Summary of Contents for Hyundai Electric HYU-CC-CHBF12001
- Page 1 CAMERA QUICK INSTALLATION GUIDE HYU-CC-CHBF12001...
- Page 2 Camera Quick Installation Guide Remind： Fix expansion rubber plugs to the wall first if it is concrete wall. Install it directly with screws if it is a wooden wall. The installation of all terminal equipment such as control, display, and recording of the camera should be smooth and easy to operate.
- Page 3 Conch Series Quick Installation Guide Large Waterproof Series If you have an external card slot, loosen the two screws first, remove the card cover, attach the memory card, and finally lock the card cover. Rear Mounting Bracket Installation Fix the bracket to the Adjust the viewing angle.
- Page 4 Camera Quick Installation Guide Bottom Mounting Bracket Installation Adjust the viewing angle. Loosen the Fix the camera to the bracket with screws at A/B to adjust the angle (A for screws. The bracket head can be horizontal angle, B for vertical angle). pre-mounted or post-mounted, Tighten the screws to complete the and then fixed to the wall with 4...
- Page 5 Conch Series Quick Installation Guide Swing the bottom cover to the right. Secure the bottom cover Adjust the viewing angle. with 4 screws to the top wall. Screw the main body into the base to complete the installation.
- Page 6 Small Hemisphere Series Quick Installation Guide Fast Mounting Bracket Installation Fast Mounting Body Sphere Bracket Fasten the quick Adjust the lens angle by rotating Installation is mount to the wall the sphere and then hang the complete. with screws. machine into the quick mount by rotating the body.
- Page 7 Big Hemisphere Series Quick Installation Guide Top Loading The factory default is the best angle, if you need to adjust: Rotate the movement horizontally Loosen 4 screws and and vertically to adjust the angle. remove the cover. Remove the rubber plug Slide the main body into the and fix the base with 4 screws.
- Page 8 Big Hemisphere Series Quick Installation Guide Wall Mounting Screw the base and bracket mounting Snap the camera body into the plate to the bracket body with screws. base. Fix the camera screw to complete the installation. First remove the fast iron Remove the rubber plug from the from the bracket body and outlet hole, insert the main body of...
- Page 9 Microcomputer Series Quick Installation Guide Loosen 2 screws to separate the bracket from the camera body. Use 4 screws to lock the bracket to the top wall or lock it to the side wall. Use 2 screws to lock the camera body and the bracket together.
- Page 10 SECURITY SHOP Vladimira Popovića 6, 11070 Novi Beograd, Srbija TEL: 011 318 68 68, 066 320015 E MAIL: office@securityshop.rs Imported/Distributed by Security Shop Doo Licensed by Hyundai Corporation Holdings, Korea Delivery and After Service shall only be covered within Serbia...
