Advanced Airport Lighting System

LED Elevated Uni-directional Lighting Fixtures

Elevated Approach Centerline Light and Cross Bar Light, Elevated Approach Side-row Light,

Elevated Runway Threshold Light, Elevated Runway Threshold Wing Bar Light, Elevated

Runway End Light and Elevated Stop Bar

EUL-AP-LED, EUL-SR-LED, EUL-TH-LED,

EUL-THW-LED, EUL-ED-LED and EUL-SB-LED

Operation Manual

Please read this manual carefully before construction, installation and operation of the product.

Please keep this manual properly for further reference.

This manual is subject to change without prior notice.

Airsafe Airport Equipment Co., Ltd.

Table of Contents

Need help?

Do you have a question about the EUL-AP-LED and is the answer not in the manual?

Questions and answers

Summary of Contents for Airsafe EUL-AP-LED

Page 1 EUL-THW-LED, EUL-ED-LED and EUL-SB-LED Operation Manual Please read this manual carefully before construction, installation and operation of the product. Please keep this manual properly for further reference. This manual is subject to change without prior notice. Airsafe Airport Equipment Co., Ltd.
Page 2 Advanced Airport Lighting System Revision Description Version Revised Approved Description Date First release V1.0 C.SY Aug. 12, 2016...
Page 3: Table Of Contents
Advanced Airport Lighting System Table of Content 1.0 Foreword ........................... - 1 - 1.1 Illustrations and Meanings ................... - 2 -- 1 - 1.2 Safety Rules and Notices ..................... - 3 -- 2 - 1.3 Quality Assurance and Responsibility ................. - 4 -- 3 - 2.0 Introduction to Lighting fixtures ..................
Page 4: Foreword
Advanced Airport Lighting System 1.0 Foreword ICAO Airport Service Manual Part 9 “Airport Maintenance Practices” and FAA AC150/5345-26 Maintenance of Airport Visual Aid Facilities are the highest criterions for site installation and maintenance of such lighting fixtures. This manual was compiled with considerable reference to these two criterions.
Page 5: Illustrations And Meanings
Advanced Airport Lighting System 1.1 Illustrations and Meanings Formatted: Font: 15 pt, Complex Script Font: 15 pt ○ Following illustrations will appear in this manual where necessary to remind or warn construction or maintenance personnel. ○ Please continue reading the subsequent content of this manual after properly understanding the meanings of these illustrations.
Page 6: Safety Rules And Notices
Advanced Airport Lighting System 1.2 Safety Rules and Notices ◼ Using the light fixtures outside of airport is strictly prohibited. ※ Inadequate maintenance or casual touch will cause light faults. ◼ Using power supply other than CCR is strictly prohibited. ※...
Page 7: Quality Assurance And Responsibility
Advanced Airport Lighting System 1.3 Quality Assurance and Responsibility Any defect in design, material or workmanship, which may occur during proper and normal use over a period of one year from date of installation but less than 15 months from date of shipment, or within the warranty period of the tender, will be repaired or preplaced by manufacturer free of charge.
Page 8: Introduction To Lighting Fixtures
Elevated Threshold Wing Bar Light EUL-ED-LED---------------------------------- Elevated Runway End Light EUL-SB-LED----------------------------------- Elevated Stop bar Type of LED Approach Centerline Light and Cross Bar Light (EUL-AP-LED): Type EUL-AP= Elevated approach centerline light and cross bar light Light source LED= LED lamp...
Page 9 Advanced Airport Lighting System Type EUL-SR= Elevated approach side-row light Light source LED= LED lamp Beam color R= Red Optional function M= single lamp fault detection function Formatted: Centered, Line spacing: single Type of LED Elevated Runway Threshold Light (EUL-TH-LED): Type EUL-TH= Elevated Runway Threshold light Light source...
Page 10 Advanced Airport Lighting System Type EUL-THW= Elevated runway threshold wing bar light Light source LED= LED lamp Beam color G= Green Optional function M= single lamp fault detection function Type of LED Elevated Runway End light (EUL-ED-LED): Type EUL-ED= Elevated runway end light Light source LED= LED lamp Beam color...
