Operating Instructions
Parts Breakdown
Some dust created by power sanding, sawing, grinding,
drilling, and other construction activities contains chemicals
known to cause cancer, birth defects or other reproductive
harm. Some examples of these chemicals are:
• lead from lead-based paints,
• crystalline silica from bricks and cement
and other masonry products, and
• arsenic and chromium from
chemically-treated lumber.
Your risk from these exposures varies, depending on how
often you do this type of work. To reduce your exposure to
these chemicals: work in a well ventilated area, and work with
approved safety equipment, such as those dust masks that are
specially designed to filter out microscopic particles.
Blows per minute . . . . . . . . . . . . . . 3200 BPM
Shank Opening . . . . . . . . . . . . . . . . . . . .401"
Bore . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3/4"
Stroke. . . . . . . . . . . . . . . . . . . . . . . . . . . .2-5/8"
Hose Size . . . . . . . . . . . . . . . . . . . . . . . 3/8" I.D.
Air Inlet . . . . . . . . . . . . . . . . . . . . . . . . . . . 1/4"
Air Pressure . . . . . . . . . . . . . . . . . . . . . . . 90 PSI
Air Consumption . . . . . . . . . . . . . . . . . . 4 CFM
Sound Level . . . . . . . . . . . . . . . . . . . . .100 dBA
Length . . . . . . . . . . . . . . . . . . . . . . . . . . .9-1/4"
CAT-190AHK6
SPECIFICATIONS
1
AlwAYS reAd
inSTrucTionS
before uSing
power ToolS
AlwAYS weAr
SAfeTY goggleS
weAr heAring
proTecTion
Avoid
prolonged
expoSure To
vibrATion
CAT-190AH
Heavy Duty
190MM
Air Hammer
Rev. 07/24/07
Advertisement
Table of Contents
Summary of Contents for Cornwell Tools CAT-190AH
- Page 1 Shank Opening .... .401" CAT-190AH Bore ......3/4"...
- Page 2 WARNING - FOLLOW THESE RULES FOR SAFE OPERATION! This Instruction Manual Contains • Place the tool on the work before starting the tool. Important Safety Information. Do not point or indulge in any horseplay with this tool. ReAD THIS INSTRUCTION • Slipping, tripping and/or falling while MANUAL CAReFULLy AND operating air tools can be a major cause UNDeRSTAND ALL INFORMATION of serious injury or death. Be aware of BeFORe OPeRATINg THIS TOOL. excess hose left on the walking or work surface. • Always operate, inspect and maintain • Keep body working stance balanced this tool in accordance with American and firm. Do not overreach when National Standards Institute Safety operating the tool. Code of Portable Air Tools (ANSI B186.1) and any other applicable • Anticipate and be alert for sudden changes in motion safety codes and regulations. during start up and operation of any power tool. • For safety, top performance and • Do not carry tool by the hose. Protect maximum durability of parts, operate this tool at 90 the hose from sharp objects and heat. psig 6.2 bar max air pressure with 3/8” diameter air • Tool shaft may continue to rotate supply hose. briefly after throttle is released. Avoid • Always wear impact-resistant eye direct contact with accessories during and face protection when operating...
- Page 3 LUbRIcATION Lubricate the air motor daily with quality air tool oil. If Nipple no air line oiler is used, run 1/2 oz. of oil through the tool. The oil can be squirted into the tool air inlet or into the hose at the nearest connection to the air sup- ply, then run the tool. Overfilling will cause a reduction in the power of the tool. OPERATION Always place a chisel in the hammer and hold the tool AIR SUPPLY down to the work before operating. Damage to the tool or the retainer may result if this precaution is not Tools of this class operate on a wide range of air pres- followed. sures. It is recommended that air pressure of these tools measures 90 PSI at the tool while running free. Higher The chisel retainers are not designed for complete pressure (over 90 psig; 6.2 bar) raises performance safety against accidental release of cutters or ham- beyond the rated capacity of the tool which will mers. To avoid injury, the throttle must never be shorten the tool’s life because of faster wear and depressed unless the chisel is held firmly against the could cause injury. work place. When tool is not in actual use, the chisel must be removed. During operation, safety goggles Always use clean, dry air. Dust, corrosive fumes and/or should always be used to guard against flying rust and water in the air line will cause damage to the tool. chips. When using tool, regulate the speed so that the Drain the air tank daily. Clean the air inlet filter screen chisel is not being driven out of the cylinder. If piston is on at least a weekly schedule. The recommended hook- allowed to strike the cylinder wall, internal damage up procedure can be viewed in the above figure. will result. The air inlet used for connecting air supply, has standard 1/4"...
- Page 4 PARTS bREAKDOWN - cAT-190AH R ef. # Item # DESCRIPTION Ref. # Item # DESCRIPTION 15 RS171815 Valve Block Assembly RS248001CWL Housing 17 RS171816 Valve Disc RS848002 Roll Pin (3 x 22mm) 20 RS648019 Piston RS848003 Inlet Bushing 21 RS648220 Cylinder RS848004 Cap 22 RS248022CWL Comfort grip RS848005 O-Ring (4.9 x 2.2mm) 23 CCR130 Quick Change Chisel Retainer RS848006...
