OWNER'S MANUAL
LED LCD MONITOR
(LED Monitor*)
* LG LED Monitor applies LCD screen with LED backlights.
Please read this manual carefully before operating your set and retain it for future reference.
32UN500/32UN500P
32UP50S
32BN50U
32UN50B
32UN50A/32UN50AP
32UN55B
32UN550/32UN550P
32BP57U
Copyright © 2020 LG Electronics Inc. All Rights Reserved.
www.lg.com

Advertisement

loading

Related Manuals for LG 32UN500P

Summary of Contents for LG 32UN500P

  • Page 1 OWNER’S MANUAL LED LCD MONITOR (LED Monitor*) * LG LED Monitor applies LCD screen with LED backlights. Please read this manual carefully before operating your set and retain it for future reference. 32UN500/32UN500P 32UP50S 32BN50U 32UN50B 32UN50A/32UN50AP 32UN55B www.lg.com 32UN550/32UN550P 32BP57U Copyright ©...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS LICENSE Each model has different licenses. Visit www.lg.com for more information on the license. LICENSE ............2 ASSEMBLING AND PREPARING ....3 The terms HDMI, HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.

  • Page 3: Assembling And Preparing

    • It is recommended that use the supplied components. • If you use generic cables not certified by LG, the screen may not display or there may be image noises. Supported Drivers and Software • Illustrations in this document represent typical procedures, so they may look different from the actual product.
  • Page 4 32BP57U 32UN50A/32UN50AP 32BP57U 32UN550/32UN550P Press the joystick button once with your finger 32UN55B Power on to turn on the monitor. 32BP57U 32UN500/32UN500P 32UN50A/32UN50AP 32UP50S 32BN50U 32UN50B 32UN500/32UN500P 32UN50A/32UN50AP Press and hold the joystick button a few seconds 32UP50S 32BN50U 32UN50B Power off with your finger to turn off the monitor.
  • Page 5 32BP57U Installing on a Table Adjusting the Stand Height 32UN500/32UN500P 32UN50A/32UN50AP • Lift the monitor and place it on the table in an upright position. Place the monitor at least 100 mm (3.94 Place the monitor mounted on the stand base in an upright position.
  • Page 6 Connect the monitor to a table using the Kensington security system cable. 32UN50AP 32UN550/32UN550P The angle of the screen can be adjusted forward or backward from -5° to 15° for a comfortable viewing 32UN55B 32UN500/32UN500P 32UN50A/32UN50AP experience. 32UP50S 32BN50U 32UN50B...
  • Page 7 LSW 149 NOTE • A non-VESA standard screw may damage the product and cause the monitor to fall. LG Electronics is not liable for any accidents relating to the use of non-standard screws. • The wall mount kit includes the installation guide and all necessary parts.
  • Page 8 • Installing the monitor on the ceiling or on a slanted wall may result in the monitor falling off, which could lead to injury. Use an authorized LG wall mount and contact the local dealer or qualified personnel. • Applying excessive force when tightening screws may cause damage to the monitor. Damage caused in this way will not be covered by the product warranty.

  • Page 9: Using The Monitor

    USING THE MONITOR DisplayPort Connection Transmits digital video and audio signals from your PC to the monitor. • Illustrations in this manual may differ from the actual product. NOTE Press the joystick button, go to Settings Input, and then select the input option. •...
  • Page 10 Connecting AV Devices HDMI Connection HDMI transmits digital video and audio signals from your AV device to the monitor. NOTE • Using a DVI to HDMI / DP (DisplayPort) to HDMI cable may cause compatibility issues. • Use a certified cable with the HDMI logo attached. If you do not use a certified HDMI cable, the screen may not display or a connection error may occur.

