INSTALLATION, OPERATION & PARTS
To prevent potential injury and to avoid unnecessary service calls, read this manual
carefully and completely.
CAUTION – We highly recommend a qualified professional install and
service this product.
WARNING – This manual contains important safety information that must
be furnished to the end user of this product. FAILURE TO READ AND
FOLLOW ALL INSTRUCTIONS COULD RESULT IN SERIOUS INJURY.
PC34 OWNER'S MANUAL
SAVE THIS INSTRUCTION MANUAL
Toll Free: 800.636.8866 • Tel: 714.505.1166 • Fax: 714.505.1160
624 South B Street • Tustin, CA 92780
advantageman com
Advertisement
Table of Contents
Related Manuals for Advantage Manufacturing PC34
Summary of Contents for Advantage Manufacturing PC34
- Page 1 PC34 OWNER’S MANUAL INSTALLATION, OPERATION & PARTS To prevent potential injury and to avoid unnecessary service calls, read this manual carefully and completely. CAUTION – We highly recommend a qualified professional install and service this product. WARNING – This manual contains important safety information that must be furnished to the end user of this product.
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Before installing or servicing this electrical equipment, turn power supply OFF. Basic safety precautions should always be followed, including the following: Failure to follow instructions may result in injury. This is the safety-alert symbol. When you see this symbol on your pump manual, look for one of the following signal words and be alert to the potential for personal injury. - Page 3 IMPORTANT SAFETY INSTRUCTIONS WARNING – Pool and spa components have a finite life. All components should be inspected frequently and replaced at least every ten years, or if found to be damaged, broken, cracked, missing, or not securely attached. WARNING – Risk of Electric Shock.
- Page 4 IMPORTANT SAFETY INSTRUCTIONS WARNING – To Reduce the risk of Entrapment hazards: – When outlets are small enough to be blocked by a person, a minimum of two functioning suction outlets per pump must be installed. Suction outlets in the same plane (i.e. floor or wall), must be installed a minimum of three feet (3’) [0.91 meter] apart, as measured from near point to near point.
-
Page 5: General Information
GENERAL INFORMATION INTRODUCTION This manual contains information for the proper installation and operation of the Advantage booster pump. The instructions in this manual mUST be followed precisely. Failure to install according to defined instructions will void warranty. pRODUCT BENEFITS • Pump is exceptionally quiet, and uses up to 40% less electricity than competitive booster pumps. •... -
Page 6: Installation Instructions
INSTALLATION INSTRUCTIONS WARNING – This product should be installed and serviced only by a qualified professional. pUmp LOCATION Typical Installation Note: Plumb the booster Min. of pump upstream of all air 3 feet Cleaner Booster inducing equipment Pump Plumbing Solar From Pool Options System... - Page 7 INSTALLATION INSTRUCTIONS WARNING – hazardous pressure. Pumps, filters, and other equipment components of a swimming pool filtration system operate under pressure. Incorrectly installed filtration equipment and/or components may fail resulting in severe personal injury or death. pLUmBING The filtration system must supply a minimum of 8 gallons per minute (GPM) of water to the booster pump. Do not connect the booster pump inlet plumbing into the top of a horizontal pipe.
-
Page 8: Electrical Warning
INSTALLATION INSTRUCTIONS CAUTION – Risk of equipment damage. If the booster pump is connected downstream from a heater, the booster pump plumbing must be a minimum of three feet in length between the booster pump inlet and the heater. Never connect the booster pump inlet into the three-foot section of heat sink pipe coming directly out of the heater, as this could damage the booster pump and void it’s warranty. -
Page 9: Start-Up And Operation
INSTALLATION INSTRUCTIONS Wiring WARNING – All electrical wiring MUST be in conformance with all applicable local codes, regulations, and the National Electric Code (NEC). Pump MUST be permanently connected to circuit. If other lights or appliances are also on the same circuit, be sure to add their amp loads before calculating wire and circuit breaker sizes. -
Page 10: Maintenance
INSTALLATION INSTRUCTIONS • open any valves at the inlet and outlet of the booster pump before operation • set all filtration system valves in a manner that does not deprive the booster pump of water during operation • do not operate the booster pump without a pressure cleaner connected to the system •... - Page 11 INSTALLATION INSTRUCTIONS Storing pump For Winterization WARNING – To avoid dangerous or fatal electrical shock hazard, turn OFF power to motor before draining pump. Failure to disconnect power may result in serious personal injury or death. 1. Turn booster pump off before turning off the filtration system pump. 2.
- Page 12 INSTALLATION INSTRUCTIONS Removing the Impeller (See Parts Diagram on page 13 of this manual for pump component locations.) 3. To prevent motor shaft from turning, carefully place a 7/16” open-end wrench over the two (2) flats on the end of the shaft. 4.
- Page 13 PARTS LIST FOR PC34 PUMP Ref. No. part No. Description 310101 Drain Plug with O-Ring 310102 Bolt 310103 Volute 310104 O-Ring 310105 Impeller 310108 Shaft Seal Assembly 310109 Seal Plate Assembly 310110 310111 Shaft Adapter 310112 Base Mounting Bolts 310113...
-
Page 14: Troubleshooting
TROUBLESHOOTING motor Will NOT Start – Check For: Make sure the terminal board connections agree with the wiring diagram on motor data plate label. Be sure motor is wired for available field supply voltage (see pump operating label). 1. Improper or loose wiring connections; open switches or relays; tripped circuit breakers, or blown fuses. Solution: Check all connections, circuit breakers, and fuses. -
Page 15: Limited Warranty
Obligations: Advantage Manufacturing will, at its option, repair or replace the defective item at its own cost and expense. Advantage Manufacturing is not responsible for any cost of shipping or transportation to or from our service facility. Advantage Manufacturing is also not liable for any loss of time, inconvenience, incidental expenses, labor and/or material charges incurred in connection with the removal or replacement of the equipment, or any other incidental or consequential damages.
