ergoselect 150
Bicycle Ergometer
Operator's Manual
201000134000 • Version 2016-03-15 / Rev 02 • English

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ergoselect 150 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ergoline ergoselect 150

Summary of Contents for ergoline ergoselect 150

  • Page 1 150 Bicycle Ergometer Operator’s Manual 201000134000 • Version 2016-03-15 / Rev 02 • English...
  • Page 2 No part of this manual may be reprinted, translated or reproduced without the manufacturer's written permission. This manual is not subject to any change order service. Please contact the manufacturer for the latest document revision. ergoline GmbH Lindenstraße 5 72475 Bitz Germany Tel.:...

  • Page 3: Table Of Contents

    ONTENTS General Information ....... . 5 Safety Information ....... . 6 Intended Use .
  • Page 4 - 4 -...

  • Page 5: General Information

    • Observance of the safety information protects from • ERGOLINE is responsible for the safety, reliability, and injuries and prevents inappropriate use of the device. performance of the equipment, only if All equipment users and persons responsible for...

  • Page 6: Safety Information

    Explosion hazards may result from the use of fl ammable anes- leakage currents do not present a hazard. thetics, skin cleansing agents or disinfectants. In case of questions, please contact your ERGOLINE dealer or the ergoline GmbH Service Department. For use, the ergometer must always be connected to electric Warning installations that fulfi ll the local requirements.

  • Page 7: Intended Use

    If you have questions in this matter, please contact tion by abruptly bending your arm while the cuff is being ERGOLINE or a representative. infl ated, causing a brief overpressure in the cuff . The cuff must defl ate immediately.

  • Page 8: Symbols

    YMBOLS Symbol ’type B applied part’. Manufacturer’s identifi cation. Type B applied parts have no direct contact with patients and off er the lowest protection against electric shock. Date of manufacture. The number found under this symbol is the year of Symbol ’type BF applied part’.

  • Page 9: Setup And Mains Connection

    ETUP AND AINS ONNECTION ONTROLS AND NDICATORS Control terminal (model P or model K) Blood pressure cuff connection (option) Adjustment of the handlebar angle Blood pressure cuff Adjustment of the handlebar height (ergoselect 200 only) Castors Speed display (RPM) for patient Adjustment of the saddle height (ergoselect 100 only) Digital saddle height indication (ergoselect 200 only)

  • Page 10: Transport

    RANSPORT Caution For short distances, the ergoselect can be lifted at the saddle and rolled away on its castors. • Equipment Damage • To cover greater distances, however, we recommend the Avoid strong vibrations of the ergoselect during transport. following method: •...

  • Page 11: Mounting The Control Terminal (Por K)

    OUNTING THE ONTROL ERMINAL The control terminal can be installed with the display either facing the patient or the operator. It is recommended to install the terminal with the display and control keys towards the operator and the speed display towards the patient. IFFERENT ORIENTATIONS OF THE CONTROL TERMINAL ONNECTING THE OWER...
  • Page 12 The connection panel is located on the underside of the ergometer. • Plug the power cord into socket (a) and use the sup- plied lock (b) to secure it against disconnection. • Using the supplied strain relief, attach the cable to the metal frame.

  • Page 13: Connecting The Ecg Cable

    Diff erent connection cables are available to support diff erent communication modes (digital, analog, remote start, etc.). All ergoline ergometers are equipped with a digital inter- face (special adapters, which can be obtained from ergo- line, are required for control of the ergometer with analog...

  • Page 14: Connecting The Blood Pressure Cuff

    ONNECTING THE LOOD RESSURE • Connect the microphone at (1). • Slip the cuff tubing onto the fi tting (2) and engage. To disconnect, push back the connector's knurled sleeve. Artifacts that may be caused by patient movements during LOOD PRESSURE CUFF CONNECTIONS the exercise test, must be avoided if possible, while the Microphone connection blood pressure is being taken.

  • Page 15: Preparing The Patient

    REPARING THE ATIENT DJUSTING THE ADDLE AND THE ANDLEBAR On the ergoselect 100, you adjust the saddle height manu- ally with a clamping lever. On the ergoselect 200, the saddle height is electrically adjusted with the corresponding keys on the control terminal (the display below the saddle indi- cates the saddle height).

