Summary of Contents for Tricity Bendix DH 102
- Page 1 INSTRUCTION BOOK Dishwasher DH 102...
- Page 2 Description of the appliance IN68 Water hardness adjustment Rinse aid dispenser Levelling spacers 10. Central filter Upper basket stop 11. Lower spray arm Salt container 12. Upper spray arm Large filter 13. Upper basket Detergent dispenser 14. Worktop Control panel Rating plate...
- Page 3 The control panel 1. MAINS ON indicator light 2. On/Off push button 3. Programme guide 4. Door handle 5. Programme marker 6. Programme selector dial 7. Programme sequence indicator As the programme progresses, the programme selector dial turns, to show the phase in the wash programme the appliance has reached.
- Page 4 Washing programmes Programme Degree of soil Starting Required Recommended Cycle description quantity of position of the push button detergent type of load programme selector Prewash Wash Any. 1 cold rinse (to avoid Partial load (to be RINSE food scraps from On/Off completed later in the sticking together).
- Page 5 Operating sequence Check the filters At the end of the washing programme Ensure they are clean and properly positioned See "Maintenance and cleaning" section. At the end of the programme the dishwasher will automatically stop. Check that there is rinse aid and 10.
- Page 6 Using your appliance Loading your appliance Before placing dishes in the machine, remove any scraps of food, to avoid clogging the filters and consequently reducing the performance. Do not load very small items which can fall through the baskets. UI49 The lower basket The lower basket is designed to take saucepans, lids, plates, salad bowls, cutlery etc.
- Page 7 The upper basket The upper basket is designed for plates (dessert plates, saucers, dinner plates of up to 25 cm in diameter), salad bowls, cups and glasses. Arrange items so that water can reach all surfaces. Light items (plastic bowls etc.) should be loaded in the upper basket and arranged so they do not move.
- Page 8 Hints for test centres Before starting any test it is necessary to fill completely with salt the salt container and with rinse aid the rinse aid dispenser Test standard: EN 50242 Reference programme: NORMAL WASH Load: 12 standard place settings Rinse aid selector: position 5 Detergent dosage:...
- Page 9 Fitting under a counter (kitchen worktop or sink) By removing the machine’s worktop, you can install it under a close fitting sink unit or a pre-existing top, providing the dimensions of the recess correspond to those shown in the picture. Proceed as follows: - Remove the machine’s worktop by unscrewing the two rear retaining screws, pull from the front and slide out...
- Page 10 Tricity Bendix, 55-77 High Street, Slough, Berkshire, SL1 1DZ Customer care telephone number... 08705 950 950 From the Electrolux Group. The world’s No.1 choice. The Electrolux Group is the world’s largest producer of powered appliances for kitchen, cleaning and outdoor use. More than 55 million Electrolux Group products (such as refrigerators, cookers, vacuum cleaners, chain saws and lawn mowers) are sold each year to a value of approx.
-
Page 11: Table Of Contents
Instruction Book - Before use - Maintenance - Installation DISHWASHER Contents Important safety information Before use Setting the water softener Filling with salt Filling with rinse aid and adjusting the dose Use of detergent Hints and tips Maintenance and cleaning Internal cleaning Cleaning the filters External cleaning... -
Page 12: Important Safety Information
Important safety information It is most important that this instruction book should be retained with the appliance for future reference. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure that the book is left with the appliance in order that the new owner can get to know the functioning of the appliance and the relevant safety information. -
Page 13: Before Use
Before use Before using your dishwasher for the first time: 1. Ensure that the electrical and water connections comply with the installation instructions 2. Remove all packaging from inside the appliance 3. Set the water softener 4. Pour 1 litre of water inside the salt container and then fill with salt 5. -
Page 14: Filling With Salt
Filling with salt Attention! Only use salt specifically designed for use in dishwashers. All other types of salt not specifically designed for use in dishwasher, especially table salt, will damage the water softener. Only fill with salt just before starting a washing SR15 programme. - Page 15 Rinse aid Rinse aid is automatically added during the last rinse, ensuring thorough rinsing, and spot and streak free drying. The dispenser, which is positioned inside the door, holds about 110 ml of rinse aid, which is sufficient for 16 - 40 dishwashing programmes, depending upon the dosage setting.
