OWNER'S MANUAL
YZF-R3
MOTORCYCLE
Read this manual carefully before oper-
ating this vehicle.
YZF-R3A
BR5-F8199-E0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the YZF-R3A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Yamaha YZF-R3A

Summary of Contents for Yamaha YZF-R3A

  • Page 1 OWNER’S MANUAL YZF-R3 MOTORCYCLE Read this manual carefully before oper- ating this vehicle. YZF-R3A BR5-F8199-E0...
  • Page 2 EAU46094 Read this manual carefully before operating this vehicle. This manual should stay with this vehicle if it is sold.
  • Page 3 Please take the time to read this manual thoroughly, so as to enjoy all advantages of your YZF-R3A. The Owner’s Manual does not only instruct you in how to oper- ate, inspect and maintain your motorcycle, but also in how to safeguard yourself and others from trouble and injury.
  • Page 4 *Product and specifications are subject to change without notice. EAUN0430 YZF-R3A OWNER’S MANUAL ©2017 PT Yamaha Indonesia Motor Manufacturing 1st edition, June 2017 All rights reserved. Any reprinting or unauthorized use without the written permission of...

  • Page 5: Table Of Contents

    Table of contents Safety information ......1-1 Periodic maintenance chart for the emission control system..6-3 Description ........2-1 General maintenance and Left view ..........2-1 lubrication chart......6-4 Right view........2-2 Checking the spark plugs ....6-7 Controls and instruments....2-3 Canister........... 6-8 Engine oil and oil filter cartridge ..6-8 Instrument and control functions..3-1 Coolant .........
  • Page 6 Table of contents Replacing a turn signal light bulb ........... 6-36 Replacing the license plate light bulb ........6-36 Supporting the motorcycle... 6-37 Troubleshooting......6-38 Troubleshooting charts....6-39 Motorcycle care and storage..7-1 Matte color caution ......7-1 Care ..........7-1 Storage ...........

  • Page 7: Safety Information

    Safety information EAU1028C an accident or equipment damage. See page 4-1 for a list of pre-operation checks. Be a Responsible Owner  This motorcycle is designed to As the vehicle’s owner, you are re- carry the operator and a passen- sponsible for the safe and proper oper- ger.
  • Page 8 Safety information  Many accidents involve inexperi- • The passenger should always enced operators. In fact, many op- hold onto the operator, the seat erators who have been involved in strap or grab bar, if equipped, accidents do not even have a cur- with both hands and keep both rent motorcycle license.
  • Page 9 Safety information Avoid Carbon Monoxide Poisoning extra care when riding a motorcycle All engine exhaust contains carbon that has added cargo or accessories. monoxide, a deadly gas. Breathing Here, along with the information about carbon monoxide can cause head- accessories below, are some general aches, dizziness, drowsiness, nausea, guidelines to follow if loading cargo to confusion, and eventually death.
  • Page 10 Genuine before using it to make sure that it Yamaha accessories, which are avail- does not in any way reduce able only from a Yamaha dealer, have ground clearance or cornering been designed, tested, and approved clearance, limit suspension travel, by Yamaha for use on your vehicle.
  • Page 11 Safety information operator and may limit control handlebars or turn signals, or ability, therefore, such accesso- parts that could break). Choose ries are not recommended. the location for the straps carefully  Use caution when adding electri- so the straps will not rub against cal accessories.

  • Page 12: Description

    Description EAU63371 Left view 1. Coolant reservoir (page 6-11) 2. Main fuse (page 6-31) 3. Owner’s tool kit (page 6-2) 4. Passenger seat lock (page 3-18) 5. Storage compartment (page 3-21) 6. Shock absorber assembly spring preload adjusting ring (page 3-22) 7.

  • Page 13: Right View

    Description EAU63391 Right view 1. Fuse box (page 6-31) 2. Battery (page 6-30) 3. Fuel tank cap (page 3-15) 4. Headlight (page 6-33) 5. Engine oil filler cap (page 6-8) 6. Engine oil level check window (page 6-8) 7. Brake pedal (page 3-14) 8.

