DN300
Revision A
Operation Manual
(Including Maintenance Requirements)
DataNode Code Version: 3.080 and above
Note: Please use the latest revision number to ensure you have the latest
information. Copies of this manual are available from Rimik and may be
available from the Rimik website.
DN300 Operation & Maintenance Manual
Revision A
Page1
Advertisement
Table of Contents
Related Manuals for Rimik DN300
Summary of Contents for Rimik DN300
- Page 1 DataNode Code Version: 3.080 and above Note: Please use the latest revision number to ensure you have the latest information. Copies of this manual are available from Rimik and may be available from the Rimik website. DN300 Operation & Maintenance Manual...
- Page 2 Any representation, statement, opinion or advice, expressed or implied in this publication is made in good faith and on the basis that Rimik, its agents and employees, are not liable (whether by reason of negligence, lack of care or otherwise) to any person for any damage or loss whatsoever which has occurred or may occur in relation to that person taking or not taking (as the case may be) action in respect of any representation, statement or advice referred to above.
-
Page 3: Table Of Contents
DataNode Connections ........................5 Power Supply and Fuses ........................8 Input/Output Modules ........................9 Starting up and powering down the DN300 ..................9 Connecting to the DN300 ................ Error! Bookmark not defined. Maintenance ............................12 Via On-Site Maintenance ........................12 Troubleshooting ............................ -
Page 4: Referenced Documents
Referenced Documents The Rimik DataNode is a modular device that can be utilised in several formats including a simple logger or as part of a Telemetry system. In its telemetry format the DataNode can operate as a FieldNode, Gateway or Standalone unit in conjunction with the Rimik API and Web Interface. -
Page 5: Datanode Connections
Plate, Post, Clamp, as required Figure 1: Free standing DN300 Unit with main components Mains powered systems do not require the Solar Panel Kit. We do recommend a backup battery together with a solar/mains charger module. Mains powered systems with battery backup are supplied with an approved mains powered 18VDC solid state plug pack. - Page 6 2 pin flat connector 5.08mm pitch for the backup battery 10. Solar In 2 pin flat connector 5.08mm pitch for solar or mains (18V DC) Figure 2: DN300 Connect Board with 4+1 ports. Populated with various modules DN300 Operation & Maintenance Manual Revision A...
- Page 7 (see Figure 3). Please note that the USB socket takes priority. When a laptop or PC is connected via the USB port the TELEM L socket is disabled. In practice this means that the DN300 will not be able to communicate with the module plugged into the left socket. If that is a modem then the unit will be off line while the USB port is actively connected to an external device.
-
Page 8: Power Supply And Fuses
Power Supply and Fuses The DN300 unit has been designed for 24 hour operation at remote unpowered sites where solar recharge is necessary. However, it can operate solely on mains power at mains powered sites with or without a backup battery. Battery only operation is also possible for short term logger placement. -
Page 9: Input/Output Modules
Where the system is provided for a standard application or the client has specified the configuration the DN300 unit may be supplied preconfigured. Where that is not the case, modules can be easily fitted but some care must be taken to ensure there are mounted correctly (not offset) and that the port is configured before connecting and operating external devices. -
Page 10: Connecting To The Dn300
To use the Rimik software interface the software must be installed on a laptop or PC. In addition the technician will require a USB C to USB Mini communication cable. Plug the USB C into the laptop and the USB Min into the socket on the module panel (see Figure 2, #1). - Page 11 IP. If you are required to undertake a firmware update, you will be supplied with a XXX.hex file from Rimik. Save it in a location that can be accessed by DN CT. The DN CT software has an embedded Firmware Update tool. Click on “Firmware Update” in the menu list to enter this function.
-
Page 12: Maintenance
As the solar panel will only commence charging the battery when enough sunlight is present, a correctly operating system should be flashing green during the morning and reach fully charged state during DN300 Operation & Maintenance Manual Revision A Page12... - Page 13 Direct Connection Where necessary, directly connect to the DataNode via a laptop with a Rimik serial cable and Interface software. Once connected all system parameters can be checked and stored data downloaded. The following on-site interface checks are not essential but are...
-
Page 14: Troubleshooting
Chek the solar panel voltage across the 2 corroded pin plug when connected and when Not Charging disconnected from the DN300. It should read approximately 20 volts across the plug when disconnected and about 18V when connected and in good light. Check that all external and internal connections are firmly seated and clean. - Page 15 Notes: DN300 Operation & Maintenance Manual Revision A Page15...