  • Page 16: Preparing The Patient For Blood Pressure Measurements

    REPARING THE ATIENT FOR LOOD RESSURE EASUREMENTS Always choose the cuff size suitable for the patient's arm. The maximum arm circumference is indicated on the cuff . ORRECT CUFF SIZE RONG CUFF SIZE ICROPHONE OSITION Before applying the cuff , check the position of the micro- phone inside the red pocket (on the inside of the cuff ): When the microphone is inside the pocket, its metal side must face the arm.

  • Page 17: Checking The Cuff Tubing

    When you close the Velcro strap, check that the metal clasp (a) is inside the marked index range (b), and not outside. The cuff tab must be located below the metal clasp (see illustration at right). ORRECT CUFF POSITION HECKING THE UBING Check that the cuff tubing does not knock against the patient's knee, when the patient is pedalling and the hand...

  • Page 18: Operation

    Control terminal P Control terminal K ONTROL TERMINAL URNING THE YSTEM ergoline You turn the ergometer on by pressing the power switch - the green indicator in the switch lights up. The ergometer runs a self-test. Subsequently, the main GmbH menu displays.

  • Page 19: Operating Modes With Control Terminalp

    PERATING ODES WITH ONTROL ERMINAL An ergoselect ergometer with a control terminal P supports the following operating modes: PC MODE An external device (e.g. stand-alone electrocardio- graph, PC-based ECG system) controls the ergometer - no intervention at all is required at the ergometer. ERGOMETRY The ergometer runs an automatic exercise test - some of the corresponding test protocols are user-confi gu-...

  • Page 20: Pc Mode

    PC M Use the softkeys on the right and left (↑ ↓) to position the PC Mode bar cursor on PC MODE and confi rm the selection with Ergometry SELECT. Manual Settings   Select AIN MENU The display changes - the ergometer is waiting for com- mands from the external ECG unit.

  • Page 21: Ergometry

    RGOMETRY Use the softkeys on the right and left (↑ ↓) to position the PC Mode bar cursor on ERGOMETRY and confi rm the selection with Ergometry SELECT. Manual Settings Select   AIN MENU Protocols The stored test protocols available for selection will be dis played.
  • Page 22 Note • The saddle height (ergoselect 200) can be changed during an exercise test. • To reactivate the saddle height adjustment function, press and the arrow keys will again be displayed. • Additional blood pressure measurements can be initiated with ERMINATING AN XERCISE The exercise phase can be terminated manually at any time...

  • Page 23: Manual

    ANUAL Use the softkeys on the right and left (↑ ↓) to position the PC Mode bar cursor on MANUAL and confi rm the selection with Ergometry SELECT. Manual Settings In this operating mode the user controls the entire exercise test by selecting the loads, stage times and by initiating blood pressure measurements.

  • Page 24: Settings With Control Terminalp

    ETTINGS WITH ONTROL ERMINAL Some of the device settings are confi gurable to meet spe- PC Mode cifi c requirements. The settings will be saved and remain Ergometry stored even when the ergometer is switched off . Manual Use the softkeys on the right and left (↑ ↓) to position the Settings bar cursor on SETTINGS and confi rm the selection with SELECT.
  • Page 25 Protocol Use the softkeys ↑ ↓ to select the parameter to edit. Select Step At Select, for example, you can choose the protocol type: Basic Load 25 W Stage Time 2 min - Step (load increase in steps) or Load Stage 25 W - Ramp (continuous load increase).
  • Page 26 ANGUAGE Language The texts can be displayed in diff erent languages. Deutsch English Francais Espanol Italiano Select   ANGUAGE MENU Beep The audio signal emitted during blood pressure measure- ments can be turned on and off . Select  ...
  • Page 27 EKG T EKG Type The selected EKG Type determines the communication method with the ECG recorder, PC-based ECG system, etc. To prevent an accidental change of this setting, the menu is protected with a password. Using the arrow keys, enter 003 and confi rm the entry with SELECT.
  • Page 28 Here you determine the RPM limits. When these limits are exceeded, the LEDs for high or low speed (RPM) will Min ↑ 0 ... 70 illuminate. Select the value to change (Min. or Max.) and confi rm with Max ↓ 50 ...

  • Page 29: Control Terminalk

    ONTROL ERMINAL URNING THE YSTEM ergoline You turn the ergometer on by pressing the power switch - the green indicator in the switch lights up. The ergometer runs a self-test. Subsequently, the main GmbH menu displays. Selftest running TEST SCREEN Note •...