  • Page 14: Controls And Instruments

    Description EAU63401 Controls and instruments 1. Clutch lever (page 3-12) 2. Left handlebar switches (page 3-11) 3. Multi-function meter unit (page 3-4) 4. Main switch/steering lock (page 3-1) 5. Front brake fluid reservoir (page 6-22) 6. Right handlebar switches (page 3-11) 7.

  • Page 15: Instrument And Control Functions

    Instrument and control functions EAU10462 EAU60863 Main switch/steering lock LOCK The steering is locked and all electrical systems are off. The key can be re- moved. To lock the steering LOCK The main switch/steering lock controls the ignition and lighting systems, and is used to lock the steering.

  • Page 16: Indicator Lights And Warning Lights

    Instrument and control functions From the “LOCK” position, push the EAU4939C Indicator lights and warning key and turn it to “ ”. lights km/h km/L L/100km mileMPG 1. Neutral indicator light “ ” 2. High beam indicator light “ ” 3.
  • Page 17 “ ”, initially when the key is turned to “ ”, have a Yamaha dealer check the elec- or if the warning light remains on, have trical circuit. a Yamaha dealer check the vehicle.

  • Page 18: Multi-Function Meter Unit

    “ ”, multi-function meter unit. Changing or if the indicator light remains on, have settings while riding can distract the a Yamaha dealer check the electrical operator and increase the risk of an circuit. accident. multi-function...
  • Page 19 Instrument and control functions Speedometer Clock The speedometer shows the vehicle’s traveling speed. For the UK: to switch the speedometer and multi-function displays between kilometers and miles, press the “SEL” button for one second. Tachometer 1. Clock The clock displays time in 12-hour for- mat.
  • Page 20 Instrument and control functions The fuel meter indicates the amount of ECA10022 NOTICE fuel in the fuel tank. When the key is turned to “ ”, the dis- Do not continue to operate the en- play segments of the fuel meter will gine if it is overheating.
  • Page 21 Instrument and control functions  two tripmeters stantaneous fuel consumption and av-  a fuel reserve tripmeter erage fuel consumption modes in the  an instantaneous fuel consump- following order: tion display TRIP F → L/100 km or km/L → AVE_ ...
  • Page 22 Instrument and control functions  “L/100 km”: The amount of fuel that point. In that case, push the “SEL” button to switch the display between necessary to travel 100 km under the various tripmeter, odometer, in- the current riding conditions is stantaneous fuel consumption and av- shown.
  • Page 23 Instrument and control functions  “AVE_ _._ MPG” (for the UK): The tripmeter are flashing, push the “RES” average distance that can be trav- button for three seconds. The oil chan- eled on 1.0 Imp. gal of fuel is ge indicator will be reset. shown.
  • Page 24 Instrument and control functions To adjust the shift timing indicator light r/min to 12000 r/min, the indicator light 1. Turn the key to “ ”. can be set in increments of 500 r/min. 2. Push and hold the “SEL” button. From 12000 r/min to 13500 r/min, the 3.

  • Page 25: Handlebar Switches

    Instrument and control functions 2. Push the “SEL” button to confirm EAU1234M Handlebar switches the selected brightness level. The display exits the shift timing light Left control mode and returns to the standard multi-function display mode. 1. Pass switch “PASS” 2.

  • Page 26: Clutch Lever

    Instrument and control functions EAU12822 Clutch lever When the switch is set to low beam, only the right headlight bulb comes on. When the switch is set to high beam, both headlight bulbs come on. EAU12461 Turn signal switch “ ”...

  • Page 27: Shift Pedal

    Instrument and control functions EAU12872 EAU12892 Shift pedal Brake lever 1. Shift pedal 1. Brake lever The shift pedal is located on the left The brake lever is located on the right side of the motorcycle and is used in side of the handlebar.

