- Page 1 Discover Adapt 30 Wireless Headset User Guide...
-
Page 2: Important Safety Instructions
Important Safety Instructions: This headset is very easy to use and setup. For optimal use, we still recommend that you read this user guide carefully before using the headset for the first time. Unpacking Remove your headset from its packaging and ensure you have the correct specified accessories. Retain the headset box for storage of your unit, and also in the event that it needs to be returned for servicing or repair. -
Page 3: What's Included
What’s included Base Unit Microphone Monaural Binaural Boom Arm Headband Headband USB Cartridge Module USA Adapter & RJ11 to RJ11 Telephone Cord IMPORTANT AUTO SET UP NOTICE This headset will auto configure to your desk phone. The compatibility switch should be used in the alternative position, if no dial tone is heard in the headset when active. - Page 4 Features: • Patented, user changeable headband from single speaker to dual speaker wearing style • Patented, universal base with slot-in cartridge drawer to accept USB or Bluetooth* modules (*Optional accessory - sold separately) • DECT security compliant - with security requirements of the DECT standard A, designed to safeguard against eavesdropping •...
-
Page 5: Positioning The Microphone
Attaching the microphone boom arm to the headband To attach the microphone boom arm to the headband, align the triangle shape on the microphone boom arm with the triangle shape on the headband and push to click into place. The microphone boom arm will then rotate to your required position. - Page 6 Connecting the Base Unit to your Desk Phone Base Unit Handset Port Telephone Port Compatibility DC Jack AUX Port Switch Desk Phone with Headset Port • Plug the supplied telephone cord into the TEL port of the base unit • Connect the other end of the telephone cord to the HEADSET port of the desk phone Desk Phone without Headset Port •...
- Page 7 Operating Instructions Please note: Your Adapt 30 is supplied paired to the base unit straight out of the box. However, if after charging the headset, the ‘GREEN’ TEL light doesn’t activate when the headset is removed from the base unit, then you should follow these instructions.
- Page 8 Base Unit Microphone Volume Microphone Mute Button Bluetooth PC/TEL Compatibility Pairing Selection Switch Button Bluetooth Button This function works when the Bluetooth module is inserted PC/TEL Selection This function works when the USB cartridge is inserted Microphone Mute Button Press to mute the call Microphone Volume Your headset has automatic audio configuration, (this can take a few minutes to settle) however, if required, you can adjust the...
-
Page 9: Visual Indicator
Base Unit Telephone Indicator Microphone Mute Indicator (Green Light) (Red Light) Battery Charge Indicator PC/Bluetooth Indicator (Blue Light) (White Light) Bluetooth Microphone Button Mute Button PC/TEL Selection Visual Indicator Charging Status LED Status Charging Battery Indicator: ‘Flashing’ 1 sec-ON, 1 sec-OFF Fully Charged Battery Indicator: ‘ON’... - Page 10 Adapt 30 Cartridge Module for USB Connection • Softphone interoperability through USB/computer with 3CX, Avaya One-X, Cisco Jabber, Counter Path and Skype with assistance from the JPL Gateway. • JPL Gateway software must be installed and running for remote call control functions to work with supported softphones.
- Page 11 Auto-Talk Option Auto-talk means that the call will be active once answered as soon as you take the headset off of the base station, this is default active. You can disable this, so that to make the call active, you have to press the call accept button on the headset when you are ready to take the call.
- Page 12 How to Activate a Conference Call between two headsets: While Headset A is on a call, press the <Mute> button on the base station (fig. 1) for more than 2 seconds. The base station is now in the ‘Conference Call Initiating Mode’ and all LEDs, except the Battery Charging LED, will be flashing.
- Page 13 Detaching the microphone boom arm from the headband How to detach the microphone boom arm from the headband correctly: Supporting the neck of the headband with your index and middle fingers, gently push the microphone speaker with your thumb from inside the ear cushion to detach the microphone boom arm from the headband.
-
Page 14: Troubleshooting
Trouble Shooting 1. Cannot hear a dial tone. • Check the PC/TEL button. TEL Mute: PC/TEL indicator – ‘OFF’ • Please check the cable connection between base unit and phone. • Check that the power adapter is plugged in and has power •... -
Page 15: Additional Accessories
Additional Accessories Adapt 30 Cartridge Module for Bluetooth Connection • Bluetooth allows the DECT headset to connect wirelessly to Bluetooth enabled smartphones. • This headset allows wireless conversations from any desk phone, softphone and mobile. • Before inserting your Bluetooth cartridge, make sure that the base unit is powered-off. - Page 16 www.discoverheadsets.com...
