Summary of Contents for GTS PLANNER 510 HD

  • Page 1 Planner 510 Versatility for any work INSTRUCTIONS MANUAL PARTS CATALOGUE T e c h n o l o g y f o r t h e W o r l d It is more Technology...
  • Page 2 Code: MD160014 Published in: 08/30/2007 Revision: C...

  • Page 3: Table Of Contents

    GTS Post-sale Services and Information 9.1 - GTS Warranty Term _________________________________________ 60 9.2 - GTS Technical Assistance ____________________________________ 61 9.3 - Technical Delivery - 1st Sheet: Customer_________________________ 62 9.4 - Technical Delivery - 2nd Sheet: (send to GTS Brasil) ________________ 64...

  • Page 4: Introduction

    See page 26 about how to request it. Dear Owner: Due to a frequent improvement Policy in its products, GTS has the right to make alte- ratons and improvements with no obligations about the products previously manufactured.

  • Page 5: Safety Recommendations

    Rear Plane PLANNER 510 2 - Safety Recommendations 1 - Before using the Plane, read carefully the current manual and follow the warnings attached to the equipment. Note: see the decals identification on page 24. 2 - Bearing in mind that safety demands attention, caution, concentration and discretion during coupling and disengaging operations, adjustments, inspections, maintenance and storage of the...
  • Page 6 GTS Brasil does not recommend equipment transit in roads and highways. Besides safety serious risks involved, Transit Legislation prohibits such driving. However, if you're going to do it, it is stated that GTS is totally exempt of any respons ibility.

  • Page 7: Technical Characteristics And Specifications

    Rear Plane PLANNER 510 3 - Technical Characteristics and Specifications 3.1 - Components Identification 1 - Plane coupling terminal to the tractor Adjustment Cylinders: traction bar. C1 Plane side displacement cylinder. C2 Blade lifting cylinder. 2 - Heading C3 Blade rotation (horizontal inclination) 3 - Blade cylinders 4 - Replaceable cutting edge.

  • Page 8: St Components Identification

    Rear Plane PLANNER 510 3 - Technical Characteristics and Specifications 3.1 - Components Identification 1 - Plane coupling terminal to the tractor Adjustment Cylinders: traction bar. C1 Plane lifting cylinder. C2 Blade rotation (horizontal inclination) 2 - Heading cylinder. 3 - Blade C3 Blade vertical inclination cylinder Note: even having 4 different hydraulic 4 - Replaceable cutting edge.

  • Page 9: Hd Technical Specifications

    Rear Plane PLANNER 510 3.2 - Technical Specifications Dimensions: Total length............7820 mm Blade Length ............4242 mm Height with Blade lifted up ........2660 mm Wheel set external width ......... 2750 mm Total weight w/ ballast............ 3300 kg Additional maximum weight..........500 kg Wheels (Tires / rims) ............

  • Page 10: St Technical Specifications

    Rear Plane PLANNER 510 3.2 - Technical Specifications Dimensions: Total length ............7720 mm Blade length ............3636 or 4242 mm Height with blade lifted up ........2660 mm Wheel set external width .......... 2650 mm Total weight w/ ballast ............ 2960 kg Additional maximum weight..........
  • Page 11 Rear Plane PLANNER 510 Hydraulic System Diagram Rear Lifting Side Articulation Blade Cylinders Cylinders Cylinders Cylinders (wheel) Valve 2 Valve 1 Tractor...
  • Page 12 Rear Plane PLANNER 510 Hydraulic System Diagram Rear Rear Lifting Cylinders Lifting Blade Cylinders Cylinders Cylinders (wheel) Cylinders (wheel) Valve Tractor Tractor...

  • Page 13: Equipment Preparation, Adjustments And Operation

    Rear Plane PLANNER 510 4 - Equipments preparation, adjustments and operation 4.1 - Plane Coupling and disengaging to the Tractor ST with mechanic blade rotation ST with hydraulic blade rotation Electro valve function selector . Electro valves function selector. Hydraulic Hoses a) Approach the tractor to the Plane heading and connect the hoses (1 e 2) to the tractor remote control as follows:...
  • Page 14 Rear Plane PLANNER 510 Electric Control (functions selector) Rotation Displacement b) Position the functions selector panel (4) (4) inside the cabin or operation platform. Note 1: the panel has magnetic bed, attaching itself in any metallic surface. OBS 2 - cabin tractors: pass the cable (3) in an appropriate place for this.

  • Page 15: Plane Carrying

    Rear Plane PLANNER 510 a) Activate the blade inclination cylinder so that it remains parallel to the ground. To do it, put the selector (D) at "Inclination" position and activate the cylinder with the lever (34) from teh remote control. b) Activate the Plane lifting cylinder Plane to support the blade on the ground.