  • Page 28: Brake Pedal

    Instrument and control functions EAU12944 EAU63040 Brake pedal The Yamaha ABS (Anti-lock Brake System) features a dual electronic con- trol system, which acts on the front and rear brakes independently. Operate the brakes with ABS as you would conventional brakes. If the ABS...

  • Page 29: Fuel Tank Cap

    ABS is op- erating. However, special tools are required, so please consult your Yamaha dealer. ECA20100 NOTICE Be careful not to damage the wheel sensor or wheel sensor rotor; other- 1.

  • Page 30: Fuel

    Instrument and control functions EAU13222 3. Wipe up any spilled fuel immedi- Fuel NOTICE: ately. Immediately Make sure there is sufficient gasoline in wipe off spilled fuel with a clean, the tank. dry, soft cloth, since fuel may EWA10882 deteriorate painted surfaces or WARNING plastic parts.

  • Page 31: Fuel Tank Overflow Hose

     Check that gasoline nozzle has the same identifier when fueling. Before operating the motorcycle:  Check the fuel tank overflow hose Your Yamaha engine has been de- connection. signed to use regular unleaded gaso-  Check the fuel tank overflow hose...

  • Page 32: Catalytic Converter

    Instrument and control functions EAU13434 EAU62622 Catalytic converter Seats This model is equipped with a catalytic converter in the exhaust system. Passenger seat EWA10863 WARNING To remove the passenger seat The exhaust system is hot after op- 1. Insert the key into the seat lock, and then turn it clockwise.
  • Page 33 Instrument and control functions Rider seat To remove the rider seat 1. Remove the passenger seat. 2. Remove the center cover by re- moving the screws. 1. Projection 2. Seat holder 2. Install the rider seat bolts. 3. Install the center cover by install- ing the screws.

  • Page 34: Helmet Holders

    Instrument and control functions EAU62930 To release a helmet from a helmet Helmet holders holder Remove the passenger seat, remove the helmet from the helmet holder, and then install the seat. 1. Helmet holder The helmet holders are located on the bottom of the passenger seat.

  • Page 35: Storage Compartment

    Instrument and control functions EAU62550 EAU39672 Storage compartment Rear view mirrors The rear view mirrors of this vehicle can be folded forward or backward for parking in narrow spaces. Fold the mir- rors back to their original position be- fore riding. 1.

  • Page 36: Adjusting The Shock Absorber Assembly

    Instrument and control functions EAU68141 Adjusting the shock absorber 3 2 1 assembly 7 6 5 4 This shock absorber assembly is equipped with a spring preload adjust- ing ring. ECA10102 NOTICE To avoid damaging the mechanism, do not attempt to turn beyond the 1.

  • Page 37: Luggage Strap Holders

    Therefore, check this system regularly and have a Yamaha dealer repair it if it does not function properly. 3-23...

  • Page 38: Ignition Circuit Cut-Off System

    Instrument and control functions EAU66730 Ignition circuit cut-off system The ignition circuit cut-off system (comprising the sidestand switch, clutch switch and neutral switch) has the following functions.  It prevents starting when the transmission is in gear and the sidestand is up, but the clutch le- ver is not pulled.
  • Page 39 Does the engine start? The neutral switch may not be working correctly. The motorcycle should not be ridden until checked by a Yamaha dealer. With the engine still running: 6. Move the sidestand up. 7. Keep the clutch lever pulled.

  • Page 40: For Your Safety - Pre-Operation Checks

    Do not operate the vehicle if you find any problem. If a problem cannot be corrected by the procedures provided in this manual, have the vehicle inspected by a Yamaha dealer. Before using this vehicle, check the following points:...
  • Page 41 • Tighten if necessary. • Check operation. Instruments, lights, — signals and switches • Correct if necessary. • Check operation of ignition circuit cut-off system. Sidestand switch • If system is not working correctly, have Yamaha dealer 3-23 check vehicle.

  • Page 42: Operation And Important Riding Points

    This model is equipped with: there is a control or function you do not  a lean angle sensor to stop the en- understand, ask your Yamaha dealer. gine in case of turnover. In this EWA10272 case, turn the key “OFF” and then WARNING to “ON”...