  • Page 30: Operating Modes With Control Terminalk

    PERATING ODES WITH ONTROL ERMINAL An ergoselect ergometer with a control terminal K supports the following operating modes: PC MODE TEST An external device (e.g. stand-alone electrocardio- Integrated test protocols (steep ramping test, PWC graph, PC-based ECG system) controls the ergometer - tests) allow an assessment of the physical fi tness.

  • Page 31: Pc Mode

    PC M When the PC Mode key has been pressed, the screen ap pears as shown at right. The ergometer is waiting for commands from the external ECG unit. Saddle ↑ Saddle ↓ With the arrrow keys, the saddle height can be electrically adjusted on the ergoselect 200 (on the ergoselect 400, these key adjust the height of the drive unit).

  • Page 32: Ergometry

    RGOMETRY The ergometer is controlled by an internally stored protocol. Pressing the "Ergometry" key will display the test protocol Ergometry WHO used last. ↑ Saddle Press the "Start" key to re-start the protocol, or press the "Select" key to display the protocol parameters or to switch ↓...
  • Page 33 DJUSTMENTS URING THE XERCISE Press the key to display the confi guration menu. This is what you can do during the test • increase or decrease the current load in increments Load + Recovery phase (adjustable between 1 watt and 25 watts) •...

  • Page 34: Manual

    ANUAL In this operating mode the user controls the entire exercise test by selecting the loads, stage times and by initiating blood pressure measurements. Load + Saddle ↑ The exercise test is started with the "Start" key, afterwards the load can be set and changed with the [Load +] and Load - Saddle ↓...

  • Page 35: Training

    RAINING Cardiologic training sessions can be performed with ergo- select ergometers equipped with control terminal K. For a detailed description of the protocols, please refer to Training No.1 Pulse the Appendix. ↑ Saddle Pressing the "Training" key will display the training protocol used last.

  • Page 36: Training With Chip Card

    The training protocols are saved to the chip card by means of a PC program ("ergoline opticare professional" or "ergo- line opticare basic"). Upon completion of the training session, the entire proce- dure (incl.
  • Page 37 Training Chipcard The name and the weight stored on the card are displayed. Sumner You can use the arrow keys to enter the current weight. David Weight + 93 kg Press the "Next" key and the initial screen will display. You Weight - can initiate the displayed training protocol or select anoth- er protocol from the chip card.

  • Page 38: Settings For Control Terminalsk

    ETTINGS FOR ONTROL ERMINALS Some of the device settings are confi gurable to meet spe- cifi c requirements. The settings will be saved and remain stored even when the ergometer is switched off . Select SETTINGS to display the confi guration menu. Settings When all changes have been made, you can exit the confi - guration menu with the...
  • Page 39 Use the softkeys ↑ ↓ to select the parameter to edit. Protocol Select Step At Select, for example, you can choose the protocol type: Basic Load 25 Watt ↑ Stage Time - Step (load increase in steps) or - Ramp (continuous load increase). Load Stage 25 Watt NIBP Lead Time 60...
  • Page 40 HANGE Load Change Here you determine the increments for each load change. Depending on your choice, each key press will change the load by +/- 1, 5, 10 und 25 watts. 1 Watt ↑ 5 Watt 10 Watt 25 Watt ↓...
  • Page 41 Date/Time To begin with, you select DATE or TIME and confi rm the selection. Then the value displayed in reverse video can be edited Date with the ↑ ↓ keys and saved with SELECT. ↑ 22. 08. 2007 Time The time is set in the same way. You exit the confi guration with 17 : 33: 51 ↓...
  • Page 42 Training For all training modes (pulse, constant load and interval), Select Pulse the warmup phase, the duration of the training session and the recovery phase are defi ned fi rst. Basic Load Watt Depending on the selected training mode, you can edit the ↑...
  • Page 43 EKG T The selected EKG Type determines the communication EKG Type method with the ECG recorder, PC-based ECG system, etc. To prevent an accidental change of this setting, the menu ↑ is protected with a password. Using the arrow keys, enter 003 and confi rm the entry with SELECT.
  • Page 44 Here you determine the RPM limits. When these limits are exceeded, the LEDs for high or low speed (RPM) will illuminate. Min ↑ 0 ... 70 ↑ Select the value to change (Min. or Max.) and confi rm with SELECT. Max ↓...