  • Page 11: User Settings

    USER SETTINGS NOTE • Your monitor’ s OSD (On Screen Display) may differ slightly from that shown in this manual. • When Beep Guide is activated, pressing the joystick button will take you to Settings right away. Activating the Main Menu Press the joystick button on the bottom of the monitor.
  • Page 12 Main Menu Features Main Menu Description Input Sets input mode. Power Off Power Off Turns off the monitor. Settings Configures the screen settings. Exit Input Settings Picture Mode Sets the picture mode. Exit Exits the main menu. Picture Mode Menu Settings To view the OSD menu, press the joystick button at the bottom of the monitor and then enter the Settings.
  • Page 13 Quick Settings Settings > Quick Settings Description Brightness Adjusts the contrast and brightness of the screen. Contrast Adjusts the volume. Volume NOTE • You can adjust Mute / Unmute by moving the joystick button to in the Volume menu. The user can adjust it to red, green, or blue by customization. Custom Warm Sets the screen color to a reddish tone.
  • Page 14 Input Settings > Input Description Input List Selects the input mode. Adjusts the aspect ratio of the screen. Full Wide Displays the video in widescreen, regardless of the video signal input. Original Displays video according to the aspect ratio of the video signal input. Aspect Ratio Just Scan The aspect ratio is not adjusted from the original.
  • Page 15 Picture NOTE • The Picture Mode that can be set depends on the Input signal. [Picture Mode on SDR (Non-HDR) signal] Settings > Picture Description Custom Allows the user to adjust each element. Vivid Heightens contrast, brightness and sharpness to display vivid images. HDR Effect Optimizes the screen for high dynamic range.
  • Page 16 [Picture Mode on HDR signal] Settings > Picture Description Custom Allows the user to adjust each element. Vivid Optimized the screen for HDR vivid colors. Cinema Optimized the screen for HDR video. This mode is optimized for FPS games.It is suitable for very dark FPS games. Picture Mode This mode is optimized for RTS Game.
  • Page 17 Settings > Picture Description Brightness Adjusts the contrast and brightness of the screen. Contrast Sharpness Adjusts the sharpness of the screen. High Optimizes the screen for crystal clear images. Best for high-definition video or games. Optimizes the screen for comfortable viewing, with images at the middle level between the low and high Middle modes.
  • Page 18 Settings > Picture Description Sets a response time for displayed pictures based on the movement of the picture on the screen. For a normal environment, it is recommended that you use Fast. When there is a lot of motion, it is recommended that you use Faster.
  • Page 19 Settings > Picture Description Mode 1, The higher the gamma value, the darker the image becomes. Likewise, the lower the gamma value, the lighter Mode 2, the image becomes. Gamma Mode 3 Mode 4 If you do not need to adjust the gamma settings, select Mode 4. Set your own color temperature.
  • Page 20 Sound Settings > Sound Description Volume To adjust the Volume of headphone or speaker. MaxxAudio® by Waves, recipient of a Technical GRAMMY Award® is a suite of studio-quality sound tools for a superior listening experience. MaxxAudio Disables the MaxxAudio function.
  • Page 21 General Settings > General Description Language Sets the menu screen to the desired language. Conserve energy by using luminance compensation algorithm. High Saves energy using the high-efficiency SMART ENERGY SAVING feature. Saves energy using the low-efficiency SMART ENERGY SAVING feature. SMART ENERGY SAVING Disables the feature.
  • Page 22 Settings > General Description Provides sharper images when connected to a device supporting ULTRA HD Deep Color. 4K@ 60 Hz Support Format Color Depth / Chroma Sampling Resolution Frame rate(Hz) 8 bit 10 bit YCbCr 4:2:0 59.94 YCbCr 4:2:2 3840 x 2160 HDMI ULTRA HD Deep Color 60.00 YCbCr 4:4:4...

  • Page 23: Troubleshooting

    TROUBLESHOOTING Nothing is displayed on the screen. • Is the monitor's power cord plugged in? Check if the power cord is correctly plugged into the power outlet. • Is the power LED on? Check the power cable connection and press the power button. •...
  • Page 24 Do you see an "Unrecognized monitor, Plug and Play (VESA DDC) monitor found" message? • Have you installed the display driver? Be sure to install the display driver from our web site: http://www.lg.com. • Make sure to check if the graphics card supports Plug and Play function.