  • Page 43: Starting The Engine

    2. Shift the transmission into the neutral position. The neutral indi- cator light should come on. If not, ask a Yamaha dealer to check the electrical circuit. 3. Start the engine by pushing the start switch.

  • Page 44: Shifting

    Operation and important riding points EAU16673 and drive train, which are not Shifting designed withstand shock of forced shifting. 1. Shift pedal 2. Neutral position Shifting gears lets you control the amount of engine power available for starting off, accelerating, climbing hills, etc.

  • Page 45: Engine Break-In

    The vehicle can now be operated nor- mally. ECA10311 NOTICE  Keep the engine speed out of the tachometer red zone.  If any engine trouble should oc- cur during the engine break-in period, immediately have a Yamaha dealer check the vehi- cle.

  • Page 46: Periodic Maintenance And Adjustment

    If you are not familiar with vehicle ser- vice, have a Yamaha dealer perform service. EWA15123 WARNING Turn off the engine when performing...

  • Page 47: Owner's Tool Kit

    If you do not have the tools or experi- ence required for a particular job, have a Yamaha dealer perform it for you.

  • Page 48: Periodic Maintenance Chart For The Emission Control System

     From 50000 km (30000 mi), repeat the maintenance intervals starting from 10000 km (6000 mi).  Items marked with an asterisk should be performed by a Yamaha dealer as they require special tools, data and technical skills. EAU71071...

  • Page 49: General Maintenance And Lubrication Chart

    X 1000 km X 1000 mi • Perform dynamic inspection Diagnostic system √ √ √ √ √ √ using Yamaha diagnostic tool. check • Check the error codes. √ √ 2 * Air filter element • Replace. Air filter case √ √...
  • Page 50 Periodic maintenance and adjustment ODOMETER CHECK OR READINGS MAINTENANCE JOB ITEM X 1000 km X 1000 mi • Check bearing assemblies for √ √ √ looseness. 14 * Steering bearings • Moderately repack with lithium- √ √ soap-based grease. • Make sure that all nuts, bolts √...
  • Page 51 Periodic maintenance and adjustment ODOMETER CHECK OR READINGS MAINTENANCE JOB ITEM X 1000 km X 1000 mi Moving parts and √ √ √ √ √ 28 * • Lubricate. cables • Check operation and free play. • Adjust the throttle cable free Throttle grip hous- √...

  • Page 52: Checking The Spark Plugs

    The spark plugs are important engine components, which should checked periodically, preferably by a Yamaha dealer. Since heat and depos- its will cause any spark plug to slowly erode, they should be removed and checked in accordance with the peri- odic maintenance and lubrication 1.

  • Page 53: Canister

    Periodic maintenance and adjustment EAU36112 EAU62632 Canister Engine oil and oil filter car- tridge The engine oil level should be checked before each ride. In addition, the oil must be changed and the oil filter car- tridge replaced at the intervals speci- fied in the periodic maintenance and lubrication chart.
  • Page 54 3. Place an oil pan under the engine An oil filter wrench is available at a to collect the used oil. Yamaha dealer. 4. Remove the engine oil filler cap, 6. Apply a thin coat of clean engine the engine oil drain bolt and its...
  • Page 55 Periodic maintenance and adjustment Recommended engine oil: See page 8-1. Oil quantity: Oil change: 1.80 L (1.90 US qt, 1.58 Imp.qt) With oil filter removal: 2.10 L (2.22 US qt, 1.85 Imp.qt) Be sure to wipe off spilled oil on any 1.

  • Page 56: Coolant

    Yamaha dealer and lubrication chart. check the vehicle. 11. Turn the engine off, wait a few mi-...
  • Page 57 If water has been voir. added to the coolant, have a Yamaha dealer check the anti- freeze content of the coolant as soon as possible, otherwise the effectiveness of the coolant will be reduced.

