ACNERGY Module Installation Manual

ACN-60FB-300

Hengdian Group DMEGC Magnetics Co., Ltd

DMEGC Solar Energy

Hengdian Industrial Area, Dongyang City, Zhejiang Province China

Tel: +86-579-86554950

SYSTOSOLAR

Fax: +86-579-86554845

1 Boulevard Gabriel Guist'hau

44000 NANTES

Email: solar@dmegc.com.cn

www.kdisolar.com

DMEGC AC Module Installation Manual

ACN-120FB-330

ACN-120WOB-330

ACN-120WOB-375

Version：

202011

Table of Contents

Need help?

Do you have a question about the ACNERGY ACN-60FB-300 and is the answer not in the manual?

Questions and answers

Summary of Contents for DMEGC ACNERGY ACN-60FB-300

Page 1 DMEGC AC Module Installation Manual ACNERGY Module Installation Manual ACN-60FB-300 ACN-120FB-330 ACN-120WOB-375 ACN-120WOB-330 Hengdian Group DMEGC Magnetics Co., Ltd DMEGC Solar Energy Hengdian Industrial Area, Dongyang City, Zhejiang Province China Tel: +86-579-86554950 SYSTOSOLAR Fax: +86-579-86554845 1 Boulevard Gabriel Guist'hau 44000 NANTES Email: solar@dmegc.com.cn...
Page 2: Table Of Contents
DMEGC AC Module Installation Manual ACNERGY Module Installation Manual Table of Contents 1. IMPORTANT SAFETY INFORMATION ....................- 1 - ............................- 1 - 1.1 R EAD THIS IRST ............................- 1 - 1.2 P RODUCT ABELS ....................... - 2 - 1.3 S...
Page 3: Important Safety Information
Enphase Enlighten energy monitoring and analysis system. Read this document before installing, wiring, or using this product. Failure to comply with these instructions will invalidate the DMEGC Warranty and may cause loss, damage, injury, or death. Module limited warranty is described in The DMEGC Warranty document.
Page 4: Safety And Advisory Symbols
DMEGC AC Module Installation Manual 1.3 Safety and Advisory Symbols To reduce the risk of electric shock, and to ensure the safe installation and operation of the DMEGC Module System, the following safety symbols appear throughout this document to indicate dangerous conditions and important safety instructions.
Page 5 DMEGC AC Module Installation Manual WARNINGS: Before installing or using the Enphase Microinverter, read all instructions and cautionary markings in the  technical description, on the Enphase equipment and on the photovoltaic (PV) equipment. Do not connect Enphase Microinverters to the grid or energize the AC circuit(s) until you have completed all of ...
Page 6 DMEGC AC Module Installation Manual WARNING: Risk of equipment damage The Enphase Microinverter is not protected from damage due to moisture trapped in cabling systems. Never mate  microinverters to cables that have been left disconnected and exposed to wet conditions. This voids the Enphase warranty.
Page 7: The Enphase Iq System
Use the terminator to seal the conductor end of the Enphase Q Cable; no other method is allowed. 2. The Enphase IQ System The Enphase IQ System includes: Enphase IQ Microinverters for DMEGC AC Module, The smart grid ready Micros convert the DC output of  the PV module into grid-compliant AC power.
Page 8: How The Ac Module Works
DMEGC AC Module Installation Manual 2.1 How the AC Module Works The Enphase Microinverter maximizes energy production by using a sophisticated Maximum Power Point Tracking (MPPT) algorithm. Each Enphase Microinverter is individually connected to one PV module in your array. This configuration enables an individual MPPT to control each PV module, ensuring that maximum power available from each PV module is exported to the utility grid regardless of the performance of the other PV modules in the array.
Page 9: Preparation
DMEGC AC Module Installation Manual 3. Preparation A ) Download the Enphase Installer Toolkit mobile app and open it to log in to your Enlighten account. With this app, you can scan microinverter serial numbers and connect to the Enphase Envoy-S to track system installation progress.
Page 10: Enphase Microinverter Installation
DMEGC AC Module Installation Manual Three Phase Cable model Connector PV module orientation Connectors per box spacing* Q-25-10-3P-200 1.3m Portrait (all) Q-25-17-3P-160 2.0m Landscape (60and 96-cell) Q-25-20-3P-160 2.3m Landscape (72-cell) D ) Check that you have these other items: Racking, AC junction box, homerun •...
Page 11 Step 16: Set Up and Activate Monitoring Step 1: Operating Conditions DMEGC Photovoltaic modules be operated within the following Operating Conditions. An installation location with conditions outside the Operating Conditions or with other Special Conditions (see below) must be avoided.
Page 12 DMEGC AC Module Installation Manual Step 3: Prepare the Microinverter Before installing the PV module the microinverters must be lifted from the shipping position. On the ground, turn  the PV module so that the microinverter faces you. Using both hands, lift the microinverter up. You will hear four clicks as the microinverter locks into the ...
