Ingics iBS07 User Manual

Hide thumbs
1
2
3
4
5
6
7

Advertisement

Table of Contents

INGICS
Guide
Ver.0b
Introduction
The document is a guide for iBS07. To quickly verify it, please download INGICS iBS01 Tag Utility APP from
below link(Android only):
Overview
Operation
Basically, iBS07 will always transmit BLE payload in the configured time interval in the background after power on. The
transmitted BLE payload/message is then received and uploaded to the internet/cloud server by the beacon gateway, such
as iGS01S or iGS03W/M/E. Besides background transmission, button or sensor status change will also trigger an immediate
BLE transmission for monitoring the sensor in real time.
Power on
iBS07 is in standby mode at shipping. You can power on it by pressing the front button. The LED will flash "Red" to indicate it
is powered on. After power on, the button becomes the alarm button.
INGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM
TECHNOLOGY
https://play.google.com/store/apps/details?id=com.ingics.tag.igstagconfig
iBS07 User Guide
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the iBS07 and is the answer not in the manual?

Questions and answers

Summary of Contents for Ingics iBS07

  • Page 1 BLE transmission for monitoring the sensor in real time. Power on iBS07 is in standby mode at shipping. You can power on it by pressing the front button. The LED will flash “Red” to indicate it is powered on. After power on, the button becomes the alarm button.

  • Page 2: Power Off

    Power off When necessary, users can power off iBS07 by applying a pencil with a blunt tip to the rubber button on the bottom side. The LED will flash “Orange” to indicate it is powered off and entering the standby mode.

  • Page 3: Working Mode

    INGICS TECHNOLOGY Working Mode Lux Sensor Inside iBS07, there is a lux sensor that can be used to detect lux of an environment. Accelerometer iBS07 reports raw accelerometer readings in x,y,z axles.. Temperature/Humidity Sensor iBS07 is always monitoring the environment temperature and transmitting the temperature value in the configured time interval .

  • Page 4: Changing Battery

    Level iBS07 uses a CR2450 coin battery as the power source. It consumes only a little power and keeps working for a long time. Below is a suggestion for translating the battery voltage to the remaining capacity at room temperature.
  • Page 5 INGICS TECHNOLOGY Configuration When powered on, iBS07 will be in configuration mode for 20 sec. Users can use iBS01 Tag Utility to scan and connect iBS07 to configure the transmit power and ADV(advertising) interval. Steps 1. Power on iBS07 2. Press the CONFIG icon on the up-right 3.
  • Page 6 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. NCC 警語 「取得審驗證明之低功率射頻器材，非經核准，公司、商號或使 用者均不得擅自變更頻率、加大功率或變更原設計之特性及功能。低功率射 頻器材之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應 立即停用，並改善至無干擾時方得繼續使用。前述合法通信，指依電信管理 法規定作業之無線電通信。低功率射頻器材須忍受合法通信或工業、科學及 醫療用電波輻射性電機設備之干擾。」 INGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM...

  • Page 7: Revision History

    INGICS TECHNOLOGY Revision History DATE REVISION CHANGES Apr 12, 2023 Initial release Jun 6, 2023 Updated FCC and NCC statement INGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM...