  • Page 58: Replacing The Air Filter Element And Cleaning The Check Hose

    1. Remove the left side panel by re- tervals specified in the periodic mainte- moving the bolts. nance and lubrication chart. Have a Yamaha dealer change the coolant. WARNING! Never attempt to remove the radiator cap when the engine is hot.
  • Page 59 Periodic maintenance and adjustment 3. Pull the air filter element out. 2. If dirt or water is visible, remove the hose, clean it, and then install 1. Air filter element 4. Insert a new air filter element into the air filter case. NOTICE: Make sure that the air filter element is properly seated in the air filter case.

  • Page 60: Checking The Throttle Grip Free Play

    Measure the throttle grip free play as and/or engine noise. To prevent this shown. from occurring, the valve clearance must be adjusted by a Yamaha dealer at the intervals specified in the periodic maintenance and lubrication chart. 1. Throttle grip free play Throttle grip free play: 3.0–5.0 mm (0.12–0.20 in)

  • Page 61: Tires

    The tires must be checked before each ride. If the center tread depth reaches the specified limit, if the tire has a nail or glass fragments in it, or if the side- wall is cracked, have a Yamaha dealer replace the tire immediately. 6-16...
  • Page 62 After extensive tests, only the tires list- ed below have been approved for this EWA10472 model by Yamaha. WARNING  Have a Yamaha dealer replace Front tire: excessively worn tires. Besides Size: being illegal, operating the vehi- 110/70-17M/C (54H)

  • Page 63: Cast Wheels

    If any damage is found, have a Yamaha dealer replace the wheel. Do not attempt even the smallest repair to the wheel. A de- formed or cracked wheel must be replaced.
  • Page 64 Periodic maintenance and adjustment 1. Right side cowling 1. Slot 2. Bolt 2. Projection 3. Right side cowling 5. Loosen the locknut at the crank- 9. Tighten the locknut at the clutch case. lever. 6. To increase the clutch lever free play, turn the clutch lever free play adjusting nut in direction (a).

  • Page 65: Checking The Brake Lever Free Play

    Yamaha dealer. 1. No brake lever free play There should be no free play at the brake lever end. If there is free play, have a Yamaha dealer inspect the brake system. EWA14212 WARNING A soft or spongy feeling in the brake lever can indicate the presence of air in the hydraulic system.

  • Page 66: Checking The Front And Rear Brake Pads

    1. Brake pad wear indicator groove indicator grooves have almost disap- Each front brake pad is provided with peared, have a Yamaha dealer replace wear indicator grooves, which allow the brake pads as a set. you to check the brake pad wear with- out having to disassemble the brake.

  • Page 67: Checking The Brake Fluid Level

    Specified brake fluid: brake system for leakage. If the brake DOT 4 fluid level goes down suddenly, have a Yamaha dealer check the cause before EWA16011 WARNING further riding. Improper maintenance can result in loss of braking ability.

  • Page 68: Changing The Brake Fluid

    EAU22734 EAU22762 Changing the brake fluid Drive chain slack Have a Yamaha dealer change the The drive chain slack should be brake fluid every 2 years. In addition, checked before each ride and adjusted have the seals of the master cylinders if necessary.
  • Page 69 [ECA17791] EAU62983 To adjust the drive chain slack Consult a Yamaha dealer before ad- justing the drive chain slack. 1. Remove the drive chain puller cap, and then loosen the axle nut and 1. Drive chain slack adjusting nut the locknut on each side of the swingarm.

  • Page 70: Cleaning And Lubricating The Drive Chain

    If a cable is wet areas. Service the drive chain as damaged or does not move smoothly, follows. have a Yamaha dealer check or re- place it. WARNING! Damage to the ECA10584 NOTICE outer housing of cables may result...

  • Page 71: Checking And Lubricating The Throttle Grip And Cable

    In pedals should be checked before each addition, the cable should be lubricat- ride, and the pedal pivots should be lu- ed by a Yamaha dealer at the intervals bricated if necessary. specified in the periodic maintenance Brake pedal chart.

