Phoenix EcoMod 3 Series Installation Instructions

!
CAUTION
• All wiring should be done by a licensed electrician in accordance with state codes, local codes, and National Electric Code (NEC) standards or International
Electrotechnical Commission (IEC) standards.
• Improper installation may result in serious injury and void warranty.
• Contains parts and assemblies susceptible to damage by electrostatic discharge (ESD).
• If the external flexible cable or cord of this luminaire is damaged, it shall be replaced with a cord with equivalent markings and ratings or a cord exclusively
available from the manufacturer.
• The light source contained in this luminaire shall only be replaced by the manufacturer or his service agent or a similar qualified person.
• To reduce the risk of strangulation the flexible wiring connected to this luminaire shall be effectively fixed to the wall if the wiring is within arm's reach.
• Surge protective devices should be utilized for fixtures installed in environments subject to power surges outside the specified operating parameters.
• Ensure control circuits (dimming circuits) are adequately separated from primary circuits (incoming AC supply circuit) when installing control devices or
control wiring.
Weight & Dimensions
LO - 31.0 lb (14.1 kg)
HI - 39.6 lb (18.0 kg)
MAX - 49.2 lb (22.3 kg)

EPA (wind load) Values

LO - 1.7 sq. ft. (0.2 m2)
HI - 2.0 sq. ft. (0.2 m2)
MAX - 2.7 sq. ft. (0.3 m2)
LO Model
18.64 in (473 mm)
HI Model
18.64 in (473 mm)
MAX Model
25.53 in (648 mm)
Phone: +1 414.973.3300 Toll Free: 800.438.1214 Fax: +1 414.973.3210 www.phoenixlighting.com
EcoMod
®
Installation Instructions
Phoenix Lighting 8711 West Port Avenue Milwaukee, WI 53224 USA
3 Series
12.23 in (311 mm)
12.27 in (312 mm)
13.87 in (352 mm)
