Summary of Contents for ROLEC LGAB0020
- Page 1 COMBI LIGHT INSTALLATION & OPERATION MANUAL MODELS: LGAB0020 6-WAY LGAB0040 10-WAY Marina Services Installation & Operation Manual - MCLM-001 Ver:1.00 Rev:0 July 2020...
- Page 2 Date Published: June 2021 Rolec Services Ltd are the publishers of this document and own the rights to use the text, images and all technical content contained within. Content supplied by third parties / partner organisations remains the property of that organisation and is used by agreement with the supplier.
- Page 3 Contents Contents Contents Safety Safety Advice within this Manual Product Overview Product Specification Physical Specification Package Contents Electrical Specification Certifications and Compliances Labelling Product Label Electrical Warning Label Deck Light Labels Internal Labels Installation Before Installation Install the Unit Maintenance MCLM-001 Installation and Operation Manual Combi Light Ver:1.00 Rev:1 June 2021...
- Page 4 Electrical Wiring Regulations of the geographical location of the installation. If the advice in this manual is not understood, contact Rolec for further advice and/or training BEFORE attempting installation/operation of the equipment.
-
Page 5: Product Overview
Product Overview Safety Advice within this Manual Rolec manuals use a system of warnings, cautions and notes. WARNINGS concern the safety of installers/end user and will be given before the detail/instructions in the manual. CAUTIONS concern the potential for damage to the equipment and will be given before the detail/instructions in the manual. -
Page 6: Product Specification
Figure 3 Combi Light steam cleaning Single Unit Dimensions Package Contents 1 x Rolec Combi Light Junction Box Combi Light LED Luminaires (6 or 10 way) and attached 10 m cable Fasteners to secure each LED luminaire (optional purchase) Installation and Operation Manual. -
Page 7: Electrical Specification
Product Specification Electrical Specification LED Type Low Voltage LED Two Directional LED Rating 2.5 W LED Light Temperature ACLG0290A - White & White (approx. 3000K – warm white) ACLG0290 - White & White (approx. 5700K – white) ACLG0270 - Blue & White (approx. 5700K – white) ACLG0280 - Green &... -
Page 8: Product Label
Labelling Labelling Users must observe the information given on labels to ensure safe use of the product. Labels may be in the form of adhesive ‘stickers’, plates, and/or moulded into the surface of components. Product Label The Product Label is mounted on the central ‘Junction Box, that connects the individual LED cable assemblies to the power supply cable and switch cables. -
Page 9: Before Installation
The instructions below are illustrative only and do NOT override anything written in the current regulations. If the advice in this manual is not understood, contact Rolec for further advice and/or training BEFORE attempting installation/operation of the equipment. Rolec Services Ltd cannot accept any responsibility for improper installation or any problems arising from improper installation. - Page 10 Installation 3. Position the Junction box and secure it with suitable fasteners. Remove the Junction Box cover. The cover is secured by captive fasteners that release the cover in 2 stages. Release each fastener to allow the cover to lift a short distance away from the main box.
-
Page 11: Maintenance
Maintenance Maintenance CAUTION: Equipment Damage Do NOT: Use Abrasive materials, Mineral or petroleum solvents / degreasers, Jet washers or Steam cleaners. Attempt to repair LED light assemblies. The LED luminaire and cable must be replaced as one unit. 1. The external surface of each deck light should be cleaned with a damp cloth every 3 months. - Page 12 Marina Services THE WORLD’S LEADING MARINA SERVICES SPECIALIST Head office contact: @ @ RolecMarina t: +44 (0) 1205 724754 www.rolecserv.com f: +44 (0) 1205 724876 rolec@rolecserv.co.uk...