  • Page 72: Checking And Lubricating The Brake And Clutch Levers

    EWA10732 Clutch lever WARNING If the sidestand does not move up and down smoothly, have a Yamaha dealer check or repair it. Otherwise, the sidestand could contact the ground and distract the operator, re- sulting in a possible loss of control.

  • Page 73: Lubricating The Swingarm Pivots

    1. Place the vehicle on a level surfa- The swingarm pivots must be lubricat- ce and hold it in an upright posi- ed by a Yamaha dealer at the intervals tion. WARNING! To avoid injury, specified in the periodic maintenance securely support the vehicle so and lubrication chart.

  • Page 74: Checking The Steering

    If any free smoothly, have a Yamaha dealer play can be felt, have a Yamaha check the wheel bearings. dealer check or repair the steer- ing.

  • Page 75: Battery

    This model is equipped with a VRLA To charge the battery (Valve Regulated Lead Acid) battery. Have a Yamaha dealer charge the bat- There is no need to check the electro- tery as soon as possible if it seems to lyte or to add distilled water.

  • Page 76: Replacing The Fuses

    Periodic maintenance and adjustment 2. If the battery will be stored for EAUN0821 Replacing the fuses more than two months, check it at The main fuse is located under the least once a month and fully char- passenger seat. ge it if necessary. To access the main fuse, proceed as 3.
  • Page 77 Periodic maintenance and adjustment 5. Place the tray in its original posi- Fuse box 2 tion, and then install the quick fas- teners. 6. Install the passenger seat. Fuse box 1 is located behind the center cover. (See page 3-18.) Fuse box 1 1.

  • Page 78: Replacing A Headlight Bulb

     Headlight lens 4. If the fuse immediately blows Do not affix any type of tinted again, have a Yamaha dealer film or stickers to the headlight check the electrical system. lens. Do not use a headlight bulb of a wattage higher than specified.
  • Page 79 Periodic maintenance and adjustment 7. Have a Yamaha dealer adjust the headlight beam if necessary. 1. Headlight bulb cover 2. Disconnect the headlight coupler. 1. Headlight coupler 3. Unhook the headlight bulb holder, and then remove the burnt-out bulb. 1. Headlight bulb holder 4.

  • Page 80: Auxiliary Light Bulb

    If the tail/brake light does not come on, have a Yamaha dealer check it. 1. Auxiliary light If the auxiliary light does not come on, have a Yamaha dealer check the elec- trical circuit or replace the bulb. 6-35...

  • Page 81: Replacing A Turn Signal Light Bulb

    Periodic maintenance and adjustment EAU62590 EAU62670 Replacing a turn signal light Replacing the license plate bulb light bulb 1. Remove the turn signal light lens 1. Remove the mudguard by remov- by removing the screw. ing the quick fasteners. 1. Turn signal light lens 1.

  • Page 82: Supporting The Motorcycle

    Periodic maintenance and adjustment EAU24351 Supporting the motorcycle Since this model is not equipped with a centerstand, follow these precautions when removing the front and rear wheel or performing other mainte- nance requiring the motorcycle to stand upright. Check that the motorcy- cle is in a stable and level position be- fore starting any maintenance.

  • Page 83: Troubleshooting

    The following troubleshooting charts represent quick and easy procedures for checking these vital systems your- self. However, should your motorcycle require any repair, take it to a Yamaha dealer, whose skilled technicians have the necessary tools, experience, and know-how to service the motorcycle properly.

  • Page 84: Troubleshooting Charts

    Check the vehicle. compression. 4. Compression The engine does not start. There is compression. Have a Yamaha dealer check the vehicle. Operate the electric starter. There is no Have a Yamaha dealer check the vehicle. compression. 6-39...
  • Page 85 Start the engine. If the engine overheats again, The coolant level is have a Yamaha dealer check and repair the cooling system. If coolant is not available, tap water can be temporarily used instead, provided that it is changed to the recommended coolant as soon as possible.

