Page 1: Table Of Contents
Changing Entertainment. Again. Find Inside: Introduction • Connections • Remote • Features • Menu • Troubleshooting • HDTV User’s Guide page 2 page 7 page 21 page 29 page 41 page 54 rca.com rca.com... -
Page 2: Important Information
Product Registration Please fill out the product registration card (packed separately) and return it immediately. For US customers: Your RCA Consumer Electronics product may also be registered at www.rca.com/productregistration. Registering this product allows us to contact you if needed. Product Information Keep your sales receipt to obtain warranty parts and service and for proof of purchase. -
Page 3: Important Safety Instructions
See the figure on the right for details. To assure adequate ventilation for this product, maintain a spacing of 4 inches from the top and sides of the TV receiver and 2 inches from the rear of the TV receiver and other surfaces. -
Page 4: Introduction
The resolution is measured by calculating the number of active lines of pixels. A pixel (which stands for picture element) is a small dot. The picture you see on your TV is composed of these dots. -
Page 5: Aspect Ratio
2 million pixels (1,920 x 1,080 = 2,073,600). More pixels equal more detail. In summary, HDTV is capable of resolution that is up to 10 times the resolution of the picture on a regular, analog TV! Aspect Ratio Aspect ratio is simply the width and height of the picture. -
Page 6: Other Key Features Of Owning An Rca Hdtv
Introduction Other Key Features of owning an RCA HDTV There are other HDTVs on the market. But your RCA HDTV has been designed with features that will enhance your TV viewing experience, and features that provide flexibility to build on the digital revolution that is taking place. A summary of your TV’s most unique features follows. - Page 7 Introduction... 2 The best of both worlds ... 2 What makes HDTV better ... 2 Other Key Features of owning an RCA HDTV... 4 Chapter 1: Connections & Setup ... 7 Things to Consider Before You Connect ... 8 Choose Your Connection ... 9 Explanation of Jacks ...
- Page 8 Blocking Movie Ratings ... 39 Blocking Unrated/Exempt Programs Lock/Unlock Parental Controls ... 40 Front Panel Block... 40 Chapter 4: Using the TV's Menu System ... 41 Sound Menu ... 42 Picture Menu ... 44 Channel Guide Menu ... 46 Time Menu... 47 Parental Control Menu ...
-
Page 9: Chapter 1: Connections & Setup
• Choose Your Connection • Explanation of Jacks • Connection Instructions • Front Panel Buttons and Jacks • Plug in the TV • Put Batteries in the Remote • How to Use the Remote Control to Complete the Initial Setup •... -
Page 10: Things To Consider Before You Connect
Important Stand and Base Safety Information Choose the location for your TV carefully. Place the TV on a stand or base that is of adequate size and strength to prevent the TV from being accidentally tipped over, pushed off, or pulled off. This could cause personal injury and/or damage the TV. -
Page 11: Connections
Needed Needed Needed Needed Needed Title Title Title Title Title Title Title Coaxial TV + DVD + VCR Audio/video Component video Coaxial TV + Satellite Audio/video Receiver + VCR S-Video TV + DVI Audio component TV + A/V Audio receiver Go to... -
Page 12: Explanation Of Jacks
Connections & Setup Explanation of Jacks This section describes the jacks you can use for connections. There are several ways to connect components to your TV. Back Panel Jacks (in alphabetical order) ANTENNA/CABLE ANALOG INPUT Lets you connect a coaxial cable to receive the signal ANTENNA/ from the antenna, cable, cable box, or a VCR. - Page 13 COMPONENT INPUTS Lets you connect a component video source, such as a DVD COMPONENT player. INPUT CMP1 • • • • COMPOSITE INPUTS Lets you connect another component such as a VCR or DVD player. COMPOSITE INPUTS Its AUDIO jacks are the same as described for CMP1 above. S-VIDEO MONO VID1...
- Page 14 Connections & Setup ANTENNA IN CABLE DVD PLAYER AUDIO OUT COMPONENT INPUTS CMP1 CMP2 DVI-HDTV VIDEO AUDIO AUDIO VIDEO ANTENNA OUT OFF-AIR ANTENN S-VIDEO OFF-AIR ANTENNA OFF-AIR ANTENNA ANTENNA DIGITAL INPUT ANTENNA/ CABLE ANALOG COMPOSITE INPUTS INPUT AUDIO/VIDEO OUTPUT S-VIDEO VID1 FIXED AUDIO MONO...