  • Page 16: Wheels Ballasting (With Water)

    Rear Plane PLANNER 510 4.3 - Wheels Ballasting (with water) The Plane wheels ballasting is recommended to allow more firmness and stability to the Plane set. The tires (14-9-26) used on the HD Plane, allow the introduction of 182 liters of water each, which give a good ballasting. The tires (12-4-24) used on the ST Plane, allow the introduction of 114 liters of water each, which give a good ballasting.

  • Page 17: Wheels Opening Adjustment (Gauge)

    Rear Plane PLANNER 510 4.4 - Wheels Opening Adjustment (gauge) The smaller gauge could be used if necessary only to carry it on load vehicles with maximum width of 2,4 m of its platform. For all working situations, it is necessary to use the bigger gauge (pic.

  • Page 18: Blade Rotation Adjustment

    Rear Plane PLANNER 510 4.5 - Blade Rotation Adjustment 1 - Pull the rope (1), to unlock the positioner arch lever(1A). 2 - Incline the blade (2A), locking the corner under the ground. 3 - Move the tractor forward or backward, according to the desired rotation, keeping the lever activated.

  • Page 19: Hd Hydraulic Controls Use

    Rear Plane PLANNER 510 5 - Adjustements and Operation 5.1 - Hydraulic Controls Use Cylinders: C1 Side Displacement C2 Blade Lifting C3 Blade Rotation Cylinders C4 Blade Inclination Cylinder Remote Control Levers 12- Hydraulic cylinders control levers (C1 and C2), according to the left selector position (E).

  • Page 20: Adjustments And Operation

    Rear Plane PLANNER 510 5 - Adjustments and Operation 5.1 - Hydraulic Controls Use Cylinders: C2 Blade Lifting C3 Blade Rotation Cylinders C4 Blade Inclination Cylinder Remote Control Levers 12- Hydraulic cylinders control levers (C1 e C2), according to the left selector position (E).

  • Page 21: Recommended And Non-Recommended Applications For Gt Plane

    Rear Plane PLANNER 510 5.2 - GTS Plane Recommended and Non-recommended Applications - NON-Recommended Applications: Trunks move. Anything that represents excessive loadings, especially on the side edges of the blade. Recommended Applications (See description on the sequence): A) Levelling B) Planishing C) Drainer Channels Opening D) Terrace Construction or conservation in contour line.
  • Page 22 Rear Plane PLANNER 510 2 - Blade Rotation (horizontal inclination) This adjustment is performed via remote control, through cylinders (C3), that rotate the blade according indicated by the arrows on the picture. The objective is to adapt: The blade angle related to the displace- ment line.
  • Page 23 Rear Plane PLANNER 510 2 - Blade Rotation (horizontal inclination) This adjustment is performed via remote control, through cylinders (C3), that rotate the blade according to the arrows on the picture. The objective is to adapt: The blade angle related to the displace- ment line.

  • Page 24: Operation Techniques

    Rear Plane PLANNER 510 5.4 - Operation Techniques A) Levelling* It is to level a ground, which is, with the surface in a certain angle. The picture below represents a typical situation, where the dotted line repre- sents the level and quota in which we want to let the ground. The work is basically to give consecutive passes from top to down, contro- lling the blade depth to get the profile of the dotted line.
  • Page 25 Rear Plane PLANNER 510 B) Planishing* It is to let a soil flat, even, which is, a surface with a flat finishing, regular. Examples: Roads construction or conservation, dikes, gorges and sluits closing (holes and channels generated by spates and erosion respectively), etc.
  • Page 26 Rear Plane PLANNER 510 C) Drainage Channels Opening Fig. C1 Pic. C2 For this operation, it must incline the blade for one of the sides and controls its depth, according desired depth to the channel or the tractor traction capacity. The number of passes will depend on the channel size.

  • Page 27: Maintenance And Conservation Instructions

    Rear Plane PLANNER 510 6 - Maintenance and Conservation Instructions 6.1 - Grease Lubrication Points Frequency: Daily, or each 10 hours (see decals on the Plane, shown on the picture). LUBRICATE EVERY Recommended Grease: 10 HOURS Litium soap based-grease, type NLGI 2 Grease application points 1 - Inclination cylinder connecting-rod bearing 2 - Inclination cylinder head bearing...

  • Page 28: Tires Calibration And Cares

    Rear Plane PLANNER 510 6.2 - Tires Calibration and Cares The tires assembly must be done only by ex- perienced people and appropriate tools. A wrong assembly may explode the tire during calibration, and may cause serious injuries and even death. It is safer to trust this job to a professional one.