  • Page 86: Motorcycle Care And Storage

    Be ble. Rust and corrosion can develop even if high-quality components are sure to consult a Yamaha dealer for used. A rusty exhaust pipe may go un- advice on what products to use be- noticed on a car, however, it detracts fore cleaning the vehicle.
  • Page 87 Motorcycle care and storage fected area any longer than in- scratching. Some cleaning structed. Also, thoroughly rinse compounds for plastic may the area off with water, immedi- leave scratches on the wind- ately dry it, and then apply a cor- shield.
  • Page 88  Consult a Yamaha dealer for ad- 4. To prevent corrosion, it is recom- vice on what products to use. mended to apply a corrosion pro- ...

  • Page 89: Storage

    Motorcycle care and storage on for a short period of time will EAU26183 Storage help remove the moisture from the lens. Short-term Always store your motorcycle in a cool, dry place and, if necessary, protect it against dust with a porous cover. Be sure the engine and the exhaust sys- tem are cool before covering the mo- torcycle.
  • Page 90 Motorcycle care and storage der head so that the electrodes are grounded. (This will limit Make any necessary repairs before sparking during the next step.) storing the motorcycle. d. Turn the engine over several times with the starter. (This will coat the cylinder walls with oil.) WARNING! To prevent dam- age or injury from sparking,...

  • Page 91: Specifications

    Specifications Dimensions: With oil filter removal: 2.10 L (2.22 US qt, 1.85 Imp.qt) Overall length: Coolant quantity: 2090 mm (82.3 in) Overall width: Coolant reservoir (up to the maximum level 720 mm (28.3 in) mark): Overall height: 0.25 L (0.26 US qt, 0.22 Imp.qt) 1135 mm (44.7 in) Radiator (including all routes): Seat height:...
  • Page 92 Specifications 5th: Rim size: 0.920 (23/25) 17M/C x MT4.00 6th: Front brake: 0.800 (24/30) Type: Chassis: Hydraulic single disc brake Frame type: Specified brake fluid: Diamond DOT 4 Caster angle: Rear brake: 25.0 ° Type: Trail: Hydraulic single disc brake 95 mm (3.7 in) Specified brake fluid: Front tire:...
  • Page 93 Specifications Brake/tail light: Front turn signal light: 10.0 W Rear turn signal light: 10.0 W Auxiliary light: 5.0 W Meter lighting: Neutral indicator light: High beam indicator light: Oil pressure warning light: Turn signal indicator light: Engine trouble warning light: ABS warning light: Fuse(s): Main fuse:...

  • Page 94: Consumer Information

    Yamaha dealer. EAU26442 Engine serial number VEHICLE IDENTIFICATION NUMBER: ENGINE SERIAL NUMBER: 1.

  • Page 95: Diagnostic Connector

    Consumer information label in the space provided. This infor- EAU69910 Diagnostic connector mation will be needed when ordering spare parts from a Yamaha dealer. 1. FI diagnostic connector The diagnostic connector is located as shown.

  • Page 96: Vehicle Data Recording

     Vehicle status and engine perfor- mance data  Fuel-injection and emission-relat- ed data Yamaha will not disclose this data to a third party except:  With the consent of the vehicle owner  Where obligated by law ...

  • Page 97: Index

    Index Horn switch........... 3-12 ABS ............3-14 ABS warning light........3-3 Identification numbers ......9-1 Air filter element and check hose, Ignition circuit cut-off system ....3-24 replacing and cleaning....... 6-13 Indicator lights and warning lights ..3-2 Auxiliary light bulb ........ 6-35 License plate light bulb, replacing ..6-36 Battery..........
  • Page 98 Index Tool kit ............6-2 Troubleshooting........6-38 Troubleshooting charts......6-39 Turn signal indicator light .......3-2 Turn signal light bulb, replacing....6-36 Turn signal switch .........3-12 Valve clearance........6-15 Vehicle identification number ....9-1 Wheel bearings, checking.....6-29 Wheels ..........6-18 10-2...
  • Page 100 PRINTED IN INDONESIA 2017.06...