Page 13 DMEGC AC Module Installation Manual Step 5: Connect the Microinverter Connect the Q Cable to the microinverter. Listen for a click as the connectors engage. (See Figure 4-2)  Figure 4-2. Connect the Q Cable to the microinverter Cover any unused connectors with Enphase Sealing Caps. Listen for a click as the connectors engage.
Page 14 DMEGC AC Module Installation Manual the roof surface and the module is more than 100mm (4 inches or more). Clearance of 7 mm or more between modules is required to allow for thermal expansion of the frames.  Figure 4-6 shows using a bolt and nut for mounting.
Page 15 DMEGC AC Module Installation Manual Figure 4-4. Mounting with Clamps Do not contact allow the bolt to contact the back sheet of the module when securing the module to the mounting  rail. Do not allow the microinverter to interfere with the mounting structure rail when securing the module to the ...
Page 16 Appropriate material should be used for mounting hardware (the module frame, mounting structure, and  hardware) to prevent itself from corrosion. DMEGC does not provide a warranty for clamps. The module warranty DMEGC provides shall be voided if  clamps selected by the customer are an improper material or size.
Page 17 DMEGC AC Module Installation Manual Step 9: Terminate the Unused End of the Cable Terminate the unused end of the Enphase Q Cable (See Figure 4-6).  Remove 13 mm ( 0.5 inch) of the cable sheath from the conductors. Use the terminator loop to measure 13 mm.
Page 18 DMEGC AC Module Installation Manual Refer to the wiring diagrams in Figure 4-7 for more information. Wire colors are listed in the following table.  L1-Black Wire Colors L2-Red Figure 4-7. Sample Wiring Diagram Step 11: Energize the system Turn ON the AC disconnect or circuit breaker for the branch circuit.
Page 19 DMEGC AC Module Installation Manual Step 12: Wiring General All wiring should be done in accordance with applicable electrical codes.  All wiring should be done by a qualified, licensed professional.  Wiring should be protected to help ensure personal safety and to prevent its damage.
Page 20 Verify that all fittings are properly installed to protect cables against damage and prevent moisture intrusion.  Check your local codes for requirements.  Step 15: Ground the DMEGC ACMs Choose to use grounding clamps or module mounting holes to ground the modules. Or, you can use a reliable  third-party grounding system.
Page 21 Place the grounding wire through the grounding clamp and tighten the nuts. Method C: Grounding with third party hardware. You can use third party grounding devices for grounding of DMEGC modules, but these devices must be reliable and must be operated per manufacturer instructions. Step 16: Set Up and Activate Monitoring Refer to the Enphase Envoy-S Quick Install Guide to install the Envoy-S and set up system monitoring and grid management functions.
Page 22: Troubleshooting
DMEGC AC Module Installation Manual 5. Troubleshooting Follow all the safety measures described throughout this manual. Qualified personnel can use the following troubleshooting steps if the PV system does not operate correctly. WARNING: Risk of electric shock. Do not attempt to repair the Enphase Microinverter; it contains no user-serviceable parts.
Page 23: Troubleshoot An Inoperable Microinverter
DMEGC AC Module Installation Manual sensor reset if the cause of the failure is still present. If the condition persists, contact your installer. Method 1: Clear this Error Using Enlighten A. Log in to Enlighten and access the system. B. Click the Events tab. The next screen shows a current DC Resistance Low - Power Off condition for the system.
Page 24: Remove And Replace A Microinverter
DMEGC AC Module Installation Manual G. Visually check that the AC branch circuit connections (Enphase Q Cable and AC connections) are properly seated. Reseat if necessary. Check also for damage, such as rodent damage. H. Make sure that any upstream AC disconnects, as well as the dedicated circuit breakers for each AC branch circuit, are functioning properly and are closed.
Page 25 DMEGC AC Module Installation Manual disconnect tool. E. Press each of the four clips to free the microinverter. F. Snap new replacement microinverter into place. G. Connect the PV Module DC connectors to the microinverter. H. Scan the new serial number I.
Page 26: Maintenance And Care
6. Maintenance and care You must perform regular inspection and maintenance of the modules, especially during the warranty period. To ensure optimum module performance, DMEGC recommends the following maintenance measures: 6.1 Visual Inspection Inspect the modules visually to find if there are any visual defects, If there are, the following items should be...
Page 27: Inspection Of Connector And Cable
No responsibility is assumed by DMEGC for any infringement of patents or other rights of third parties, which may result from use of the PV product. No license is granted by implication or otherwise under any patent or patent rights.