  • Page 29: Blade Maintenance

    Rear Plane PLANNER 510 6.4 - Blade Maintenance The blade act of cutting, is performed by the edge (1), that it is replaceable. It cannot be sharpening, and should be replaced when presents abrasion and makes it difficult to perform the job. The edge is attached to the blade through a pair of screws, which nuts must be tighten on the torque of 293 N/m.

  • Page 30: Parts Catalogue

    Parts Catalogue...
  • Page 31 Index 8- Parts Catalogue HD Pistons ST Pistons Blade with Hydraulic Activation Blade with ST Manual Activation Rear Set HD Front Set ST Front Set HD Hydraulics Electric ST Hydraulics Electric ST Hydraulics Wheel Set Counterweights Adhesives...
  • Page 32 Rear Plane PLANNER 510 Pistons...
  • Page 33 Rear Plane PLANNER 510 Pistons ITEM CODE DESCRIPTION Wheel Piston Set 510 4 X 640 X 63.5 PM000541 Displacement Piston Set 510 4 X 256 X 63.5 PM000544 Blade Piston Set 510 3 X 815 X 57.15 PM000543 Lifting Piston Set 510 5 X 270 X 50.8 PM000542 Tilting Axle Weld Set ø40 X 173 PM000546...
  • Page 34 Rear Plane PLANNER 510 Pistons...
  • Page 35 Rear Plane PLANNER 510 Pistons ITEM CODE DESCRIPTION Wheel Piston Set 510 4 X 640 X 63.5 PM000541 Lifting Piston Set 510 5 X 270 X 50.8 PM000542 Wheel Pivot Weld Set ø40 X 103 PM000550 Lifting Piston Axle ø 40 X 303 PS000807 Lifting Piston Axle ø...
  • Page 36 Rear Plane PLANNER 510 Blade with Hydraulic Activation...
  • Page 37 Rear Plane PLANNER 510 Blade with Hydraulic Activation ITEM CODE DESCRIPTION PM000563 Blade Weld Set 4242 - Planner 510 - HD PM000564 Blade Weld Set 3636 - Planner 510 - ST PS000654 Straight Blade Cut - 2131,2 - HD PS000810 Blade Cut - 1826,40 (Ref.
  • Page 38 Rear Plane PLANNER 510 Blade with ST Manual Activation...
  • Page 39 Rear Plane PLANNER 510 Blade with Manual Activation ITEM CODE DESCRIPTION PM000564 Blade Weld Set 3636 - Planner 510 PS000810 Blade Cut 1826,40 (Ref.124874) Yellow PM000547 Blade Main Axle Weld Set ø60 X 430 MD020103 Hex. Screw M12x50 MB 10.9 FZF MD180002 Special Flat Collar 13.3x33x3 RB PS000897 Fixing Pivot Bushing 22.22x13X14...
  • Page 40 Rear Plane PLANNER 510 Rear Set...
  • Page 41 Rear Plane PLANNER 510 Rear Set ITEM CODE DESCRIPTION PM000567 Rear Axle Weld Set Planner 510 PM000561 Intermediate Articulator Weld Set PS000716 Main Bearing 8 Holes MD020089 Hex. Screw M12x65 MB 10.9 FZF PM000551 Rear Piston Flange Weld Set PM000514 Rear Pisto Lock Weld Set PM000554 Right Directional Arm Weld Set Planner 510...
  • Page 42 Rear Plane PLANNER 510 Front Set...
  • Page 43 Rear Plane PLANNER 510 Front Set ITEM CODE DESCRIPTION PM000565 Main Weld Set - Planner 510 HD PM000562 Front Chassis Weld Set Planner 510 HD PS000804 Side Tilting Axle ø 60 X 530 PS000806 Lifting Main Axle ø 60 X 474 MD020046 Hex.
  • Page 44 Rear Plane PLANNER 510 Front Set...
  • Page 45 Rear Plane PLANNER 510 Front Set ITEM CODE DESCRIPTION PM000566 Main Weld Set - Planner 510 ST PS000806 Lifting Main Axle ø 60 X 474 MD030006 Elastic Pivot M12x90 MD020046 Hex. Screw M12x100 MA ZB 8.8 MD040010 Hex. Nut M12 MA Autoblock ZB 8.8 MD040031 Hex.
  • Page 46 Rear Plane PLANNER 510 Hydraulics Electric...
  • Page 47 Rear Plane PLANNER 510 Hydraulics Electric ITEM CODE DESCRIPTION PM000488 Solenoid+Directioner+Valve Set (3192376) PM000487 Plug S-9005 Ref. Steck MD020100 Cylinder Head Screw M8X90 MA Blackish 12.9 MD040027 Hex. Nut M8 w/ Flange Torque MA ZB 8.8 MD140002 Adapter M22x1.5 X 11/16 UNF Flat Place MD140006 Adapter M22x1.5 X 13/16 UNF Flat Place MD010011...
  • Page 48 Rear Plane PLANNER 510 Hydraulics Electric...
  • Page 49 Rear Plane PLANNER 510 Hydraulics Electric ITEM CODE DESCRIPTION PM000488 Solenoid+Directioner+Valve Set(3192376) PM000487 Plug S-9005 Ref. Steck MD020100 Cylinder Head Screw M8X90 MA Blackish 12.9 MD040027 Hex. Nut M8 w/ Flange Torque MA ZB 8.8 MD140002 Adapter M22x1.5 X 11/16 UNF Flat Place MD140006 Adapter M22x1.5 X 13/16 UNF Flat Place MD010011 Oring 3-909 - INT.17.93 X SEC 2.46 MD010009 Oring 2-012 - INT.9.25 X SEC 1.78...
  • Page 50 Rear Plane PLANNER 510 Hydraulics...
  • Page 51 Rear Plane PLANNER 510 Hydraulics ITEM CODE DESCRIPTION PM000495 Hose Set w/Tractor 2500mm Sugarcane PM000603 Lifting / Block Hose Set 1000mm PM000600 Wheel Piston Hose Set 3050mm PM000538 Front Chassis Inferior Hydraulic Pipe Set ST PM000539 Front Chassis Upper Hydraulic Pipe Set ST MD140001 Adapter 3/4 UNF X 11/16 UNF Flat Place MD010008...
  • Page 52 Rear Plane PLANNER 510 Wheel Set...
  • Page 53 Rear Plane PLANNER 510 Wheel Set ITEM CODE DESCRIPTION PS000841 Axle Neck 6.0 Ton Planner 510 MD050011 Ball bearing PS000840 Wheel Hub PS000842 PS000843 Collar MD020816 Screw MD040037 Nut PM000568 Rim Weld Set W 10 X 24 - ST PM000540 Rim Weld Set DW 13 X 26 - HD PS000816 24 Chamber - T640 - Wheel 12.4.24 - ST...
  • Page 54 Rear Plane PLANNER 510 Counter weights...
  • Page 55 Rear Plane PLANNER 510 Counter weights ITEM CODE DESCRIPTION PS000718 Counter weight 40Kg MD020052 Hex. Screw M16x45 MA ZB 8.8 MD170018 Pressure Collar B16 ZB MD180003 Special Flat Collar 16,8x36x5,0 ZB...
  • Page 56 Rear Plane PLANNER 510 Adhesives...
  • Page 57 MD150251 Screw Retighten Attention Adhesive MD150194 Manual Attention Adhesive MD150185 Planner 510 Adhesive MD150188 Side GTS (Planner/New Line) Adhesive Lifted Lock Attention Adhesive Planner 510 MD150246 MD150245 Axle Lock Attention Adhesive Planner 510 P MD150249 Adhesive HD Planner 510 Adhesive ST Planner 510...