  • Page 45: Cleaning, Maintenance, Disposal

    LEANING AINTENANCE ISPOSAL Warning ENERAL LEANING • Shock Hazard • Wipe the device surface down with a cloth moistened with soap water or a disinfectant. • Disconnect the device from the power line before cleaning. The cloth should not be dripping wet; do not allow liquids to enter the device.
  • Page 46 LEANING THE LOOD RESSURE EMOVING THE ICROPHONE Pull the end of the cuff through the metal clasp and fold out the cuff . Pull on the short Velcro tab to open the microphone pock- et and carefully remove the microphone. LEANING Clean the cuff and tubing with a moist cloth.
  • Page 47 Manual as unsorted municipal waste. It must be collected separately. Please contact the authorized manufacturer ergoline GmbH to obtain information concerning the decommissioning of your equipment. There is no proper waste management, proper disposal is documented by ergoline GmbH. Consult operating instructions. - 47 -...

  • Page 48: Technical Specifications

    ECHNICAL PECIFICATIONS RGOMETER Model modular ergometer system ergoselect models ergoselect 100 P / K, ergoselect 200 P / K Operating Mode continuous operation Power 100 - 240 V / 50 - 60 Hz (100 VA max.) specifi cation power cord US: SPT 2x18AWG 125 V / 10 A "hospital"...
  • Page 49 Displays LCD: 68 x 34 mm, 128 x 64 pixels (Control Terminal P) 115 x 88 mm, 320 x 240 pixels (Control Terminal K) additional LED display for speed (RPM) Interfaces PORT 1 (DSUB-9-pole): digital remote control RS232 by PC or ECG recorder, remote start of ECG recorder (optional) USB: digital remote control by PC (driver required)
  • Page 50 Infl ation Pressure 300 mmHg max.; during infl ation the infl ation pressure automatically adapts to patient's BP Infl ation Rate between approx. 6 seconds (to 140 mmHg) and approx. 18 seconds (to 300 mmHg) Max. Cuff Pressure 300 mmHg Cuff Defl ation Method pulse-dependent defl ation rate approx.
  • Page 51 AMILY OF CHARACTERISTICS OF THE BRAKING TORQUE CONTROL RANGE black: speed-independent range to DIN VDE 0750-0238 black + grey: speed-independent range of the ergoselect ergometer IEC 60601-1 AMILY OF CHARACTERISTICS OF THE LOAD PERIODS ACCORDING TO Under permanent load, the load periods and pauses (white) shall be observed. - 51 -...

  • Page 52: Electromagnetic Compatibility En 60601-1-2

    LECTROMAGNETIC OMPATIBILITY EN 60601-1-2 Warning Changes or modifi cations to this system not expressly approved by ergoline could cause EMC issues with this or • RF INTERFERENCE • other equipment. • Use of portable telephones or other radio frequency (RF)
  • Page 53 ’ – E UIDANCE AND ANUFACTURER ECLARATION LECTROMAGNETIC MMUNITY The ergoselect ergometer is intended for use in the electromagnetic environment specifi ed below. It is the responsibility of the customer or user to ensure that the ergoselect ergometer is used in such an environment. ImmunityTest IEC 60601 Test Level Compliance Level...
  • Page 54 ’ – E UIDANCE AND ANUFACTURER ECLARATION LECTROMAGNETIC MMUNITY The ergoselect ergometer is intended for use in the electromagnetic environment specifi ed below. It is the responsibility of the customer or user to ensure that the ergoselect ergometer is used in such an environment. ImmunityTest IEC 60601 Test Level Compliance Level...
  • Page 55 ECOMMENDED SEPARATION DISTANCES BETWEEN PORTABLE AND MOBILE COMMUNICATIONS EQUIPMENT AND THE ERGOSELECT ERGOMETER The ergoselect ergometer is intended for use in the electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the ergoselect ergometer can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the ergoselect ergometer as recommended below, according to the maximum output power of the communications equipment.
  • Page 56 - 56 -...
  • Page 58 GmbH Lindenstraße 5 72475 Bitz Germany Tel.: +49-(0) 7431 98 94 - 0 Fax: +49-(0) 7431 98 94 - 128 e-mail: info@ergoline.com http: www.ergoline.com...