-
Page 15: Tv + Dvd + Vcr
1. Connect your DVD Player to your TV. A. Connect the audio (white and red) cables to the CMP1 L and R audio input jacks on the back of the TV and to the audio output jacks on the DVD player. - Page 16 Connections & Setup ANTENNA IN CABLE SATELLITE RECEIVER VIDEO AUDIO S-VIDEO COMPONENT INPUTS CMP1 CMP2 DVI-HDTV VIDEO AUDIO AUDIO VIDEO ANTENNA OUT OFF-AIR ANTENN ANTENNA DIGITAL INPUT ANTENNA/ CABLE ANALOG COMPOSITE INPUTS INPUT AUDIO/VIDEO OUTPUT S-VIDEO FIXED AUDIO MONO VID1 VARIABLE VID2 AUDIO...
-
Page 17: Tv + Satellite Receiver + Vcr
B. Connect the audio (white and red) cables to the VID2 L/MONO and R audio jacks on the back of the TV and to the Audio Output jacks on the VCR. C. Connect the video cable to the VID2 V (Video) jack on the back of the TV and to the video output jack on the VCR. -
Page 18: Tv + Dvi Component
TV+ A/V Receiver A/V RECEIVER TAPE These are two different ways your TV uses a component to hear audio. Connect audio cables to either the FIXED or VARIABLE AUDIO L and R OUTPUT jacks and to the audio inputs on... -
Page 19: The Front Of Your Tv
Chapter 3. Front Panel Buttons If you cannot locate your remote, you can use the front panel buttons of your TV to operate many of the TV’s features. MENU/OK Brings up the Main menu. In the menu system, it selects highlighted items. -
Page 20: Plug In The Tv
CLEAR Plug in the TV Plug the flat end of the cable into the power jack on the back of the TV. Then plug the other end of the power cord into an appropriate wall outlet. Be sure to insert the plug completely. -
Page 21: Complete The Initial Setup
OK. Welcome Screen and Connection Confirmation The next screen welcomes you to your new RCA TV. Press OK to continue with the setup. After the welcome screen, the initial setup asks you to make sure that you've connected the HDTV to your cable or antenna signal. Once you've confirmed that the HDTV is connected, press OK. -
Page 22: Changing Lists And Labels
Blue center convergence of the screen. If it is not, use the arrow buttons to move the blue cross to overlap the green cross. Press OK (the TV tunes to the last selected/ available channel in the channel list). In channel list option. Press the left In channel list Channel label option. -
Page 23: Chapter 2: Using The Remote Control
Using the Remote Control Chapter Overview: • The Buttons on the Remote Control • Programming the Remote to Operate Other Components • How To Use the Remote After You’ve Programmed It • Volume Punchthrough Feature • Using the INPUT Button •... -
Page 24: The Buttons On The Remote Control
VCR, DVD, or audio receiver) that you’ve programmed to work with this button. AUX by default is set up for an RCA HDTV Tuner receiver. This button lights when you press a valid button in AUX•HD mode (see Modes of Operation on page 26 for more details). -
Page 25: Using The Remote Control
SAT•CABLE mode (see Modes of Operation on page 26 for more details). SKIP In TV mode, activates the commercial skip timer. This button also activates the search function on some RCA, GE, or ProScan VCRs (when the remote is in VCR mode). -
Page 26: Programming The Remote To Operate Other Components
The AUX•HD button can be programmed to operate most brands of an additional remote-controllable component: satellite receiver, cable box, DVD, VCR, and an audio component. A second and third RCA TV can be programmed to any component button, except the TV button. -
Page 27: How To Use The Remote After You've Programmed It
Once the remote has been programmed successfully, you are ready to use it to operate your components. To Operate the Component: 1. Press the appropriate component button (DVD, TV, VCR, SAT•CABLE, AUDIO, AUX•HD) to set the remote to control the component. 2. Press ON•OFF to turn the component ON or OFF. -
Page 28: Modes Of Operation
(DVD player, VCR, cable box, etc.) it uses operational modes triggered by the component buttons. For example, if you want the remote control to operate the TV, press the TV button to put the remote into TV mode. If you want the remote to operate the VCR, press the VCR button. -
Page 29: Deleting All Volume Punchthrough Commands
VCR. To play, stop, or rewind the VCR tape using the remote that came with your TV, you must first press the VCR or AUX•HD button (whichever one is programmed to the VCR) to put the remote control in VCR mode. -
Page 30: Pvr Codes
Hitachi... 5066, 5067 Hughes... 5062, 5071 JVC ... 5065 3047 Panasonic... 5060 Philips ... 5068 Primestar ... 5061 Proscan ... 5000, 5001, 5072 RCA ... 5000, 5001, 5072 Realistic ... 5053 Sony ... Sony ... Sony STS1... 5054 STS3... 5055 STS4... 5056 Toshiba... -
Page 31: Chapter 3: Using The Tv's Features
Using the TV's Features Chapter Overview: • Channel Banner • Digital and Analog Tuners • Autotuning • Parental Controls and V-Chip Changing Entertainment. Again. Changing Entertainment. Again. Graphics contained within this publication are for representation only. -
Page 32: Channel Banner
Using the TV’s Features Channel Banner There are several indicators that might appear when you press the TV or INFO button on the remote. What you see depends on the tuner you're watching (digital or analog) and the information available for the current program. This display is called the Channel Banner. The list at the bottom of this page describes the items on the Channel Banner screen (left to right and top to bottom). -
Page 33: Digital And Analog Tuners
4. Enter the number of the subchannel. This number appears to the right of the primary channel number. 5. Press OK to tune to the channel or wait a few seconds and the TV tunes to the channel. Note: Once you've run the auto channel search on a tuner, you can just use the channel up and down buttons on the remote control to change channels when the remote's in TV mode. -
Page 34: Autotuning
TV (like a VCR, DVD player, etc.) When you set up autotuning in the menu system you don’t have to remember to change your TV to the CMP1 input, for example, when you want to watch a DVD on your DVD player. - Page 35 Channel 3/4 switch is set to channel 3. VID1 or VID2 (Video Input) Component is connected to a VIDEO or S-Video jack on the back of the TV and you want the TV to tune to a VID input channel when you press the corresponding component button.
