USER'S MANUAL
Model iQ2000 Series Dust Collector
with manual shaker
WARNING
Read all the following safety and operating instructions prior to using this unit. Not ob-
serving this information can result in electrical shock, serious physical injury or damage to
equipment. Personal Protective Equipment (Respirator, Safety Glasses, Ear Plugs
etc.) Should Be worn at all time when Operating or Servicing The Dust Collection
Vacuum and Related Equipment
*For Gas powered units refer to Honda Operators Manual for
motor servicing and operation.
