Set Time (Public Function)
https://codelocks.zohodesk.eu/portal/en/kb/articles/kl1100-keypad

Advertisement

Table of Contents
loading

Summary of Contents for D&D Technologies CodeLocks KL1100

  • Page 1 Codelocks Support KL1100 Keypad - Programming and Operating Instructions Table of contents Overview Penalty Time Batteries Access Methods Code Clients The KL1100 Keypad has four Code Client levels Master Code Client (8 digits) Sub-Master Code Client (8 digits) Technician Code Client (6 digits) User Code Clients (4 digits) Functions Operating Instructions ...

  • Page 2: Penalty Time

    Set or Change Date & Time Restrict Opening Time Change Locked Indication (Public Function) Troubleshooting Factory Reset Keypad Method (Private & Public Function) Manual Method Firmware Check Overview Penalty Time Inputting an incorrect Code 3 times will incur a 10 second time delay before any further use is possible. Batteries The KL1100 Keypad uses 4 x AA batteries.
  • Page 3 Opens the Lock (deletes current User Code Client in Public Function) All programming including Technician and User Code Client registration The default Master Code Client is 11335577 Sub-Master Code Client (8 digits) Opens the Lock (deletes current User Code Client in Public Function) Limited programming including Technician and User Code Client registration Technician Code Client (6 digits) Opens the Lock (retains current User Code Client in Public Function)
  • Page 4 Recommended: The Master Code can be used to change all settings and should be kept safe and not shared. Change the Master Code (Private & Public Function) #Master Code ● ● New Master Code ● New Master Code ● ● Example: #11335577 ●...
  • Page 5 #Master Code ● ● ● ● Example: #11335577 ● ● ● ● Result: The Sub-Master Code has been disabled. Auto-Unlock (Public Function) #Master Code ● ● Time <01-24> hours ● ● Example: #11335577 ● ● ● ● Result: The lock will automatically unlock 6 hours after being locked Disable Auto-Unlock (Public Function) #Master Code ●...
  • Page 6 NOTE : DST is not supported. Restrict Opening Time #Master Code or Sub-Master Code ● 18 ● HHmm (Start) ● HHmm (End) ● ● Example: #11335577 ● 12 ● 0830● 1700 ● ●  Result: User Code can only be used between 08:30 and 17:30. Change Locked Indication (Public Function) #Master Code ● ● Disable or Enable <00 or 01> ●...

  • Page 7: Troubleshooting

    Result: The lock will operate in Public Function, remaining unlocked until a User enters their own Code (twice) to lock. Public Function (Single Entry) #Master Code ● ● ● Example: #11335577 ● ● ● Result: The lock will operate in Public Function, remaining unlocked until a User enters their own Code (once) to lock Private Function #Master Code ●...

  • Page 8: Factory Reset

    20% - 50% ● ● ● ● <20% ● ●  Battery Failure After a Code is entered, the red LED will flash 3 times to indicate low power. The KitLock will operate for a further 100 openings. The batteries should be replaced as soon as possible. Battery Failure Override The KL1100 KeyPad has been designed so that a mobile power bank can be used to open the lock to allow access to the batteries so they can be replaced should they fail.

  • Page 9: Firmware Check

    Result: All User Codes will have been deleted, the Sub-Master and Technician Codes disabled and all settings reverted to factory default. The Master Code will be 11335577 and a single User Code of 2244 will be available. The lock will be in Private Function. Firmware Check To check the firmware version installed on the lock.