-
Page 36: Parental Controls And V-Chip
Once you block programs, you can unblock programs by entering a password. By default, the software inside your TV is turned “off.” For instructions to turn on V-Chip, go to page 40. -
Page 37: The V-Chip Rating Screen
TV-Y children from ages 2-6. It is not expected to frighten younger children. Chapter 3 Using the TV’s Features Rating Status Field Lets you select whether the status of the age-based rating limit to the left is View or Block. -
Page 38: Blocking/Viewing Age-Based Ratings
Adult language Sexual situations Violence Fantasy Violence To change all V-Chip movie or TV ratings to View, press the 0 number button. Blocking Age-Based Ratings You can automatically block all program ratings above a specified age- based rating level. To block programs with higher ratings: 1. -
Page 39: Canada V-Chip Ratings
4. Press the OK button to change the status back to adult language content, but not programs with TV-MA language content. Note: Only the content theme status corresponding to TV-14 (L) language changes to (V) View. Higher rated content themes, such as that for TV-MA language, do not change. -
Page 40: Canadian French V-Chip Rating System
Using the TV’s Features Rating Adults. Programming is for adults only. This program contains sustained violence or extremely violent 18 ans + scenes. Viewers 16 and over. Programming is not suitable for those under age 16. This program contains 16 ans + frequent scenes of violence or intensely violent scenes. -
Page 41: V-Chip Movie Rating Limit
V-Chip Movie Rating Limit Set movie rating limits by blocking movies rated above a specified level. To access the Movie Rating Limit menu: 1. Press MENU on the remote control (the TV's MAIN MENU appears). 2. Select Parental Control. 3. Select US V-Chip. -
Page 42: Lock/Unlock Parental Controls
Parental Controls again. Front Panel Block Selecting this option lets you block (disable) or unblock (enable) the TV’s front panel. The remote still tunes to any channel. When using this as a Parental Control method, remove access to any remote that is capable of operating the television while you have the front panel blocked. -
Page 43: Chapter 4: Using The Tv's Menu System
Using the TV's Menu System Chapter Overview: • Sound Menu • Picture Menu • Channel Guide Menu • Time Menu • Parental Control Menu • Setup Menu Changing Entertainment. Again. Changing Entertainment. Again. Graphics contained within this publication are for representation only. -
Page 44: Sound Menu
If your preferred language is being broadcast with a program, then the TV will play it. If not, then the TV will play the default audio for the program (usually English in the U.S.). The default digital channel audio language options are English, Spanish, German, Italian, Japanese, Chinese, and Korean. -
Page 45: Using The Tv's Menu System
The language you choose becomes your preferred audio language for all channels on the digital tuner until you turn the TV off. If the language you choose here is not being broadcast with a program, then the TV will play the default audio for the program (usually English in the U.S.). -
Page 46: Picture Menu
The On setting should only be used in rare circumstances when the TV is used solely with film-based sources (like DVDs on a non- progressive-scan player). The Off setting turns off film mode upconversion. Try using this Off setting turns off film mode upconversion. - Page 47 Each ANTENNA jack counts as a single input. Chapter 4 Using the TV’s Menu System Picture preset Displays a choice list that lets you select one of the preset Picture preset Picture preset Displays a choice list that lets you select one of the preset picture settings: Vibrant, Cinematic, Natural, Sports, Videogame, Video Camera or Personal.
