TemperZone MT Series Installation & Maintenance

CONTENTS
1. GENERAL ..............................................................................1
2. SAFETY INSTRUCTIONS .....................................................1
3. PACKING & TRANSPORT .....................................................2
4. POSTIONING & MOUNTING .................................................3
5. ASSEMBLY & INSTALLATION ...............................................3
6. WIRING ..................................................................................3
7. START-UP & OPERATION .....................................................4
8. COMMISSIONING .................................................................4
9. MAINTENANCE .....................................................................4
10. TROUBLESHOOTING .........................................................5
11. WARRANTY .........................................................................5
COMMISSIONG SHEET ............................................................6
MT Series (Clever)
Chilled / Hot Water Air Handling Units
Installation & Maintenance

1. GENERAL

Page
Follow these instructions to ensure the optimum performance,
reliability and durability.
Units must be installed in accordance with all national and
regional regulations and bylaws. National Health and Safety
regulations must be followed to avoid personal injuries.
The appropriate local permits must be acquired and
adhered to.
This appliance is not intended for use by persons (including children)
with reduced physical, sensory, or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for
their safety. Children should be supervised to ensure that they do not
play with the appliance.

2. SAFETY INSTRUCTIONS

All paragraphs preceded by this symbol
as they underline dangerous situations or important information.
2.1 General
CLEVER Air handling units are to be installed, operated and
maintained only by qualified technical personnel. The units
are suitably designed for air conditioning, heating, cooling
and ventilation.
2.2 Fan Coil Section
!
DANGER. ROTATING MACHINERY.
It is strictly forbidden to enter into the fan area while the
fan is operating. When necessary, the operator should
be equipped with proper safety equipment and clothes in
compliance with local regulations. Once turned off, the fan
will take time to come to a complete stop.
2.3 Heating Coil
Pay attention to the heating coil high temperature. The
maintenance personnel should treat the surface as hot and
be equipped with gloves and clothes to prevent accidents.
2.4 Electrical Connections
Turn all isolators off before touching any electrical
connections. The electric cables and cables sockets should
be in compliance with local wiring regulations.
2.5 Filter Plenum Section
Turn the power supply OFF, before entering into this area.
The filter section should be treated as highly flammable
due to fine dust build-up present. As such it is forbidden to
smoke or to light flames inside the filters area. Dirty filters
can easily ignite.
2.6 Moving Parts
Pay attention when the dampers are operating.
DO NOT place your hands on moving components such as
blades or fan wheels.
- 1 -
!
require great attention
003-000-293 05/23