Page 11 Advanced Airport Lighting System Type EUL-SB= Elevated stop bar Light source LED= LED lamp Beam color R= Red Optional function M= single lamp fault detection function - 8 -...
Page 12: Technical Specifications
Advanced Airport Lighting System 2.1 Technical Specifications This product conforms to the provisions of the following standards or technical specifications. For dated standards or technical specifications, only the edition cited applies. For undated references, the latest edition of the referenced document (including any amendments) applies.
Page 13: Application Scope
2.4 Technical Parameters Rated Life of Light Description Type Power Fact Source ≥ Elevated Approach Centerline Light ≥50,000h EUL-AP-LED-C-X 36VA and Cross Bar Light ≥ ≥50,000h Elevated Approach Side-row Light EUL-SR-LED-R-X 28VA ≥ ≥50,000h EUL-TH-LED-G-X 36VA Elevated Runway Threshold Light ≥...
Page 14: Technical Features
Advanced Airport Lighting System 2.5 Technical Features Formatted: Line spacing: Exactly 22 pt ⚫ Long life, energy saving, maintenance free and other characteristics of LED will bring huge economic benefits to customers; ⚫ With the proprietary optical design, the lighting fixtures still have the all-optical output when the front glass is covered in part;...
Page 15: Structure
Advanced Airport Lighting System 2.6 Structure 1 – Cover bracket 10 – Front adjusting screw 2 – Optical cover 11 – Check ring 12 – Hinged shaft 3– Optical cover gasket 4 – LED lamp 13 – Rear adjusting screw 5 –...
Page 16: Fault Detection Or Lamp Bypass Functions
Advanced Airport Lighting System 2.7 Fault Detection or Lamp Bypass Functions This product complies with the requirements of FAA EB67 and GB/T 7256, and integrates single lamp fault detection function; Or, it can provide the option of lamp bypass function in accordance with the requirements of FAA AC150-5345/46.
Page 17: Installation
Advanced Airport Lighting System 3.0 Installation Requirements for installation should be learned thoroughly before installation including installation tools and site requirement, etc., to avoid malfunction of the light due to incorrect installation. 3.1 Installation Methods Method 1: Mast installation; Method 2: Ground installation of extension pole; Method 3: L-867 deep bucket flange installation;...
Page 18: Installation Tools
Advanced Airport Lighting System 3.2 Installation Tools Choosing right tools not only can ensure the correct and reliable installation of the lighting fixtures, but also can reduce unnecessary safety accidents. Special Tools listed in the table may be purchased from the manufacturer or any distributor. Universal tools are available on local hardware market.
Page 19: Installation Of Lighting Fixtures
Advanced Airport Lighting System 3.4 Installation of Lighting Fixtures ○ This Operation Manual does not define the installation of the flange. For the technical support, please contact the construction party and the dimension of the chassis installed, please see Figure below: Formatted: Indent: First line: 5 ch Formatted: Indent: First line: 5 ch ○...
Page 20 Advanced Airport Lighting System Installation method 1: Mast installation ⚫ When unpacking the package, check whether the parts are complete. Carefully handle the lighting fixtures to void damaging the assy. ⚫ Connect the A6 plug of the lighting fixtures with the secondary receptacle of the isolation transformer and cover the lighting fixture onto the support reserved by the mast.
Page 21 Advanced Airport Lighting System ◼ The non-standard tools shall not be used for assembling and dismounting the lighting fixtures. ※ It may cause personal injury or damage to the lighting fixtures. Formatted: Line spacing: At least 12 pt ◼ During wiring, the lead shall not be pressed by the lighting fixture flange. ※...
Page 22 Advanced Airport Lighting System 3.5.2 Corrector operating parts as shown in Figure Digital inclinometer Calibration base Positioning groove Positioning surface Horizontal calibration groove 3.5.3 Corrector installation As shown in Figure, put the corrector on the light body; the positioning groove and surface are bound with the connecting piece on the lighting fixtures and the rear of the corrector is close to the rear cover.