-
Page 48: Channel Guide Menu
Using the TV’s Menu System Channel Guide Menu The Channel Guide lets you view the entire list of channel numbers and labels for the tuner you're on. Press the GUIDE button to bring up the Channel Guide menu. There are two different kinds of channel guides—the one you see depends on the tuner you're on. -
Page 49: Remote
first enter the number zero, then number eight. Use the OK button to choose between AM and PM. Wake up timer Lets you set the TV to turn itself on. When you turn on Wake up timer, the following options appear: Wake up time Lets you set the time you want the TV to turn itself on. -
Page 50: Features
If you change how you receive broadcasts through the antenna input, you must change the Signal type setting. Choose Cable if you are using cable or a cable box for TV signals. Cable Cable if you are using cable or a cable box for TV signals. - Page 51 Closed Caption information, which lets you display the audio portion of a program as text on the TV screen. Some programs on digital channels offer digital captioning information, which gives you more options for the way the captioning is displayed on the screen.
- Page 52 Using the TV’s Menu System Go back Closed Caption Setting On... Analog CC Type CC1... Digital CC Type Service 1... Digital CC Preset Custom... Digital CC Style Press < or > key to select the closed caption setting. Go back Closed Caption Size Standard...
- Page 53 Convergence Chapter 4 Using the TV’s Menu System Autotuning Displays a choice list that lets you set up the TV to automatically Autotuning Autotuning Displays a choice list that lets you set up the TV to automatically tune to the correct input channel when you press a component button (VCR, DVD, AUX•HD or SAT•CABLE) on the remote.
- Page 54 This page left blank intentionally.
-
Page 55: Chapter 5: Other Information
Other Information Chapter Overview: • Troubleshooting • Care and Cleaning • FCC Information • Limited Warranty • Accessory Information Changing Entertainment. Again. Changing Entertainment. Again. Graphics contained within this publication are for representation only. -
Page 56: Troubleshooting
Check the wall receptacle (or extension cord) to make sure it is “live” by plugging in something else. • Something might be wrong with your remote control. Press the POWER button on the front of the TV. If the TV turns on, check the remote control solutions on the next page. - Page 57 Channel may be blocked or not approved in the Parental Controls menu. • If using a VCR, check to make sure the TV/VCR button on the VCR is in the correct mode (press the TV/VCR button on your VCR). Noisy stereo reception •...
- Page 58 If you forget your password, press MENU, then select Parental Control (the password entry screen appears). Simultaneously press and hold CH+ and VOL+ on the TV’s front panel for 8 seconds. The Parental control menu appears on the screen, and you can re- enter a password via Lock Parental Controls.
-
Page 59: Care And Cleaning
While cleaning do not spray liquid directly on the screen, or allow liquid to run down the screen and inside the TV. Also, never place drinks or vases with water on top of the TV. This could increase the risk of fire or shock hazard or damage to the TV. -
Page 60: Limited Warranty
• Please complete the online Product Registration on www.rca.com or complete and mail the Product Registration Card packed with your unit. It will make it easier to contact you should it ever be necessary. The return of the card is not required for warranty coverage. - Page 61 Limitation of Warranty: • THE WARRANTY STATED ABOVE IS THE ONLY WARRANTY APPLICABLE TO THIS PRODUCT. ALL OTHER WARRANTIES, EXPRESS OR IMPLIED (INCLUDING ALL IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE) ARE HEREBY DISCLAIMED. NO VERBAL OR WRITTEN INFORMATION GIVEN BY TTE TECHNOLOGY INC., ITS AGENTS OR EMPLOYEES SHALL CREATE A GUARANTY OR IN ANY WAY INCREASE THE SCOPE OF THIS WARRANTY.
-
Page 62: Accessory Information
You can buy some accessories on-line at: www.rca.com. Screw-on Cable attaches to the round antenna connectors (called 75-ohm F-type) on the back of your VCR or TV. The ends screw onto the connectors VH81 (3-ft), price: $3.95 for a secure connection. -
Page 63: Index
Digital sound 3 Accessories 60 Digital closed captions 49, 50 Age-based ratings 36 Digital TV 2, 10, 13, 15, 19, 30, Amplifier 42 Analog closed captions 49, 50 Direct entry programming 25 Analog TV 2, 10, 30, 31, 46, 48 ANT•CAB button 2, 22... - Page 64 TTE Technology, Inc. 10330 North Meridian Street Indianapolis, IN 46290 ©2005 TTE Technology, Inc. RCA and associated marks are trademarks of THOMSON S.A. used under license to TTE Corporation. Printed in USA TOCOM 16510760...