  • Page 59: Gts Post-Sale Services And Information

    1. The Warranty is valid for the first 12(twelve) months, starting on the date in which the machine was delivered to the first user. 2. The current Warranty consists, on GTS Brasil Ltda commitment, to repair or to supply free of charge, in its factory, the parts which present manufacturing defects, previously analyzed.

  • Page 60: Gts Warranty Term

    Plane correctly. However, if some unforeseen happened, we advise to look for assistance at the nearest Authorized Dealer. If it's necessary, the Dealer will request for help to the GTS Technical Assistance. GTS do Brasil Ltda. Manufactoring and Sales Agricultural Machines and Implements.

  • Page 61: Gts Technical Assistance

    Rear Plane PLANNER 510 9.3 - Technical Delevery - 1st Sheet: Customer 1 - Customer Information Dear Customer: the information requested below, is to allow GTS Brasil Ltda to know you better. Name: ____________________________ Address:_______________________________ City/Town:_________________________ State:_________________________________ Main activities performed in your land:...
  • Page 63 Rear Plane PLANNER 510 9.4 - Technical Delevery 2nd sheet - (sent to GTS) 1 - Customer Information Dear Customer: the information requested below, is to allow GTS Brasil Ltda to know you better. Name: ____________________________ Address:_______________________________ City/Town:_________________________ State:_________________________________ Main activities performed in your land:...
  • Page 66 VERSATILITY FOR ANY WORK T e c h n o l o g y f o r t h e W o r l d It is more Technology w w w . g t s d o b r a s i l . c o m . b r 3000, Alcides Baccin Street, •...