Page 23 Advanced Airport Lighting System adjustment of the horizontal beam angle. 3.5.5 Adjustment of vertical beam angle: Put the digital inclinometer on the calibration bracket, slightly unscrew the front, rear and side adjusting screws of the lighting fixtures, through adjusting the front and rear adjusting screws, make the lighting fixtures rotate along with the hinged shaft of the light body, observe the value (i.e.
Page 24: Replacement Of Components Of Lighting Fixtures
Advanced Airport Lighting System 4.0 Replacement of Components of Lighting Fixtures When any damage or failure occurs to any consumable or other component of the lighting fixtures, it is required to timely dismantle the lighting fixtures for replacement of the component. Replacement of components needs to dismount the lighting fixtures, so any minor error will cause adverse consequences.
Page 25: How To Replace Optical Cover
Advanced Airport Lighting System 4.1 How to Replace Optical Cover 1. Place the lighting fixture cover upwards (Figure 4-1). 2. Unscrew 4 fixing screws, remove the cover bracket, take out the optical cover out of the cover bracket adhesive tape; replace a new optical cover and ensure that it is closely attached to the adhesive tape (Figure 4-2).
Page 26: Operation And Control
Advanced Airport Lighting System 5.0 Operation and Control The lighting fixtures are applicable to CCR power supply 6.6A circuit special for airports, which forms a secondary circuit with the lighting fixtures through secondary outgoing line of isolation transformer connected on primary circuit. Due to the use of isolation transformer, the damage of lamp of single lighting fixture will not affect whole series circuit.
Page 27: Maintenance Of Lighting Fixtures
Advanced Airport Lighting System 6.0 Maintenance of Lighting Fixtures Suggestions for daily maintenance provided in this section are only for reference. Airports Formatted: Indent: First line: 2 ch may formulate their own daily maintenance guidelines with reference to other provisions or maintenance experience of airport staff;...
Page 28: Regular Spot Check And Troubleshooting
Advanced Airport Lighting System reached. 6.2 Regular Spot Check and Troubleshooting Serial Failure Phenomenon Possible Reasons Countermeasures No light output or flashing Failure of LED lamp Replace the LED light source assy or driver assy or driver or return the lighting fixtures manufacturer for maintenance.
Page 29 Advanced Airport Lighting System ◼ Torque wrench other than powerful wrench must be used. ※ Otherwise it may damage the screw and thread to result in accidents. - 26 -...
Page 30 Advanced Airport Lighting System 7.0 List of Components and Ordering of Spare Articles and Formatted: Font: (Default) Times New Roman Formatted: Heading 1, None, Space Before: 6 pt Accessories Formatted: Font: Not Bold The table in this chapter lists the components and relevant ordering information of the spare articles and accessories of this product.
Page 31 Advanced Airport Lighting System List of supporting accessories of this product is as follows (needing additional order): Serial No. Order No. Description 924241 2 inches frangible part 276A1 Flange 240mm Ø60 extension pole It may be customized according to the requirements. 924252 2 inches sleeve frangible assy 27683...
Page 32: Packaging, Transportation And Storage
Advanced Airport Lighting System 8.0 Packaging, Transportation and Storage 8.1 Packaging and Weight Packaging: 1 pcs / box Gross weight: 4 KG / box Volume: 220*220*265 8.2 Transportation Mode Well packed products may be transported in three modes- railway, highway and air according to factors such as transportation distance, quantity of lights and delivery cycle.
Page 33 Advanced Airport Lighting System The final right to interpret this manual is reserved by Airsafe Airport Equipment Co., Ltd. Thanks for your purchasing and using AIRSAFE product! Address: No. 38, Anxin Road, Xuhang Town, Jiading District, Shanghai, China Postal Code: 201800 Tel.: 021-53540453...
