Model:
12200 Stockade Filer
12201 Stockade Filer
12202 Stockade Filer Kit
12203 Stockade Foundry Filer
12204 Stockade Sander
12205 Stockade Saw
12206 Stockade Saw Kit
12207 Stockade Filer/Saw Kit
!
WARNING
12117 Slider Housing
(Incl. 01041, 12167, 12168, 96139.
54519 Planetary Gear (3)
54468 Ring Gear
12222 Planetary
Carrier
54475 Gear Shaft (3)
02650 Bearing
01476 Cylinder
L
3
50767 Pin
01487 Rear Bearing Plate
*01448 Throttle Lever
95558 Retaining
Ring
01488 Housing
Please indicate:
Model #, Serial #,
and RPM
when ordering
replacement parts.
See reverse side for Accessories and Important Operating, Maintenance and Safety Instructions.
Always operate, inspect and maintain this tool in accordance with the Safety Code for portable air tools
(ANSI B186.1) and any other applicable safety codes and regulations. Please refer to Dynabrade's
Warning/Safety Operating Instructions for more complete safety information.
95862 Set Screw
L
2
T
2
95862 Set Screw
L
2
01041 Grease Fitting
G
54552 Bearing
12174 E-Ring
12120 Crank
12170 Retaining Ring
50777 Rotor
01480 Blades (4) (4 pkg.)
95711 Retaining Ring
12132 Pin
01472 Tip Valve
01464 Seal
01468 Spring
Oil
O
01449 Valve Stem
Loctite/Hernon: L
L
95730 O-Ring
Torque: N•m x 8.85 = In. - lbs.
01024 O-Ring
T
T
01469 Regulator
(includes o-rings)
Shade Parts represent 94520 Muffler Assembly
*Optional 01462 Safety lock lever assembly available.
Stockade Filer/Saw
Air Powered Reciprocating Filer/Saw
12167 Bearing
01041 Grease Fitting
12119 Retaining Ring
02694 Bearing
12121 Crank Pivot Plate
01547 Collar
12220 Gear Case
50784 Set Screw
O
01041 Grease Fitting
01543 Air Control Ring
94521 Muffler Base
95438 O-Ring
94524 Sintered Muffler
KEY
Grease
G
= Hernon #940
2
= 17 N•m, T
= 23 N•m
2
3
Parts Page Reorder No. PD97•11
Effective March, 1997
2,800 strokes per minute
96139 Retaining Ring
G
12168 Shaft Seal
95862 Set Screw
12122 Slider Crank
G
01007 Bearing
53151 Pinion
T
4
L
50778 Spacer
3
G
53161 Front Bearing Plate
94525 Felt Muffler
95375 O-Ring
94522 Muffler Cap
T
12166 Guard
2
12125 Square Bearing
T
L
2
2
54552 Bearing
94526 Spacer
94523 Inlet Adapter
T
L
O
2
3
Advertisement
Table of Contents
Related Manuals for Dynabrade 12201
Summary of Contents for Dynabrade 12201
- Page 1 Always operate, inspect and maintain this tool in accordance with the Safety Code for portable air tools WARNING (ANSI B186.1) and any other applicable safety codes and regulations. Please refer to Dynabrade's Warning/Safety Operating Instructions for more complete safety information.
- Page 2 2. Some silencers on air tools may clog with use. Clean and replace as required. 3. All Dynabrade air motors should be lubricated. Dynabrade recommends one drop of air lube per minute for each 10 SCFM (example : if the tool specification state 40 SCFM, set the drip rate of your filter-lubricator at 4 drops per minute).
- Page 3 Important: Manufacturer’s warranty is void if tool is disassembled before warranty expires. Notice: Dynabrade strongly recommends the use of their 52296 Repair Collar (sold separately) during assembly/disassembly activities. Failure to use this collar will highly increase the risk of damage to the valve body of this tool. Please refer to parts breakdown for part identification.
- Page 4 Important: Motor should now be tested for proper operation at 90 PSI. If motor does not operate properly or operates at a higher RPM than marked on the tool, the tool should be serviced to correct the cause before use. Before operating, place 2-3 drops of Dynabrade Air Lube (P/N 95842) directly into air inlet with throttle lever depressed.