  • Page 25: Product Specification

    32UP50S 32BN50U 32UN50B 32UN550/32UN550P 32UN55B PRODUCT SPECIFICATION 32UN500/32UN500P 32UP50S 32UN50B 32UN50A/32UN50AP Color Depth 8-bit / 10-bit color is supported. 32BN50U 32BP57U Max Resolution 3840 x 2160 @ 60 Hz Resolution 32UN550/32UN550P 32UN55B Recommended Resolution 3840 x 2160 @ 60 Hz...
  • Page 26 Monitor Size (Width x Height x Depth) 714.3 x 512.3 x 208.8 (mm) With Stand Dimensions 28.1 x 20.1 x 8.2 (inches) 714.3 x 420.0 x 45.7 (mm) Without Stand 28.1 x 16.5 x 1.7 (inches) With Stand 7.7 kg (16.9 lbs) Weight (Without Packaging) Without Stand 6.7 kg (14.7 lbs)
  • Page 27 32UN55B PRODUCT SPECIFICATION 32UN500/32UN500P 32UP50S 32UN50B 32UN50A/32UN50AP 32BN50U 32BP57U Color Depth 8-bit / 10-bit color is supported. 32UN550/32UN550P 32UN55B Max Resolution 3840 x 2160 @ 60 Hz Resolution Recommended Resolution 3840 x 2160 @ 60 Hz Power Rating 19 V 3.3 A...
  • Page 28 32BN50U 32BP57U Monitor Size (Width x Height x Depth) 714.3 x 512.3 x 208.8 (mm) 714.3 x 645.5 x 252.9 (mm) With Stand Dimensions 28.1 x 20.1 x 8.2 (inches) 28.1 x 25.4 x 9.9 (inches) 714.3 x 420.0 x 45.7 (mm) 714.3 x 420.0 x 45.7 (mm) Without Stand 28.1 x 16.5 x 1.7 (inches)
  • Page 29 32UN500/32UN500P 32UP50S 32UN50B 32UN50A/32UN50AP PRODUCT SPECIFICATION 32BN50U 32BP57U 32UN550/32UN550P 32UN55B Color Depth 8-bit / 10-bit color is supported. Max Resolution 3840 x 2160 @ 60 Hz Resolution Recommended Resolution 3840 x 2160 @ 60 Hz Power Rating 19 V 3.3 A On mode: 45 W Typ.
  • Page 30 Monitor Size (Width x Height x Depth) 714.3 x 595.9 x 226.7 (mm) With Stand Dimensions 28.1 x 23.4 x 8.9 (inches) 714.3 x 420.0 x 45.7 (mm) Without Stand 28.1 x 16.5 x 1.7 (inches) With Stand 8.2 kg (18.0 lbs) Weight (Without Packaging) Without Stand 6.7 kg (14.7 lbs)
  • Page 31 Factory Support Mode (Preset Mode, PC) DisplayPort Preset Mode Horizontal Frequency (kHz) Vertical Frequency (Hz) Polarity (H/V) Remarks 640 x 480 31.469 59.94 800 x 600 37.879 60.317 1024 x 768 48.363 1920 x 1080 67.5 2560 x 1440 88.79 59.95 3840 x 2160 66.66...
  • Page 32 HDMI Preset Mode Horizontal Frequency (kHz) Vertical Frequency (Hz) Polarity (H/V) Remarks 640 x 480 31.469 59.94 800 x 600 37.879 60.317 1024 x 768 48.363 1920 x 1080 67.5 2560 x 1440 88.79 59.95 HDMI Preferred timing, HDMI ULTRA HD Deep Color : Off 3840 x 2160 66.66 HDMI Preferred timing, HDMI ULTRA HD Deep Color : On...
  • Page 33 Beep Guide Menu Location Menu Location Menu Location Quick Settings Input - Aspect Ratio - Just Scan 2 2 3 Picture - Picture Adjust - Black Level - Low 3 2 5 2 Quick Settings - Brightness Picture Picture - Picture Adjust - DFC 3 2 6 Quick Settings - Brightness 1 1 1 Slider...
  • Page 34 Menu Location Menu Location Menu Location 3 4 6 6 1 Picture - Color Adjust - Color Temp - Medium 3 4 2 3 General Picture - Color Adjust - Six Color - Blue Saturation Slider Picture - Color Adjust - Color Temp - Cool 3 4 2 4 General - Language Picture - Color Adjust - Six Color - Cyan Hue...
  • Page 35 Menu Location Menu Location General - Power LED - Off 5 3 2 General - Reset to Initial Settings - No 5 11 2 General - Automatic Standby General - Automatic Standby - 8H 5 4 1 General - Automatic Standby - 6H 5 4 2 General - Automatic Standby - 4H 5 4 3...
  • Page 36 Supplier’s Declaration of Conformity Trade Name Responsible Party LG Electronics USA, Inc. (for 32BN50U/32BP57U) Address 111 Sylvan Avenue, North Building, Englewood Cliffs, NJ 07632 E-mail lg.environmental@lge.com The model and serial number of the product are located on the back and on one side of the product. Record them below in case you ever need service.