-
Page 16: Use Of Detergent
Use of detergent Only use detergents specifically designed for use in dishwashers. We recommend the use of Finish detergents which are available in the following options: Min = 15 g Finish Double Action Tablets. Each tablet has the exact Max = 30 g amount of detergent required, simply place in the dispenser. -
Page 17: Hints And Tips
Hints and tips To save energy Items not suitable for dishwashers Place dishes in the machine immediately after every meal The following items should not be washed in the and wait until the dishwasher is full before washing. dishwasher (unless they are sold as dishwasher proof): If necessary run the Rinse and Hold programme (see "Washing Programmes"... -
Page 18: Maintenance And Cleaning
Maintenance and cleaning Internal cleaning Ensure that the seals around the door, the detergent and rinse aid dispensers are cleaned regularly with a damp cloth. We recommend the use of Finish Dishwasher Cleaner every 3 months or run a 65°C wash without dishes using detergent. -
Page 19: Something Not Working
Something not working Certain problems are due to lack of simple maintenance or oversights, which can be solved easily without calling out an engineer. Before contacting your local Service Force Centre, please carry out the checks listed below. Important: If you call out an engineer to a fault listed below or to repair a fault caused by incorrect use or installation a charge will be made even if the appliance is in guarantee. -
Page 20: Installation
Installation Any electrical work required to install this appliance should be carried out by a qualified electrician or competent person. Any plumbing work required to install this appliance should be carried out by a qualified plumber or competent person. Remove all packaging before positioning the machine. If possible, position the machine next to a water tap and a drain. -
Page 21: Electrical Connection
The waste connection must be at a height of between 30 cm (minimum) and 100 cm (maximum) from the bottom of the dishwasher. The drain hose can face either to the right or left of the dishwasher Ensure the hose is not bent or squashed as this could prevent or slow down the discharge of water. - Page 22 5. The purchase date Customer Care Department For general enquiries concerning your Tricity Bendix appliance or for further information on Tricity Bendix products please contact our Customer Care Department by letter or telephone at the address below. Customer Care Department...
- Page 23 08705 929 929 To contact your local Service Force Centre telephone ISLE OF LEWIS ND Macleod CHANNEL ISLANDS NORTH EAST 16 James Street Stornoway GUERNSEY Guernsey Electricity GATESHEAD Unit 356a Isle of Lewis PA87 2QW PO Box 4 Dukesway Court Vale, Guernsey Dukesway Channel Islands GY1 3AD...
- Page 24 08705 929 929 To contact your local Service Centre telephone MIDLANDS LONDON & EAST ANGLIA SOUTH EAST BIRMINGHAM 66 Birch Road East BECKENHAM 11a Gardner Ind. Estate ASHFORD Unit 2 Wyrley Trading Estate Kent House Lane Bridge Road Business Centre Witton Beckenham Bridge Road...
- Page 25 Standard guarantee conditions We, Tricity Bendix, undertake that if within 12 months of the date of purchase this Tricity Bendix appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that: The appliance has been correctly installed and used only on the electricity supply stated on the rating plate.
- Page 28 2 07/01...
- Page 29 This file has been downloaded from: www.UsersManualGuide.com User Manual and User Guide for many equipments like mobile phones, photo cameras, monther board, monitors, software, tv, dvd, and othes.. Manual users, user manuals, user guide manual, owners manual, instruction manual, manual owner, manual owner's, manual guide, manual operation, operating manual, user's manual, operating instructions, manual operators, manual operator, manual product, documentation manual, user maintenance, brochure, user reference, pdf manual...
